BNI EIP-502-105-Z015
IP67 Modules
4 IO Link/In-/Outputs,12 In-/Outputs
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BNI EIP-502-105-Z015 and is the answer not in the manual?

Questions and answers

Summary of Contents for Balluff BNI EIP-502-105-Z015

  • Page 1 BNI EIP-502-105-Z015 IP67 Modules 4 IO Link/In-/Outputs,12 In-/Outputs User’s Guide...
  • Page 2 6.1. Process Data Inputs Standard Input Data IO Link Input Data 6.2. Process Data Outputs Standard Output Data IO Link Output Data Display 7.1. General 7.2. Adress Defaults 7.3. Controls and visualization 7.4. Display information 7.5. Design and Symbols www.balluff.com...
  • Page 3 Balluff Network Interface EtherNet/IP™, BNI EIP-502-105-Z015 7.6. Startup 7.7. Main Menue 7.8. IP Setup 7.9. IP Config 7.10. Module information 7.11. General Informations Webserver 8.1. General 8.2. Home 8.3. Diagnostic Process 8.4. Device Properties 8.5. Diagnostic Module 8.6. Configurations Appendix 9.1.
  • Page 4: Note

    4 ”Technical Data”). 1.4. Symbols Note tip This symbol indicates general notes. Note This symbol indicates a security notice which most be observed. 1.5. Abbreviations Balluff Network Interface Standard input port EtherNet/IP™ Electromagnetic Compatibility Function ground Standard output port www.balluff.com...
  • Page 5: Safety

    Note voltage Disconnect all power before servicing equipment. Note In the interest of product improvement, the Balluff GmbH reserves the right to change the specifications of the product and the contents of this manual at any time without notice. www.balluff.com...
  • Page 6: Getting Started

    Status LED: Communication / Module Port 1 (Standard I/O) Port 5 (Standard I/O) Power Supply Port Pin/Port LED : Signal status Label Port 6 (Standard I/O) EtherNet/IP™ port 1 Port 7 (IO Link, Standard I/O) Grounding connection Port 8 (IO Link, Standard I/O) www.balluff.com...
  • Page 7: Mechanical Connection

    Balluff Network Interface EtherNet/IP™, BNI EIP-502-105-Z015 Getting Started 3.2. Mechanical The module is attached using 2 M6 screws and 2 washers. connection Isolation pad as accessory available 3.3. Electrical connection Power Supply Function Description +24 V Actuator power supply +24 V Module / sensor power supply 7/8”, male...
  • Page 8: I/O-Port

    9 amperes. Note! Unused I/O port socket must be fitted with cover caps to ensure IP67 protection rating. IO Link-Port M12, A-coded, female Function +24V, 1,6 A Input / Output IO Link / Input / Output n.c. www.balluff.com...
  • Page 9: Technical Data

    Balluff Network Interface EtherNet/IP™, BNI EIP-502-105-Z015 Technical data 4.1. Dimensions 4.2. Mechanical data Housing material Die case zinc, matt nickel plated Enclosure rating per IEC 60529 IP 67 (only when plugged-in and threaded-in) 7/8” 4-pin male Supply voltage Input ports / Output ports...
  • Page 10: Ethernet

    IO Link IO Link communication running Green IO Link No IO Link communication flashing Short-circuit single LED: Short-circuit on Pin 4 both LEDs: Short-circuit between Pin 1 and 3 IO Link IO Link Device has wrong configuration flashing www.balluff.com...
  • Page 11: Integration

    Balluff Network Interface EtherNet/IP™, BNI EIP-502-105-Z015 Integration 5.1. Data Please enter the following values to your Control System. They describe the datasizes for Configuration input, output and config data. Instance ID Data length INPUT OUTPUT CONFIG 5.2. Config Data In the following tables you can see the mapping of the configuration data string. The default values which are stated below describe a configuration with IO Link function on Pin 4 and standard input function (normally open) on Pin 2 of each IO Link port.
  • Page 12: Process Data

    Error Code Additional Code Event 1 Additional Code Error Code Additional Code Event 2 Additional Code Error Code Additional Code Event 3 Additional Code … The data of the other IO Link ports has the same structure and follows here www.balluff.com...
  • Page 13: Process Data Outputs

    Balluff Network Interface EtherNet/IP™, BNI EIP-502-105-Z015 Process Data 6.2. Process Data There are 134 bytes of output data. Have a look at the tables below to see the mapping of Outputs the process data outputs. Byte Modul part Description 0…5...
  • Page 14: Display

    6 LED 7.4. Display Cursor for selecting address type information Cursor zur Auswahl der Adressausprägung Cursor for selecting octet IP: IP address 3: fourth octet SN: Subnet address 2: third octet GW: Gateway address 1: second octet 0: first octet www.balluff.com...
  • Page 15: Design And Symbols

    Balluff Network Interface EtherNet/IP™, BNI EIP-502-105-Z015 Display 7.5. Design and There are some symbols used in the following flow-charts to describe the display- Symbols functionality: actual state change-over condition: short-time keypress on set key condition: long-time keypress on setkey (min. 3 seconds) ...
  • Page 16: Ip Setup

    The entered value can immediately seen on the ip overview screen. • Manual changes of ip, subnet or gateway results in automatic change to “static” in IP Setup. Note: To work with the new configuration the module needs a power-down reset. www.balluff.com...
  • Page 17: Module Information

    Balluff Network Interface EtherNet/IP™, BNI EIP-502-105-Z015 Display 7.10. Module  information Version MAC-ID   …  EIP-502- SW: x.x XX : XX : XX : 100-Z016 HW: x.x XX : XX : XX • By short-time keypress on arrow key you can scroll through module information menu.
  • Page 18: Webserver

    First make sure that a correct integration into your network has been done. To get a connection to the webserver enter the IP address of the module to your browser address bar. A welcome page with a list of all Balluff Ethernet Network-interfaces is shown. Please use Internet Explorer 7 or higher.
  • Page 19: Appendix

    502 = IP 67 IO Link Master-Modul Variants 105 = Display version, 2-port switch Mechanical version Z015 = Die-cast zinc housing Material: 1. Balluff housing version Uplink: 2 x M12x1 internal thread Power: 7/8“ external thread Sensor Ports: 8 x M12x1 internal thread 9.3. Order Information...
  • Page 20 Balluff GmbH Schurwaldstrasse 9 73765 Neuhausen a.d.F. Germany Tel. +49 7158 173-0 Fax +49 7158 5010 www.balluff.com balluff@balluff.de...
