BNI EIP-508-105-Z067
Network interface
6
WebUI/web interface (continued)
The c
iO-l
Onnected inK deviceS
form of a list of currently connected IO-Link devices as well
as the associated, required IODD file name (column iOdd
f ).
ilenaMe
To avoid manual renaming of the associated image
files, we recommend uploading ZIP files with the
IODD content.
Firmware
Under f you can see which version of the firmware
irMware
is being used and when it was uploaded. Via f
u , you can upload a different firmware version. Only
plOad
files in BFW format are supported.
Fig. 6-37: Firmware view
Output test
Via the O dialog, every output pin can be tested
utput teSt
online. To set the output to either 0 or 1, the respective pin
must be configured first as a d
p dialog. At a physical port, a maximum of 2 pins can
OrtS
be configured accordingly, depending on the variant. This
can either be confirmed via i/O p
cOnfiguratiOn fOr all pOrtS
or can be done individually. In the following example
illustration, some available pins are configured as digital
outputs:
Fig. 6-38: Output test (example)
40 english
bar also displays help in the
irMware
O via the i/O
igital utput
> S
OrtS et Specified
: > d > S > S
igital Out et all et all
6.7

Notifications

Via the navigation bar, click on the corresponding icon (see
chapter 6.2 on page 25) to access the notifications (see
Fig. 6-39).
Fig. 6-39: Notification: Request for password change
The notification history can be deleted with d
6.8 REST API
Via the REST-API interface, identification data, process
data and configuration settings of the IO-Link master and
other connected devices can be requested and modified.
The REST API interface is also used by the user interface
of the web interface for communication with the module.
The REST API specification implemented in the module is
saved in YAML files in the device and can be downloaded
(i > l ) and displayed, e.g., in the
nfO Ocal dOcuMentS
Swagger Editor (http://editor.swagger.io/).
The present module supports the following REST APIs:
– Generic REST API for Balluff devices and applications.
Base path of the REST API in the module:
http://[ip-address]/api/balluff/v1/
– The REST API (JSON for IO-Link) standardized by the
IO-Link community.
.
elete all
