- Page 1 Unit 5344 Cabin Equipment Operation Manual...
- Page 2 This manual is intended as an operational overview only. It is not intended to replace operation or maintenance instructions for any component or feature. Copyright © 2003 Cessna Aircraft Company, All Rights Reserved. 5344...
-
Page 3: Table Of Contents
Table of Contents Cabin Entertainment/Phone Equipment Page Cabin Equipment Location Diagram ..... . . Cabin Information Display ......Cabin Information Data Port Operation . - Page 4 Blank Page 5344...
-
Page 5: Cabin Entertainment/Phone Equipment Page
Cabin Entertainment/Phone Equipment Flight Phone (Voice Only) Fax / Data Panel Galley Cabin Information Forward Closet Data Port Cabin Information Display Flight Phone (Full Function) Fax / Data Panel Toilet Aft Closet Baggage Compartment 5344... -
Page 6: Cabin Information Display
Cabin Information Display This Cabin Display is an airborne data display system intended to provide a wide variety of flight information. It consists of (1) an SSW Model 90006 Processor Unit, (2) an SSW Model 15001 Display Unit and (3) an SSW Model 35012 Display Cable. -
Page 7: Aero-M Telephone
Aero-M Telephone The TT-3000 Aero-M Telephone System provides digital voice, fax and data transmission capabilities via SATCOM during flight. All normal Aero-M Telephone operations are performed using the system’s handset. The keypad is used to enter telephone phone numbers, menu selections or 2nd Functions, which are displayed on a backlit LCD screen. -
Page 8: Aero-M Voice Only Telephone
Aero-M Voice Only Telephone The TT-3000 Aero-M Voice only Telephone handset provides digital voice transmission capabilities via SATCOM during flight. The keypad is used to enter telephone phone numbers only. For detailed information and instructions for using the different services, refer to the Aero-M User Manual. Handset Features: Power LED (Green) Log On LED (Green) -
Page 9: Fax/Data Panel Operation
Fax/Data Panel Operation The cabin fax/data panels are used for either fax or data transmission. The panels utilize RJ-11 jacks for fax or a computer can be plugged into the 9-pin serial jacks. For detailed operation instructions, see the user manual of the type of equipment connected to the fax/data panel. - Page 10 Blank Page 5344...
-
Page 11: Cabin Switch Panels
Cabin Switch Panels Fax / Data Panel Forward Closet Master Control Switch Panel Side-Facing Couch Read Light Switch Panel Entry Light Switch Panel Read / Table Light Switch Panel Read / Table Light Switch Panel Read / Table Light Switch Panel Read / Table Light Switch Panel Fax / Data Panel... -
Page 12: Master Control Switch Panel
Master Control Switch Panel (Located in Galley Header) Press to Turn Lighting On/Off (Light Designates On) Press to Turn Vanity Hot Water Tank Heater On and Off Press to Turn Galley Hot Liquid (Light Designates On) Heater On/Off (Light Designates On) Side-Facing Couch Read / Read Light Switch Panel Press to Turn Read Light On, Press Again for Off... -
Page 13: Entry Light Switch Panel
Entry Light Switch Panel Press to Turn Cabin Lights On, Press Again for Dim Press Again for Off (Light Designates On) Press to Turn Entry Lights On, Press Again for Off (Light Designates On) Door Lock Indicator (Light Designates Locked) Vanity Switch Panel Press to Turn Cabin Lights On, Press Again for Off... - Page 14 Blank Page 5344...
-
Page 15: Furniture Location & Operation
Furniture Location & Operation 110V Outlet Hot Liquid Container Galley Forward Closet Side-Facing Couch Passenger Seat Passenger Seat Table Table Passenger Seat Passenger Seat 110V Outlet Table Table Passenger Seat 110V Outlet Side-Facing Seat Toilet (When Installed) Passenger Seat Aft Closet Hot Water Tank Baggage Compartment... -
Page 16: Seat Adjustment
Seat Adjustment Passenger seats have forward, aft and lateral adjustment with seat back recline. By pulling the armrest seat adjustment lever up, it is possible to adjust the seat position forward, aft, out from the wall or swivel to face any direction. Push lever down to recline the seat back. - Page 17 Table Operation Pull table inboard. Lift table up. Rotate table down until it is at rest in down position. Unfold table leaf. Reverse steps 1 through 4 to stow table. Note: Return table to its stowed position during takeoffs and landings. See Passenger Briefing Card for complete instructions.
-
Page 18: Galley
Galley Master Control Switch Hot Liquid Container Pull-Out Work Surface Ice Chest Manual Overboard Drain Operation (for Ice Chest) The ice-chest drawer located in the lower section of the galley is equipped with a manual drain valve used to empty water from the ice chest. To open drain valve: Turn drain valve counter-clockwise Open ice-chest drawer. -
Page 19: Hot Liquid Container Removal
Hot Liquid Container Removal A Prepco hot liquid container is located in the upper section of the galley. The hot liquid container holds one gallon and is easily removed for filling. The master control switch panel in the galley header controls the heater in the hot liquid container (see previous page for switch operation). -
Page 20: Manual Window Shade Operation
Manual Window Shade Operation Cabin Window Shades open and close by sliding the shade handle from right to left. (Left Hand Window Shown Only.) Vanity Sink Switch Panel Water Tank Vanity Switch Panel Note: Water will continue to run a few seconds after sink water switch is released. -
Page 21: Water Storage Tank Removal
Water Storage Tank Removal The water tank for the armrest sink is located inside the aft closet behind the top access panel on the sink side. This tank is easily removed for filling. Caution: Do NOT remove water tank when tank heater is turned on. To remove and fill water container: Open the upper access panel by pulling up on the latch and out on... -
Page 22: Aft Side-Facing Seat (Removable)
Aft Side-Facing Seat (Removable) Carefully pull out on fascia to release Ny-Latches. Fold down back cushion. Disengage plungers on inboard fittings. Track seat forward until aft seat fittings are in cutout of seat tracks. Lift and remove seat frame from aircraft. Caution: Take care to not scratch or nick... -
Page 23: Toilet
Toilet Press to Flush Toilet Note: The toilet is externally serviceable. Refer to the aircraft maintenance manual for instructions on service procedures. 5344... - Page 24 Blank Page 5344...
-
Page 25: Emergency Equipment
Emergency Equipment Fire Extinguisher (Under Copilot’s Seat) Protective Breathing Life Vest Equipment (Stored In Seat-Back Pocket) (Stored In Chart Case) Rechargeable Flashlight Rechargeable Flashlight (Mounted on chart case) (Mounted on chart case) Galley Forward Closet Cabin Entry/Exit Life Vest Life Vest (Stored Under Seat Shroud) (Stored Under Seat Shroud) Fire Extinguisher... -
Page 26: Brace Positions
Brace Positions Assume brace positions as shown below. FORWARD REAR Side-Facing Seat Rear-Facing Seat Forward-Facing Seat Emergency Exits The airplane has two exits with emergency exit releases and signs. To Open Emergency Exit Door: To Open Cabin Entry Door: Push button pull handle out from stow position and rotate counterclockwise to the open position. -
Page 27: Emergency Locator Transmitter
Emergency Locator Transmitter The emergency locator transmitter (ELT) unit is located in the aft tail cone equipment. The unit is self-contained and battery powered. An indicator light provides a visual indication of ELT operation. A switch mounted in the unit and a cockpit switch provides control of the ELT. -
Page 28: Life Vests
Life Vests Life vests are located in the base of each passenger seat for use in the event of an over-water emergency landing. (Refer to the life vest location placard for your seat.) A life vest is also located in the pocket on the back of the pilot and copilot seats. Instructions for use of the life vests are provided on a placard on each vest and on the passenger-briefing card located at each seat. -
Page 29: Seat Belts
Seat Belts It is recommended that seat belts Pull To remain fastened during flight. For Tighten comfort, the optional shoulder harness may be detached during flight. Note: Seat belts and shoulder harness must be fastened Push Button during takeoff and landings. To Release See Passenger Briefing Card for complete instructions.
