Summary of Contents for ANCEL S1000
- Page 1 Automotive Diagnostic Leak Detector User Manual...
- Page 2 Smoke Oil The equipment is compa�ble with mineral oil based baby oil like Johnson&Johnson Pink bo�le. Pure #5 white oil is the best choice if available. Specifica�on Model S1000 S2000 S3000 Pressure Gauge Flow Indica�on Flow Control Flow Rate <6 L/Min...
- Page 3 Accessories Explana�on Power Cord To offer connec�on from the unit to the automobile ba�ery, in order to drive the unit. Smoke Delivery Hose For introduc�on of smoke from the unit to Adapter Cone / Universal Intake Bladder or to the vacuum pipe directly.
- Page 4 C - Smoke Outlet Port While set up the unit, the Smoke Delivery Hose need to be mounted onto the Smoke Outlet . D - Power Socket While set up the unit, the power cords need to plug into the power socket. E,F - State Indica�on and Air Control The <E - LED Indication>...
- Page 5 L - Oil Level Gauge While set up the unit, smoke oil need to be filled into the unit, do not exceed the MAX line. Check and confirm proper oil level periodically. If the oil level is lower than the MIN line,the unit would need a refill.
