- Page 1 MAXIMIZER BELT CONVEYOR SEED HANDLING SYSTEM 1310-001 OPERATOR’S MANUAL PART IDENTIFICATION YETTER MANUFACTURING CO. FOUNDED 1930 Colchester, IL 62326-0358 Toll free: 800/447-5777 309/776-3222 (Fax) Website: www.yetterco.com E-mail: info@yetterco.com...
-
Page 2: Safety Alert Symbol
Important will WARRANTY Yetter Manufacturing warrants all products manufactured and sold by it against defects in material. This warranty being expressly limited to replacement at the factory of such parts or products as shall appear to be defective after inspection. -
Page 3: Pre-Operating Check List
SAFETY which exist in the operation of the machine in accordance with OSHA regulations. WATCH FOR THIS SYMBOL. IT POINTS Safety Is No Acciden OUT IMPORTANT SAFETY PRECAUTIONS. IT MEANS “ATTENTION---BECOME ALERT!” The following safety instructions, combined with common sense, will save your equipment from YOUR SAFETY IS INVOLVED. -
Page 4: Maintenance
After extended use, the tender belt may stretch to the point that there is not sufficient take-up in the head assembly to tighten it. Obtain additional take-up by cutting a 6” to 8” section from the belt. A new splice lacing may be ordered from your dealer or from Yetter Mfg. Inc. PERIODIC CLEAN-OUT……………. -
Page 5: Operation
MAINTENANCE BELT SPLICING…….. A tender belt must not run out at the splice area. Run out will occur if the belt is not cut square or splice is not installed square. HYDRAULIC FLUID…….. Use high quality hydraulic oil. Fill oil to level with the upper hole/vent of the reservoir. OPERATION 1. - Page 6 Move the toggle switch to control the start and stop of the seed flow. CLEANOUT… Close the seed box gate before the seeding implement is full, so that the Maximizer belts are empty of seed before transporting. Run the conveyor until all the seed that is on the belts has been transferred.
- Page 7 BELT ASSEMBLY INSTRUCTIONS At the start point, see view of head and tail assembly. Feed a cable or rope through the head assembly down to the tail assembly. Now attach the belt to the rope/cable and use the rope/cable to pull the belt through the tube. Make sure the rough side is up and the smooth side is down against the inside wall of the tube.
-
Page 8: Troubleshooting
This is a list of many of the possible problems, causes and solutions to problems that you may encounter. If you have a problem that is not covered, please contact your dealer or Yetter Manufacturing Co. at 1-800-447-5777. Before you call, please have your operator’s manual and the model number of the machine. - Page 9 PARTS IDENTIFICATION...
- Page 10 PARTS IDENTIFICATION...
- Page 11 PARTS IDENTIFICATION...
- Page 12 PARTS IDENTIFICATION...
- Page 13 PARTS IDENTIFICATION...
- Page 14 PARTS IDENTIFICATION...
- Page 15 PARTS IDENTIFICATION...
- Page 16 PARTS IDENTIFICATION...
- Page 17 PARTS IDENTIFICATION...
- Page 18 PARTS IDENTIFICATION...
- Page 19 PARTS IDENTIFICATION...
- Page 20 PARTS IDENTIFICATION...
- Page 21 PARTS IDENTIFICATION...
- Page 22 PARTS IDENTIFICATION...
- Page 23 PARTS IDENTIFICATION...
- Page 24 PARTS IDENTIFICATION...
- Page 25 PARTS IDENTIFICATION...
- Page 26 PARTS IDENTIFICATION HYDRAULICS SHOWN ASSEMBLED TO MACHINE...
- Page 27 WIRING SCHEMATIC & ASSEMBLY 1310-434 WIRE HARNESS Each photo shown is actual location of the wiring harness hook up.
