Joie C2005B Quick Reference

Armour
MODEL C2005B
quick reference
IMPORTANT: After reading this Quick Reference read the
Instruction Booklet carefully
THESE COLOURS SHOW IF THE INSTRUCTIONS ARE
FOR REARWARD OR FORWARD FACING
BLUE is for rearward facing information
YELLOW is for forward facing information

Shoulder Height Label

READ THIS FIRST
This restraint has a shoulder height level label.
Use this label to decide if the restraint should be rear or forward facing or
if the child is too big for the restraint.
Once your child passes
dotted line C they are too
C
big for this restraint and
need to move to a Boost-
er Seat.
Once your child's shoul-
B
ders reach the dotted line
B the restraint must be
forward facing.
Once your child's shoul-
ders pass the dotted line
A
A they can be either
rearfacing or forward
facing.
If your child's shoulders
are below the bottom
dotted line A the restraint
must be rearfacing.
USE

Quick Reference - using restraint FORWARD FACING

1 2 3
INSTRUCTIONS
REAR FACING ONLY FORWARD FACING ONLY STORED AT REAR
OF SEAT
1 2 3 4 5
1. Recline restraint to 2. Place child in seat. 3. Child's shoulders must
one of the FORWARD be above lower dotted
FACING yellow numbers. line.
USE

Quick Reference - using restraint REAR FACING

1 2
3
1. Recline restraint to 2. Place child in seat. 3. Child must be placed
the REAR FACING rmly against both the
blue number.
back and bottom of the
seating surface.
6
7 8
"CLICK"
6. Harness buckle tongues 7. Straps must 8. Pull front harness
must be locked in place. not be twisted. strap tight.
4
5
Squeeze release
handle to adjust
headrest height
"CLICK"
5. Harness buckle tongues
4. Adjust headrest up or
must be locked in place.
down until shoulder straps
are above shoulders.
4 5
4. Child's shoulders must 5. Adjust headrest up or down until
be below middle dotted shoulder straps are just above shoulders.
line.
9 Check
NO
• Restraint is fully reclined.
GAP
• Child is correct size to be rear facing.
• Headrest and shoulder straps at correct height.
• Harness is latched securely.
GAP • No twists in straps.
• Harness is snug on child.
For complete instructions on how to use this
Pull to tighten
restraint refer to USE INSTRUCTIONS
straps
9. Check strap tension.
Put nger under strap
and pull out.
8
7
6
NO
GAP
Pull to tighten
straps
6. Straps must 7. Pull front harness 8. Check strap tension
not be twisted. strap tight. for one nger gap.
.
Check
• Restraint is correctly reclined.
• Child is correct size to be forward facing.
• Headrest and shoulder straps at correct height.
• Harness is latched securely.
• No twists in straps.
• Harness is snug on child.
For complete instructions on how to use this restraint
refer to USE INSTRUCTIONS
Squeeze release handle to
adjust headrest height.
Position bottom of headrest
just above shoulders.
GAP
