10.1.4. Operation Procedures
1
Follow the NETYS RT UPS User Manual to execute input/ output connection.
2
Follow the battery installation procedure to connect the UPS and the Socomec
external battery pack(s).
3
Turn on every Socomec external battery pack's breaker and the UPS's input
breaker.
4
Follow the NETYS RT UPS User Manual to turn on the UPS.
10.1.5. Technical Specifications
Socomec External Battery Pack
Applicable to NETYS RT Series UPS
Battery
Dimensions (W × D × H)
Environment
Refer to the rating label for the safety rating.
All specifications are subject to change without prior notification.
70 EN
Type
Qantity
Weight
Operating Temperature
Relative Humidity
NRT3-B7000
7 kVA
VRLA
16 × 12V/7Ah
440 × 565 × 89 mm
(17.3" × 22.2" × 3.5")
39 kg (86 Ib)
0 ~ 40°C (32 ~ 104°F)
5 ~ 95% (non-condensing)
NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC
NRT3-B11000
11 kVA
20 × 12V/9Ah
440 × 650 × 131 mm
(17.3" × 25.6" × 5.1")
67 kg (147.7 Ib)
