Furn Mill COLLAB Assembly Instruction

Bench

ASSEMBLY INSTRUCTION

COLLAB BENCH

COLLAB SHOE RACK

PRODUCT CODE: HOCHR00140

Requirement for Assembly

ASSEMBLY RATING

The Assembly Rating is a 5-point

system that shows the degree of effort

needed in assembling a specific

product (with 1 being easy and 5 being

difficult).

For most products, two

persons are recommended.

EASY

DIFFICULT

2 PERSONS RECOMMENDED

1/1

Table of Contents

Do you have a question about the COLLAB and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION COLLAB BENCH COLLAB SHOE RACK PRODUCT CODE: HOCHR00140 Requirement for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult).
Page 2 HARDWARE DETAIL ASSEMBLED PRODUCT HARDWARE QTY. M8x35mm Allen key No. 5...
Page 3 STEP 01 STEP01 Flip part A and Part B. Fix part A and part B with Allen bolt using Allen key as shown in fig. STEP02 Insert Part C in last Assemble part as shown in fig.
Page 4 Allen key STEP03 Allen Bolt Fix part c using Allen bolt at position B1,B2,B3 &B4 with the help of allen key as shown in fig. STEP04 Flip the Product. Your Shoe Rack is Ready...
Page 5 We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase. Your satisfaction is the greatest recognition we could have.
