Pilot's Operating Handbook
FAA Approved Airplane Flight Manual
THIS PUBLICATION MUST BE
CARRIED IN THE AIRPLANE
AT ALL TIMES.
This publication includes the material required to be furnished to the pilot by FAR Part
23 and consttutes the FAA Approved Airplane Flight Manual.
FAA APPROVAL
MA APPAOIJE lMDER FAR 21 SUBPART J
The Ceuna AilCNlt Co
��--:::.:_
Date: 24 NcNember t999
.
i)
Member of GAMA
and
The Cessna Aircraft
Company
Model 172R
with 180 HP Engine
as Modified by MK172-72-01
Serial No.l 7 28 0 6 24
Registration No.N
COPYRIGHT e 1999
The Cessna Aircraft Company
Wichita, Kansa s USA
Original Issue - 24 November 1999
4 8 OE R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cessna 172R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Textron Cessna 172R

Summary of Contents for Textron Cessna 172R

  • Page 1 • Pilot's Operating Handbook FAA Approved Airplane Flight Manual The Cessna Aircraft Company THIS PUBLICATION MUST BE CARRIED IN THE AIRPLANE AT ALL TIMES. Model 172R with 180 HP Engine as Modified by MK172-72-01 Serial No.l 7 28 0 6 24 4 8 OE R Registration No.N This publication includes the material required to be furnished to the pilot by FAR Part...
  • Page 2 THIS MANUAL WAS PROVIDED FOR THE AIRPLANE IDENTIRED ON THE TITLE ..�: ..---,j .., PAGE ______ _ SUBSEQUENT REVISIONS SUPPLIED BY CESSNA AIRCRAFT COMPANY MUST BE PROPERLY INSERTED. 8�/ The Cessna Aircraft Company, Aircraft Division...
  • Page 3 REVISION MODEL 172R180HP PILOT'S OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL REVISION 2 4 OCTOBER 2001 172R180PHUSR02 INSERT THE FOLLOWING PAGES INTO THE PILOT'S OPERATING HANDBOOK...
  • Page 4 � ,..-..._...
  • Page 7 CESSNA PERFORMANCE­ MODEL 172A (180 HP) SPECIFICATIONS PERFORMANCE-SPECIFICATIONS (Continued) WING LOADING: Lbs/Sq Ft ......14.7 POWER LOADING Lbs/HP .
  • Page 8 CESSNA COVERAGE/REVISIONS MODEL 172R (180 HP) COVERAGE The Pilot's Operating Handbook in the airplane at the time of delivery from The Cessna Aircraft Company contains information applicable to the Model 172R (180 HP) airplane by serial number and registration number shown on the Title Page. This handbook is applicable to airplane serial number 172R (180 HP) 80001 and On.
  • Page 9 CESSNA COVERAGE/REVISIONS MODEL 172R (180 HP) It is the responsibility of the owner to maintain this handbook in current status when it is being used for operational purposes. wheneverl Owners should contact their local Cessna Service Station the revision status of their handbook is in question. Revisions are distributed to owners of U.S.
  • Page 10 CESSNA COVERAGE/REVISIONS MODEL 172R (180 HP) IDENTIFYING REVISED MATERIAL Additions or revisions to the text in an existing section will be identified by a vertical line (revision bar) adjacent to the applicable revised area on the outer margin of the page. When technical changes cause unchanged text to appear on a different page, a revision bar will be placed in the outer lower margin of the page, opposite the page number and date of the...
  • Page 11 LOG OF EFFECTIVE PAGES CESSNA MODEL 172R (180 HP) LOG OF EFFECTIVE PAGES The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the POH. Pages which are affected by the current revision will carry the date of that revision.
  • Page 12 LOG OF EFFECTIVE PAGES CESSNA MODEL 172R (180 HP) LOG OF EFFECTIVE PAGES (Continued) PAGE DATE PAGE DATE .... . 3-15 Oct 4/01 5-2 (Blank) Nov 24/99 ... .
  • Page 13 LOG OF EFFECTIVE PAGES CESSNA MODEL 172R (180 HP) LOG OF EFFECTIVE PAGES (Continued) PAGE DATE DATE PAGE ......6-22 Oct 4/01 Oct 4/01...
  • Page 14 LOG OF EFFECTIVE PAGES CESSNA MODEL 172R (180 HP) LOG OF EFFECTIVE PAGES (Continued) DATE PAGE 8-20 ... . . Oct 4/01 8-21 ..
  • Page 15 't""'" GENERAL...
  • Page 16 < c.:,...

  • Page 17: Table Of Contents

    CESSNA SECTION 1 MODEL 1 7 2R (180 HP) GENERAL SECTION 1 GENERAL TABLE OF CONTENTS Page Three View - Normal Ground Attitude Introduction ........Descriptive Data ........Engine ........Propeller ........Fuel .......................
  • Page 18 CESSNA SECTION 1 MODEL 172R (180 HP) GENERAL I ..,------- - -36'-1"----- -- -->- ======= �� �� r �{ -=== 76" MAX os,o, 05101 Figure 1-1. Three View - Normal Ground Attitude (Sheet 1 of 2) Nov 24/99...

  • Page 19: Three View - Normal Ground Attitude

    CESSNA SECTION 1 GENERAL MODEL 172R (180 HP} 27'-2"----• 8'-11" MAX. WING SPAN SHOWN WITH STROBE LIGHTS INSTALLED. NOTE 1: WHEEL BASE LENGTH IS 65". NOTE 2: PROPELLER GROUND CLEARANCE IS 11 1/4". NOTE 3: WING AREA IS 174 SQUARE FEET. NOTE 4: NOTE 5: MINIMUM TURNING RADIUS("...

  • Page 20: Descriptive Data

    DESCRIPTIVE DATA ENGINE Number of Engines: 1. Engine Manufacturer: Textron Lycoming. Engine Model Number: IO-360-L2A. Engine Type: Normally aspirated, direct drive, air-cooled, horizontally opposed, fuel injected, four cylinder engine with 360 cu. in. displacement.
  • Page 21 MIL-L-22851 or SAE J1899 Aviation Grade Ashless Dispersantl Oil: Oil conforming to Textron Lycoming Service Instruction No. 1014, and all revisions and supplements thereto, must be used after first 50 hours or once oil consumption has stabilized.

  • Page 22: Maximum Certificated Weights

    SECTION 1 CESSNA GENERAL MODEL 172R (180 HP) Recommended Viscosity for Temperature Range: Temperature MIL-L-22851 MIL-L-6082 Ashless Dispersant SAE Grade SAE Grade Above 27 ° C (80"F) 15W-50, 20W-50 or 60 Above 16 ° C (60 ° 40 or 50 -1 ·c (30"F) to 32•c (90 °...

  • Page 23: Standard Airplane Weights

    SECTION 1 CESSNA GENERAL MODEL 172R (180 HP) Weight in Baggage Compartment, Normal Category: Baggage Area 1 (Station 82 to 108): 120 lbs. See note below. Baggage Area 2 (Station 108 to 142): 50 lbs. See note below. NOTE The maximum combined weight capacity for Baggage Area 1 and Baggage Area 2 is 120 lbs.

  • Page 24: General Airspeed Terminology And Symbols

    SECTION 1 CESSNA GENERAL MODEL 172A (180 HP) SYMBOLS, ABBREVIATIONS AND TERMINOLOGY GENERAL AIRSPEED TERMINOLOGY AND SYMBOLS KCAS Knots Calibrated Airspeed is indicated airspeed corrected for position and instrument error and expressed in knots. Knots calibrated airspeed is equal to KT AS in standard atmosphere at sea level. KIAS Knots Indicated Airspeed is the speed shown on the airspeed indicator and expressed in knots.

  • Page 25: Meteorological Terminology

    CESSNA SECTION 1 MODEL 172R (180 HP) GENERAL Best Angle-of-Climb Speed is the speed which re­ sults in tfle greatest gam of altitude in a given hori­ zontal distance. Best Rate-of-Climb Speed is the speed which results in the greatest gain in altitude in a given time. METEOROLOGICAL TERMINOLOGY Outside Air Temperature is the free air static temperature.

  • Page 26: Airplane Performance And Flight Planning Terminology

    SECTION 1 CESSNA GENERAL MODEL 172R (180 HP) AIRPLANE PERFORMANCE AND FLIGHT PLANNING TERMINOLOGY Demonstrated Crosswind Velocity is the velocity Demon­ strated of the crosswind component for which adequate Crosswind control of the airplane during takeoff and landing Velocity was actually demonstrated during certification tests. The value shown is not considered to be limiting.

  • Page 27: Weight And Balance Terminology

    CESSNA SECTION 1 MODEL 172A (180 HP) GENERAL WEIGHT AND BALANCE TERMINOLOGY Reference Reference Datum is an imaginary vertical plane from ----.._ Datum which all horizontal distances are measured for balance purposes. Station Station is a location along the airplane fuselage given in terms of the distance from the reference datum.
  • Page 28 CESSNA SECTION 1 GENERAL MODEL 172R (180 HP) Maximum Maximum Ramp Weight is the maximum weight Ramp approved for ground maneuver, and includes the Weight weight of fuel used for start, taxi and runup. Maximum Maximum Takeoff Weight is the maximum weight Takeoff approved for the start of the takeoff roll.

  • Page 29: Metric Imperial/ U. S. Conversion Charts

    CESSNA SECTION 1 MODEL 172A (180 HP) GENERAL METRIC/ IMPERIAL/ U.S. CONVERSION CHARTS The following charts have been provided to help international operators convert U.S. measurement supplied with the Pilot's Operating Handbook into metric and imperial measurements. The standard followed for measurement units shown, is the National Institute of Standards Technology (NIST), Publication 811, "Guide for the Use of the International System of Units (SI)."...
  • Page 30 CESSNA SECTION 1 MODEL 172R (180 HP) GENERAL (Pounds .454 = Kilograms) (Kilograms x 2.205 = Pounds) KILOGRAMS INTO POUNDS KILOGRAMMES EN LIVRES 15.432 17.637 19.842 4.409 6.614 8.819 11.023 13.228 2.205 41.888 33.069 35.274 37.479 39.683 22.046 24.251 26.456 28.660 30.865 63.934...
  • Page 31 CESSNA SECTION 1 MODEL 172R (180 HP) GENERAL (Pounds x .454 = Kilograms) (Kilograms 2.205 = Pounds) POUNDS KILOGRAMS 220- . -- 10 0 Units 10, 100, etc. 0585T1027 Figure 1-2 . Weight Conversions (Sheet 2 of 2) Nov 24/99 1-15...
  • Page 32 SECTION 1 CESSNA GENERAL MODEL 172A (180 HP) (Meters x 3.281 = Feet) (Feet x .305 = Meters) METERS INTO FEET ..METERES EN PIEDS feet feet feet feet feet feet feet feet feet feet . . . 3.281 6.562 9.842 13.123 16.404...
  • Page 33 SECTION 1 CESSNA MODEL 172R (180 HP) GENERAL (Meters x 3.281 = Feet) (Feet x .305 = Meters) FEET METERS Units x 10, 100, etc. Figure 1-3 . Length Conversions (Sheet 2 of 2) Nov 24/99 1-17...
  • Page 34 SECTION 1 CESSNA GENERAL MODEL 172R (180 HP) (Centimeters x .394 = Inches) (Inches x 2.54 = Centimeters) CENTIMETERS INTO INCHES ..CENTIMETRES EN POUCES . . . 0.394 0.787 1.181 1.575 1.969 2.362 2.756 3.150 3.543 3.937 4.331 4.724 5.118 5.512 5.906...
  • Page 35 S ECTION 1 CESSNA GENERAL MODEL 172R (180 HP) (Centimeters x .394 = Inches) (Inches x 2.54 = Centimeters) INCHES CENTIMETERS 9 -�-23 5--, 4 -;__-10 2-�- 5 Units x 10, 100, etc. 0585T1028 11---'- - 0 Figure 1-4. Length Conversions (Sheet 2 of 2) Nov 24/99 1-19...

  • Page 36: Distance Conversions

    SECTION 1 CESSNA GENERAL MODEL 172A {180 HP) (Statute Miles x1 .609=Kilometers) (Kilometers x.622=Statute Miles) (Statute Miles x.869=Nautical Miles) (Nautical Miles x1 .15=Statute Miles) (Nautical Miles xl .852=Kilometers) (Kilometers x.54=Nautical Miles) NAUTICAL STATUTE MILES MILES KILOMETERS Units x 10, 100, etc. 0585T1029 Figure 1-5.
  • Page 37 SECTION 1 CESSNA GENERAL MODEL 172R (180 HP) (liters x = Imperial Gallons) (Imperial Gallons x 4.546 = Liters) LITERS INTO IMPERIAL GALLONS LITRES EN GALLONS IMPERIAL . . . 1.540 1.760 1.980 0.880 1.100 1.320 0.220 0.440 0.660 3.740 3.960 4.180 2.200...
  • Page 38 SECTION 1 CESSNA GENERAL MODEL 172R (180 HP) ..(Imperial Gallons x 4.4546 = Liters) (Liters x .22 = Imperial Gallons) IMPERIAL LITERS GALLONS Units x 1 100, etc. 0585T1032 Figure 1-6. Volume Conversions (Sheet 2 of 3) 1-22 Oct 4/01...
  • Page 39 CESSNA SECTION 1 MODEL 172R (180 HP) GENERAL (Imperial Gallons x 1.2 = U.S. Gallons) (U.S. Gallons x .833 = Imperial Gallons) (U.S. Gallons x 3.785 = Li_ t ers) (Liters x .264 = U.S. Gallons) U.S. IMPERIAL LITERS GALLONS GALLONS 100 1 OO Units x 10, 100, etc.

  • Page 40: Temperature Conversions

    CESSNA SECTION 1 MODEL 172R (180 HP) GENERAL TEMPERATURE CONVERSIONS ° C X 9/5 + 32 = ° F 1000 1020 0585T1034 Temperature Conversions Figure 1-7. Nov 24/99 1-24...
  • Page 41 SECTION 1 CESSNA GENERAL MODEL 172R (180 HP) AVGAS Specific Gravity (Kilograms X 1.389 Liters) (Liters X .72 Kilograms) (Pounds X .633 Liters) (Liters X 1.58 Pounds) LITERS POUNDS LITERS KILOGRAMS AVGAS FUEL Units x 10, 100, etc..__ ) 0585T1030 Figure 1-8.

  • Page 42: Quick Conversions

    CESSNA SECTION 1 GENERAL MODEL 172R (180 HP) AV GAS SPECIFIC GRAVITY 0.72 Figure 1-9. Quick Conversions Nov 24/99 1-26...
  • Page 43 :::!
  • Page 44 � :::i...
  • Page 45 CESSNA SECTION 2 MODEL 172R (180 HP) LIMITATIONS SECTION 2 LIMITATIONS TABLE OF CONTENTS Page Introduction ........2-3 Airspeed Limitations .

  • Page 47: Introduction

    CESSNA SECTION 2 MODEL 172R (180 HP) LIMITATIONS INTRODUCTION Section 2 includes operating limitations, instrument markings, and basic placards necessary for the safe operation of the airplane, its engine, standard systems and standard equipment. The limitations included in this section and in Section 9 have been approved by the Federal Aviation Administration.

  • Page 48: Airspeed Limitations

    SECTION 2 CESSNA LIMITATIONS MODEL 172A (180 HP) AIRSPEED LIMITATIONS Airspeed limitations and their operational significance are shown in Figure 2-1. Maneuvering speeds shown apply to normal category operations. The utility category maneuvering speed is 98 KIAS at 2200 pounds. SYMBOL KIAS REMARKS...

  • Page 49: Airspeed Indicator Markings

    Red Line Maximum speed for all operations. Figure 2-2. Airspeed Indicator Markings POWERPLANT LIMITATIONS Engine Manufacturer: Textron Lycoming. Engine Model Number: 1O-360-L2A. Maximum Power: 180 BHP rating. Engine Operating Limits for Takeoff and Continuous Operations: Maximum Engine Speed: 2700 RPM.
  • Page 50 MIL-L-6082 or SAE J1966 Aviation Grade Straight Mineral Oil or MIL-L-22851 or SAE J1899 Ashless Dispersant Oil: conforming to Textron Lycoming Service Instruction 1014, and all revisions and supplements thereto, must be used. Propeller Manufacturer: McCauley Propeller Systems. Propeller Model Number: 1A170E/JHA7660.

  • Page 51: Normal Category

    CESSNA SECTION 2 MODEL 172R (180 HP) LIMITATIONS WEIGHT LIMITS NORMAL CATEGORY Maximum Ramp Weight: 2558 lbs. Maximum Takeoff Weight: 2550 lbs. Maximum Landing Weight: 2550 lbs. Maximum Weight in Baggage Compartment: Baggage Area 1 - Station 82 to 108: 120 lbs. Baggage Area 2 - Station 108 to 142: 50 lbs.

  • Page 52: Maneuver Limits

    CESSNA SECTION 2 LIMITATIONS MODEL 172R (180 HP) UTILITY CATEGORY Center of Gravity Range: Forward: 35.0 inches aft of datum at 1950 lbs. or less, with straight line variation to 37.5 inches aft of datum at 2200 lbs. 40.5 inches aft of datum at all weights. Aft: Reference Datum: Lower portion of front face of firewall.
  • Page 53 CESSNA SECTION 2 MODEL 172R (180 HP) LIMITATIONS UTILITY CATEGORY This airplane is not designed for purely aerobatic flight. However, in the acquisition of various certificates sue� as commercial pilot and flight instructor, certain maneuvers are required by the FAA. All of these maneuvers are permitted in this airplane when operated in the utility category.

  • Page 54: Flight Load Factor Limits

    SECTION 2 CESSNA LIMITATIONS MODEL 172R (180 HP) FLIGHT LOAD FACTOR LIMITS NORMAL CATEGORY Flight Load Factors (Maximum Takeoff Weight - 2550 lbs.): *Flaps Up ..... . . + 3.8g, -1 .52g *Flaps Down .

  • Page 55: Fuel Limitations

    CESSNA SECTION 2 MODEL 172R (180 HP) LIMITATIONS FUEL LIMITATIONS Total Fuel: 56 U.S. gallons (2 tanks at 28.0 gallons each). Usable Fuel (all flight condi1ions): 53.0 U.S. gallons. Unusable Fuel: 3.0 U.S. gallons (1.5 gallons each tank). NOTE To ensure maximum fuel capacity and mm1m1ze cross­ feeding when refueling, always park the airplane in a wings­...

  • Page 56: Placards

    SECTION 2 CESSNA MODEL 172R (180 HP) LIMITATIONS PLACARDS The following information must be displayed in the form of composite or individual placards. 1. ln'full view of the pilot: (The "DAY-NIGHT-VFR-IFR" entry, - shown on the example below, will vary as the airplane is - equipped).
  • Page 57 SECTION 2 CESSNA LIMITATIONS MODEL 172R (180 HP) On the fuel selector valve: TAKEOFF BOTH ALL FLIGHT LANDING ATTITUDES 53.0 GAL. FUEL SELECTOR RIGHT LEFT 26.5 GAL. 26.5 GAL. LEVEL LEVEL FLIGHT FLIGHT ONLY ONLY Near fuel tank filler cap: FUEL 100LU100 MIN.
  • Page 58 SECTION 2 CESSNA LIMITATIONS MODEL 172R (180 HP) In baggage compartment: 120 POUNDS MAXIMUM BAGGAGE FORWARD OF BAGGAGE DOOR LATCH 50 POUNDS MAXIMUM BAGGAG E AFT OF BAGGAGE DOOR LATCH MAXIMUM 120 POUNDS COMBINED FOR ADDITIONAL LOADING INSTRUCTIONS SEE WEIGH T AND BALANCE DATA A calibration card must be provided to indicate the accuracy °...
  • Page 59 CESSNA SECTION 2 LIMITATIONS MODEL 172R (180 HP) O n the Upper Right Side of the Aft Cabin Partition: EMERGENCY LOCATOR TRANSMITTER INSTALLED AFT OF THIS PARTITION MUST BE SERVICED IN ACCORDANCE WITH FAR PART 91.207 On forward face of firewall adjacent to the battery: CAUTION 24 VOL TS D.C.
  • Page 63 CESSNA SECTION 3 EMERGENCY PROCEDURES MODEL 172R (180 HP) SECTION 3 EMERGENCY PROCEDURES TABLE OF CONTENTS Page Introduction AIRSPEEDS Airspeeds For Emergency Operation ....EMERGENCY PROCEDURES CHECKLIST Engine Failures ........
  • Page 64 SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172R (180 HP) TABLE OF CONTENTS (Continued) Page Electrical Power Supply System Malfunctions ... 3-11 Ammeter Shows Excessive Rate of Charge (Full Scale Deflection) ......3-11 Low Voltage Annunciator (VOL TS) Illuminates During Flight (Ammeter Indicates Discharge) .

  • Page 65: Introduction

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES INTRODUCTION Section 3 provides checklist and amplified procedures for coping with emergencies that may occur. Emergencies caused by airplane or engine malfunctions are extremely rare if proper preflight inspections and maintenance are practiced. Enroute weather emergencies can be minimized or eliminated by careful flight planning good judgment when unexpected weather is...

  • Page 66: Emergency Procedures Checklist

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES EMERGENCY PROCEDURES CHECKLIST Procedures in the Emergency Procedures Checklist portion of this section shown in bold faced type are immediate action items which should be committed to memory. ENGINE FAILURES ENGINE FAILURE DURING TAKEOFF ROLL 1.

  • Page 67: Forced Landings

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES NOTE If propeller is windmilling, engine will restart automatically within a few seconds. If propeller has stopped (possible at low speeds), turn ignition switch to START, advance throttle slowly from idle, and lean the mixture from full rich, as required, to obtain smooth operation.

  • Page 68: Ditching

    SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172R (180 HP) DITCHING 1. Radio -- TRANSMIT MAYDAY on 121.5 MHz, giving location and intentions and SQUAWK 7700. 2. Heavy Objects (in baggage area) - - SECURE OR JETTISON (if possible). 3. Passenger Seat Backs -- MOST UPRIGHT POSITION. 4.

  • Page 69: During Start On Ground

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES FIRES DURING START ON GROUND 1. Cranking - CONTINUE to get a start which would suck the flames and accumulated fuel into the engine. If engine starts: 2. Power -- 1800 RPM for a few minutes. 3.

  • Page 70: Electrical Fire In Flight

    SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172R (180 HP) ELECTRICAL FIRE IN FLIGHT 1. Master Switch -- OFF. 2. Vents, Cabin Air, Heat - CLOSED. 3. Fire Extinguisher - ACTIVATE (if available). 4. Avionics Master Switch -- OFF. 5. All Other Switches (except ignition switch) -- OFF. A wARNING AFTER DISCHARGING FIRE EXTINGUISHER AND ASCERTAINING...

  • Page 71: Icing

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES WING FIRE 1. Landingrraxi Light Switches -- OFF. 2. Navigation Light Switch - OFF. 3. Strobe Light Switch -- OFF. 4. Pltot Heat Switch -- OFF. NOTE Perform a sideslip to keep the flames away from the fuel tank and cabin.

  • Page 72: Landing With A Flat Main Tire

    SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172R (180 HP) 10. Approach at 65 to 75 KIAS depending upon the amount of the accumulation. 1 1. Perform a landing in level attitude. STATIC SOURCE BLOCKAGE (Erroneous Instrument Reading Suspected) 1. Static Pressure Alternate Source Valve -- PULL ON. 2.

  • Page 73: Electrical Power Supply System Malfunctions

    CESSNA SECTION 3 EMERGENCY PROCEDURES MODEL 172R (180 HP) ELECTRICAL POWER SUPPLY SYSTEM MALFUNCTIONS AMMETER SHOWS EXCESSIVE RATE OF CHARGE (Full Scale Deflection) 1. Alternator -- OFF. AcAUTION WITH THE ALTERNATOR SIDE OF THE MASTER SWITCH OFF, COMPASS DEVIATIONS OF AS MUCH AS 25 °...

  • Page 74: Vacuum System Failure

    SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172A (180 HP) llf low voltage annunciator (volts) illuminates again: 7. Alternator-- OFF. A cAunoN WITH THE ALTERNATOR SIDE OF THE MASTER SWITCH OFF, COMPASS DEVIATIONS OF AS MUCH AS 25 ° MAY OCCUR. 8.

  • Page 75: Amplified Emergency Procedures

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES AMPLIFIED EMERGENCY PROCEDURES The following Amplified Emergency Procedures elaborate upon information contained in the Emergency Procedures Checklists portion of this section. These procedures also include information not readily adaptable to a checklist format, and material to which a pilot could not be expected to refer in resolution of a specific emergency.
  • Page 76 CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES After an engine failure in flight, the most important course of action is to continue flying the airplane. Best glide speed (68 KIAS) should be established as quickly as possible. While gliding toward a suitable landing area, an effort should be made to identify the cause of the failure.

  • Page 77: Forced Landings

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES FORCED LANDINGS If all attempts to restart the engine fail and a forced landing is imminent, select a suitable field and prepare for the landing as discussed under the Emergency Landing Without Engine Power checklist.

  • Page 78: Emergency Operation In Clouds (Vacuum System Failure)

    SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172R (180 HP) At flare out, the nose down moment resulting from power reduction is an adverse factor and the airplane may hit on the nose wheel. Consequently, at flare out, the elevator trim control should be adjusted toward the full nose up position and the power adjusted so that the airplane will rotate to the horizontal attitude for touchdown.

  • Page 79: Emergency Descent Through Clouds

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES 3. Check accuracy of the turn by observing the compass heading which should be the recipr cal of the original heading. 4. If necessary, adjust heading primarily with skidding motions rather than rolling motions so that the compass will read more accurately.

  • Page 80: Inadvertent Flight Into Icing Conditions

    SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172A (180 HP) 3. Cautiously apply elevator back pressure to slowly reduce the airspeed to 80 KIAS. 4. Adjust the elevator trim control to maintain an 80 KIAS glide. 5. Keep hands off the control wheel, using rudder control to hold a straight heading.

  • Page 83: Electrical Power Supply System Malfunctions

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES If a total loss of oil pressure is accompanied by a rise in oil tem­ perature, there is good reason to suspect an engine failure is im­ minent. Reduce engine power immediately and select a suitable forced landing field.

  • Page 84: Insufficient Rate Of Charge

    CESSNA SECTION 3 MODEL 172R (180 HP) EMERGENCY PROCEDURES INSUFFICIENT RATE OF CHARGE NOTE Illumination of the low voltage (VOL TS) annunciator and ammeter discharge indications may occur during low RPM conditions with an electrical load on the system, such as during a low RPM taxi.
  • Page 85 .."" (")0 m::J:J ""· C:;i,,, "'...
  • Page 86 "' -'a: �5 .,...
  • Page 87 CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES SECTION 4 NORMAL PROCEDURES TABLE OF CONTENTS Page Introduction AIRSPEEDS ..... . Airspeeds For Normal Operation CHECKLIST PROCEDURES Preflight Inspection...
  • Page 88 CESSNA SECTION4 MODEL 172R (180 HP) NORMAL PROCEDURES TABLE OF CONTENTS (Continued) Page 4-16 Landing ........Normal Landing .
  • Page 89 CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES TABLE OF CONTENTS (Continued) Page Landing ........4-31 Normal Landing .
  • Page 92 CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES NOTE Visually check airplane for general condition during walk­ around inspection. Airplane should be parked in a normal ground attitude (refer to Figure 1-1) to ensure that fuel drain valves allow for accurate sampling. Use of the refueling steps and assist handles will simplify access to the upper wing surfaces for visual checks and refueling operations.

  • Page 93: Preflight Inspection

    CESSNA SECTION 4 MODEL 172R {180 HP) NORMAL PROCEDURES CHECKLIST PROCEDURES PREFLIGHT INSPECTION G)CABIN 1. Pitot Tube Cover --REMOVE. Check for pitot blockage. 2. Pilot's Operating Handbook --AVAILABLE IN THE AIRPLANE. 3. Airplane Weight and Balance -- CHECKED. 4. Parking Brake -- SET. 5.

  • Page 96: Nose

    SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172R (180 HP) 2. Engine Oil Dipstick/Filler Cap -- CHECK oil level, then check dipstick/filler cap SECURE. Do not operate with less than five quarts. Fill to eight quarts for extended flight. 3. Engine Cooling Air Inlets -- CLEAR of obstructions. 4.

  • Page 97: Left Wing Leading Edge

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES LEFT WING Leading Edge 1. Fuel Tank Vent Opening -- CHECK for blockage. 2. Stall Warning Opening -- CHECK for blockage. To check the system, place a clean handkerchief over the vent opening and apply suction;...

  • Page 98: Starting Engine (With Battery)

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES STARTING ENGINE (With Battery) 1. Throttle -- OPEN 1/4 INCH. 2. Mixture -- IDLE CUT OFF. 3. Propeller Area -- CLEAR. 4. Master Switch -- ON. 5. Auxiliary Fuel Pump Switch -- ON. �...

  • Page 100: Takeoff

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES 6. Flight Instruments -- CHECK and SET. 7. Fuel Quantity -- CHECK. 8. Mixture -- RICH. 9. Fijel Selector Valve -- RECHECK BOTH. 10. Throttle -- 1800 RPM. a. Magnetos -- CHECK (RPM drop should not exceed 150 RPM on either magneto or 50 RPM differential between magnetos).
  • Page 101 172R180PHUS NOTE: The accompanying (attached) FAA Approved Temporary Revision page(s) may or may not be applicable to your serial airplane. Please refer to the individual FAA Approved Temporary Revision page(s) to determine applicability status for your airplane. � 28 August 2014 172R180PHUS U.S.
  • Page 102 MODEL 172R 180HP NAV 1/NAV II TEMPORARY REVISIONS U.S. Pilot's Operating Handbook and FAA Approved Airplane Flight Manual Model 172R 180HP Nav I/ Nav II Airplanes 17280159 thru 17280707 incorporating MK172-72-01 THIS IS A LIST OF ALL CURRENT FAA APPROVED TEMPORARY REVISIONS.
  • Page 103 TEMPORARY REVISION FOR CESSNA PILOTS OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL Model 172R with 180HP Engine as Modified by MK172- Publication Affecied: 72-01, basic PIiot's Operating Handbook and FAA Approved Airplane Flight Manual, Revision 3, dated 23 August 2004.
  • Page 104 TEMPORARY REVISION FOR CESSNA PILOrs OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL BEFORE TAKEOFF Throttle Control - CHECK IDLE Throttle Control-1000 RPM or LESS 172R180PHUS-03 TR04...
  • Page 105 TEMPORARY REVISION FOR CESSNA PILOT'S OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL Model 172R with 180HP Engine as Modified by MK172- Publication Affected: 72-01, basic Pilot's Operating Handbook and FAA Approved Airplane Flight Manual, Revision dated 23 August 2004. Airplanes 17280159 thru...
  • Page 106 TEMPORARY REVISION FOR CESSNA PILOT'S OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL BEFORE TAKEOFF WARM UP If the engine idles smoothly with the throttle against the idle stop, (approximately 675 RPM) and accelerates smoothly, the engine is ready for takeoff. Since the engine is closely cowled for efficient in-flight engine cooling, the airplane should be pointed into the wind to avoid overheating during prolonged engine operation on the ground.

  • Page 107: Short Field Takeoff

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES SHORT FIELD TAKEOFF ° 1. Wing Flaps -- 10 2. Brakes -- APPLY. 3. Throttle -- FULL OPEN. 4. Mixture -- RI . C H (above 3000 feet, LEAN to obtain maximum RPM).

  • Page 108: Before Landing

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES BEFORE LANDING 1. Pilot and Passenger Seat Backs -- MOST UPRIGHT POSITION. 2. Seats and Seat Belts -- SECURED and LOCKED. 3. Fuel Selector Valve -- BOTH. 4. Mixture -- RICH. 5.

  • Page 109: After Landing

    CESSNA SECTION 4 MODEL 172A (180 HP) NORMAL PROCEDURES AFTER LANDING 1. Wing Flaps -- UP. SECURING AIRPLANE 1. Parking Brake -- SET. 2. Avionics Master Switch, Electrical Equipment, Autopilot (if installed) -- OFF. 3. Mixture -- IDLE CUT OFF (pulled full out). 4.

  • Page 110: Preflight Inspection

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES AMPLIFIED PROCEDURES PREFLIGHT INSPECTION The Preflight Inspection, described in Figure 4-1 and adjacent checklist, is required prior to each flight. If the airplane has been in extended storage, has had recent major maintenance, or has been operated from marginal airports, a more extensive exterior inspection is recommended.

  • Page 111: Starting Engine

    CESSNA SECTION 4 MODEL 172R (180 HP) PROCEDURES NORMAL If the airplane has been operated from muddy fields or in snow or slush, check the main and nose gear wheel fairings for obstructions and cleanliness. Operation from a gravel or cinder field will require extra attention to propeller lips and abrasion on leading edges of the horizontal tail.

  • Page 112: Taxiing

    SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172R (180 HP) Should the engine tend to die after starting, turn on the auxiliary fuel pump temporarily and adjust the throttle and/or mixture as necessary to keep the engine running. In the event of over priming or flooding, turn off the auxiliary fuel pump, open the throttle from 1/2 to full open, and continue cranking with the mixture full lean.

  • Page 114: Before Takeoff

    SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172R (180 HP) BEFORE TAKEOFF WARM UP If the engine idles (approximately 600 RPM) and accelerates smoothly, the airplane is ready for takeoff. Since the engine is closely cowled for efficient in-flight engine cooling, precautions should be taken to avoid overheating during prolonged engine operation on the ground.

  • Page 115: Landing Lights

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES LANDING LIGHTS If landing lights are to be used to enhance the visibility of the airplane in the traffic pattern or enroute, it is recommended that only the taxi light be used. This will extend the service life of the landing light appreciably.

  • Page 116: Wing Flap Settings

    SECTION 4 CESSNA MODEL 172R (180 HP) NORMAL PROCEDURES WING FLAP SETTINGS ° ° Normal takeoffs are accomplished with wing flaps 0 . Using ° wing flaps reduces the ground roll and total distance over an obstacle by approximately 1 o percent. Flap deflections greater than °...

  • Page 117: Cruise

    SECTION 4 CESSNA NORMAL MODEL 172R (180 HP) PROCEDURES CRUISE Normal cruise is performed between 45% and 75% rated power The engine RPM and corresponding fuel consumption for various altitudes can be determined by using the data in Section 5. NOTE Cruising should be done at 75% power as much as practicable until a total of 50 hours has accumulated or oil...

  • Page 118: Ileaning With An Egt Indicator

    SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172R (180 HP) 55% POWER 65% POWER 75%POWER ALTITUDE KTAS KTAS NMPG NMPG KTAS NMPG Sea Level 11.2 12.0 12.8 4000 feet 13.2 11.7 12.4 8000 feet 12.9 13.6 12.2 Standard Conditions, Zero Wind Figure 4-3.

  • Page 119: Fuel Savings Procedures For Flight Training Operations

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES FUEL SAVINGS PROCEDURES FLIGHT TRAINING OPERATIONS For best fuel economy during flight training operations, the following procedures are recommended. 1. After engine start and for all ground operations, set the throttle to 1200 RPM and lean the mixture for maximum RPM.

  • Page 120: Fuel Vapor Procedures

    SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172R (180 HP) FUEL VAPOR PROCEDURES The engine fuel system can become susceptible to fuel vapor formation on the ground during warm weather. This will generally loccur when the outside ambient air temperature is above 80 °...

  • Page 121: Spins

    Cessna 172R (180 HP). The cabin should be clean and all loose equipment (including the microphone and rear seat belts) should be stowed or secured.
  • Page 122 SECTION4 CESSNA NORMAL PROCEDURES MODEL 172R (180 HP) The normal entry is made from a power off stall. As the stall is approached, the elevator control should be smoothly pulled to the full aft position. Just prior to reaching the stall "break", rudder control in the desired direction of the spin rotation should be applied so that full rudder deflection is reached almost simultaneously with reaching full aft elevator.

  • Page 123: Landing

    CESSNA SECTION 4 MODEL 172A (180 HP) NORMAL PROCEDURES NOTE lf disorientation precludes a visual determination of the direction of rotation, the symbolic airplane in the turn coordinator may be referred to for this information. Variations in basic airplane rigging or in weight and balance due to installed equipment or right seat occupancy can cause differences in behavior, particularly in extended spins.

  • Page 124: Short Field Landing

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES SHORT FIELD LANDING For a short field landing in smooth air conditions, make an approach at 61 KIAS with 30 ° flaps using enough power to control the glide path. (Slightly higher approach speeds should be used under turbulent air conditions.) After all approach obstacles are cleared, progressively reduce power and maintain the approach speed by lowering the nose of the airplane.

  • Page 125: Cold Weather Operation

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES COLD WEATHER OPERATION Special consideration should be given to the operation of the airplane fuel system during the winter season or prior to any flight in cold temperatures. Proper preflight draining of the fuel system is especially important and will eliminate any free water accumulation.

  • Page 126: Winterization Kit

    SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172R (180 HP) When using an external power source, the master switch must be in the OFF position before connecting the external power source to the airplane receptacle. See Section 7, Ground Service Plug Receptacle for external power source operations.

  • Page 127: Hot Weather Operation

    CESSNA SECTION 4 MODEL 172R (180 HP) NORMAL PROCEDURES HOT WEATHER OPERATION Refer to the general warm temperature starting information under Starting Engine in this section. Avoid prolonged engine operation on the ground. NOISE CHARACTERISTICS AND NOISE REDUCTION The certificated noise level for the Model 172R (180 HP) at 2550 pounds maximum weight is 75.1 dB(A).
  • Page 128 ---...
  • Page 129 PER FO RM AN CE...
  • Page 130 ..
  • Page 131 CESSNA SECTION 5 MODEL 172R (180 HP) PERFORMANCE SECTION 5 PERFORMANCE TABLE OF CONTENTS Page Introduction ........5-3 Use of Performance Charts .

  • Page 133: Introduction

    SECTION 5 CESSNA MODEL 172R (180 HP) PERFORMANCE INTRODUCTION Performance data charts on the following pages are presented so that you may know what to expect from the airplane under various conditions, and also, to facilitate the planning of flights in detail and with reasonable accuracy.

  • Page 134: Takeoff

    SECTION 5 CESSNA PERFORMANCE MODEL 172R (180 HP) CRUISE CONDITIONS: Total distance 360 Nautical Miles Pressure altitude 7500 Feet ° ° Temperature C (16 C Above Standard) 10 Knot Headwind Expected wind enroute LANDING CONDITIONS: Field pressure altitude 2000 Feet °...

  • Page 136: Fuel Required

    SECTION 5 CESSNA PERFORMANCE MODEL 172R (180 HP) FUEL REQUIRED The total fuel requirement for the flight may be estimated using the performance information in Figure 5-7 and Figure 5-8. For this sample problem, Figure 5-7 shows that a climb from 2000 feet to 8000 feet requires 2.2 gallons of fuel.
  • Page 137 CESSNA SECTION 5 MODEL 172R (180 HP) PERFORMANCE The resultant cruise distance is: Total distance Climb distance Cruise distance 342 nm With an expected 10 knot headwind, the ground speed for cruise is predicted to be: 107 Knots Therefore, the time required for the cruise portion of the trip is: 342 Nau tica l Mi les = 3.2 Hou rs 107 Knots The fuel required for cruise is:...

  • Page 138: Demonstrated Operating Temperature

    SECTION 5 CESSNA MODEL 172R (180 HP) PERFORMANCE LANDING A procedure similar to takeoff should be used for estimating the landing distance at the destination airport. Figure 5-11 presents landing distance information for the short field technique. The ° distances corresponding to 2000 feet and 30 C are as follows: Ground roll 650 Feet...
  • Page 139 CESSNA SECTION 5 MODEL 172R (180 HP) PERFORMANCE AIRSPEED CALIBRATION NORMAL STATIC SOURCE CONDITION: Power required for level flight or maximum power descent. FLAPS KIAS 100 110 120 130 140 150 160 8 7 97 107 117 127 137 147 157 KCAS FLAPS 100 110 - - - -- - -- ----...
  • Page 140 CESSNA SECTION 5 MODEL 172R (180 HP) PERFORMANCE AIRSPEED CALIBRATION ALTERNATE STATIC SOURCE CONDITION: Power required for level flight or maximum power descent. FLAPS 100 110 120 130 140 150 160 KIA$ 105 115 125 134 144 154 KCAS 62 68 FLAPS °...
  • Page 142 CESSNA SECTION 5 MODEL 172R (180 HP) PERFORMANCE STALL SPEEDS AT 2550 POUNDS Conditions: Power Off MOST REARWARD CENTER OF GRAVITY ANGLE OF BANK FLAP ° ° ° SETTING KIAS KCAS KIAS KCAS KIAS KCAS KIAS KCAS ° ° MOST FORWARD CENTER OF GRAVITY ANGLE OF BANK FLAP °...
  • Page 143 CESSNA SECTION 5 PERFORMANCE MODEL 172R (180 HP) WIND COMPONENTS NOTE: Maximum demonstrated crosswind velocity is 15 knots (not a limitation). ;:� � 10 CROSSWIND COMPONENT - KNOTS 0585C1003 Figure 5-4. Crosswind Components 5-13 Oct 4/01...
  • Page 144 SECTION 5 CESSNA PERFORMANCE MODEL 172R (180 HP) SHORT FIELD TAKEOFF DISTANCE AT 2550 POUNDS CONDI T IONS: Flaps 10 ° Full Throttle Prior to Brake Release Paved, level, dry runway Zero Wind Lilt Off: KIAS Speed at 50 Ft: 56 KIAS °...
  • Page 145 CESSNA SECTION 5 MODEL 172R (180 HP) PERFORMANCE SHORT FIELD TAKEOFF DISTANCE AT 2400 POUNDS CONDITIONS: Flaps 10 ° Full Throttle Prior to Brake Release Paved, level, dry runway Zero Wind 48 KIAS Lift Off: Speed at 50 Ft: 54 KIAS °...
  • Page 146 �l::CTION 5 CESSNA PERFORMANCE MODEL 172R (180 HP) SHORT FIELD TAKEOFF DISTANCE AT 2200 POUNDS CONDITIONS: Flaps 10 ° Full Throttle Prior to Brake Release Paved, level, dry runway Zero Wind 44 KIAS Lift Off: Speed at 50 Ft: 50 KIAS °...
  • Page 147 SECTION 5 CESSNA PERFORMANCE MODEL 172R (180 HP) MAXIMUM RATE-OF-CLIMB AT 2550 POUNDS CONDITIONS: Flaps Up Full Throttle PRESS CLIMB RATE OF CLIMB - FPM SPEED ° ° ° ° KIA$ S.L. 2000 4000 6000 8000 10,000 - - - 12,000 NOTE: Mixture leaned above 3,000 feet for maximum RPM.
  • Page 148 SECTION 5 CESSNA PERFORMANCE MODEL 172R (180 HP) TIME, FUEL AND DISTANCE TO CLIMB AT 2550 POUNDS CONDITIONS: Flaps Up Full Throttle Standard Temperature FROM SEA LEVEL PRESS RATE CLIMB TIME FUEL SPEED DIST CLIMB USED KIAS S.L. 1000 2000 3000 4000 J .5...
  • Page 149 SECTION 5 CESSNA PERFORMANCE MODEL 172R (180 HP) CRUISE PERFORMANCE CONDITIONS: 2550 Pounds Recommended Lean Mixture At All Altitudes (Refer to Section 4, Cruise) STANDARD CABOVE 2o·c BELOW ° PRES! STANDARD TEMP STANDARD TEMP TEMPERATURE KTAS KTAS KTAS 2000 2550 11.1 10.5 2500...
  • Page 150 SECTION 5 CESSNA PERFORMANCE MODEL 172R (180 HP) CRUISE PERFORMANCE CONDITIONS: 2550 Pounds Recommended Lean Mixture At All Altitudes (Refer to Section 4, Cruise) ° ° c ABOVE c BELOW STANDARD PRES� STANDARD TEMP TEMPERATURE STANDARD TEMP KTAS KTAS KTAS 80 00 2700 11.1...
  • Page 151 CESSNA SECTION 5 MODEL 172R (180 HP) PERFORMANCE RANGE PROFILE 45 MINUTES RESERVE 53 GALLONS USABLE FUEL CONDITIONS: 2550 Pounds Recommended Lean Mixture for Cruise At All Altitudes Standard Temperature Zero Wind 12,000 10, 000 · � :t - · �i � : t i � 8,000 ·...
  • Page 153 CESSNA SECTION 5 MODEL 172R (180 HP) PERFORMANCE SHORT FIELD LANDING DISTANCE AT 2550 POUNDS � CONDITIONS: Flaps 30 ° Power Off Maximum Braking Paved, level, dry runway Zero Wind Speed at 50 Ft: 61 KIAS ° ° ° ° °...
  • Page 156 WEIGHT & BALANCE/ (n EQUIPMENT LIST...
  • Page 157 CESSNA SECTION 6 MODEL 172R (180 HP) WEIGHT & BALANCE/EQUIPMENT LIST SECTION 6 WEIGHT & BALANCE/ EQUIPMENT LIST TABLE OF CONTENTS Page Introduction ........6- 3 Airplane Weighing Procedures .

  • Page 159: Introduction

    CESSNA SECTION 6 MODEL 172R (180 HP) WEIGHT & BALANCE / EQUIPMENT LIST INTRODUCTION This section describes the procedure for establishing the basic empty weight and moment of the airplane. Sample forms are provided for reference. Procedures for calculating the weight and moment for various operations are also provided.
  • Page 160 SECTION 6 CESSNA WEIGHT & BALANCE/ EQUIPMENT LIST MODEL 172R (180 HP) AIRPLANE WEIGHING FORM REFERENCE DATUM (FIREWALL FRONT FACE, ,----NOTE --- -, LOWER PORTION) ST A 0.0 IT IS THE RESPONSIBILITY OF THE PILOT TO ENSURE THAT THE AIRPLANE IS LOADED PROPERLY.
  • Page 161 SECTION 6 CESSNA WEIGHT & BALANCE/ EQUIPMENT LIST MODEL 172R (180 HP) LOCATING CG WITH AIRPLANE ON LANDING GEAR FORMULA for Longitudinal CG: INCHES (NOSE GEAR NET WEIGHT) ( ) X (B) (A) · AFTOF ------------- = ( NOSE AND MAIN LANDING GEAR WEIGHT DATUM TOTALED( MEASURING A AND B...

  • Page 162: Weight And Balance

    SECTION 6 CESSNA WEIGHT & BALANCE/ EQUIPMENT LIST MODEL 172R (180 HP) 3. Weighing: a. Weigh airplane in a closed hangar to avoid errors caused by air currents. b. With the airplane level and brakes released, record the weight shown on each scale. Deduct the tare, if any, from each reading.
  • Page 163 S:() < SAMPLE WEIGHT AND BALANCE RECORD 0(/) m(I) � ..)> (CONTINUOUS HISTORY OF CHANGES IN STRUCTURE OR EQUIPMENT AFFECTING WEIGHT AND BA ANCE) --..J I\:) <.0" AIRPLANE MODEL I PAGE NUMBER lsERIAL No..RUNNING WEIGHT CHANGE !" ITEM NO.

  • Page 164: Baggage Tie-Down

    SECTION 6 CESSNA WEIGHT & BALANCE / EQUIPMENT LIST MODEL 172R (180 HP) NOTE Loading Graph information for the pilot, passengers and baggage is based on seats positioned for average occupants and baggage loaded in the center of the baggage areas as shown on the Loading Arrangements diagram.
  • Page 165 CESSNA SECTION 6 MODEL 172R (180 HP) WEIGHT & BALANCE/ EQUIPMENT LIST LOADING ARRANGEMENTS Pilot or passenger center of gravity on adjustable seats positioned for average occupant. Numbers in parentheses indicate forward and aft limits of occupant center of gravity range. * * Arm measured to the center of the areas shown.
  • Page 166 CESSNA SECTION 6 & MODEL 172R (180 HP) WEIGHT BALANCE/ EQUIPMENT LIST • CABIN HEIGHT MEASUREMENTS FIREWALL TIE - DOWN RINGS ;';. '// ; , - - - -3 4" AFT BAGGAGE AREA DOOR OPENING DIMENSIONS WIDTH WIDTH HEIGHT HEIGHl (TOP) (BOTTOM) (FRONT)
  • Page 167 CESSNA SECTION 6 MODEL 172A (180 HP} WEIGHT & BALANCE/ EQUIPMENT LIST CABIN WIDTH MEASUREMENTS INSTRUMENT PANEL REAR DOORPOST BULKHEAD ------,- 4'o sb 60 I 10 so so 100 11 o 120 1 so 140 1 b 2h CABIN 65.3 STATIONS (C.G.
  • Page 168 SECTION 6 CESSNA MODEL 172R (180 HP) WEIGHT & BALANCE / EQUIPMENT LIST WEIGHT AND MOMENT TABULATION SAMPLE YOUR ITEM DESCRIPTION AIRPLANE AIRPLANE Moment Moment Weight Weight (Lb-ins. (Lb-ins. (lbs.) (lbs.) /1000) /1000) 1 . Basic Empty Weight (Use data pertaining your airplane as it is...
  • Page 169 172R180PHUS NOTE: The accompanying (attached) FAA Approved Temporary Revision page(s) may or may not be applicable to your serial airplane. Please refer to the individual FAA Approved Temporary Revision page(s) to determine applicability status for your airplane...
  • Page 170 TEMPORARY REVISIONS MODEL 172R 180HP NAV 1/NAV II U.S. Pilot's Operating Handbook and FAA Approved Airplane Flight Manual Model 172R 180HP Nav I/ Nav II Airplanes 17280159 thru 17280707 incorporating MK172-72-01 THIS IS A LIST OF ALL CURRENT FAA APPROVED TEMPORARY REVISIONS. The following list of temporary revisions must be incorporated into this basic U.S.
  • Page 171 TEMPORARY REVISION FOR CESSNA PILOT'S OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL Publication Aff e cted: Model 172R with 180HP Engine as Modified by MK172-72- 01. bas'c Pilot's Operating Handbook and FAA Approved Airplane Flight Manual, Revision dated 23 August 2004. Airplane Serial Numbers Affected: Airplanes 17280159 lhru 17280707 incorporating MK172-...
  • Page 172 TEMPORARY REVISION FOR CESSNA PILOT'S OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL This Page Intentionally Left Blank 172R180PHUS-03 TR03...
  • Page 173 TEMPORARY REVISION FOR CESSNA PILOT'S OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL CENTER OF GRAVITY MOMENT ENVELOPE Loaded Airplane MomenV1000 (Kilogram - Millimeters) 600 700 800 900 1000 1100 1200 1300 1400 1500 2600t-'-r--r--.,..,__,_._ ..,....-.-_...___,..,� 1150 1600 1500 110 120...
  • Page 174 TEMPORARY REVISION FOR CESSNA PILOT'S OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL CENTER OF GRAVITY LIMITS Airplane C.G. Location - Millimeters Aft of Datum (FS 0.0) 1025 1075 1125 1175 1225 1000 1050 1100 1150 1200 1150 1100 2400 1050 2300 2200...
  • Page 175 CESSNA SECTION 6 MODEL 172R (180 HP) WEIGHT & BALANCE/ EQUIPMENT LIST YOUR YOUR YOUR AIRPLANE AIRPLANE AIRPLANE Moment Moment Moment Weight Weight Weight (Lb-ins. (Lb-ins. (Lb-ins. (lbs.) (lbs.) (lbs.) /1000) /1000) /1000) NOTE When several loading configurations are representative of your operations, it may be useful to fill ou t one or more of the above columns so specific loadings are available at a glance.
  • Page 176 SECTION 6 CESSNA WEIGHT & BALANCE/ EQUIPMENT LIST MODEL 172R (180 HP) LOAD MOMENT/1000 (KILOGRAM - MILLIMETERS) 100 150 200 250 300 350 400 -300 ---- :::t iii 250 � · · · · ' · ~ '. � f :: : = Lg:�...
  • Page 177 CESSNA SECTION 6 MODEL 172R (180 HP) WEIGHT & BALANCE/ EQUIPMENT LIST LOAOEO AJAPLANE MOMENT/1 0 00 (KILOGRAM· MILLIMETEAS) 1000 1100 1200 1300 1400 1500 2600 . Lt 1100 2500 1050 1000 � �2200 £12100 �2000 �1900 1800 1700 1600 ••...
  • Page 178 CESSNA SECTION 6 MODEL 172R (180 HP) WEIGHT & BALANCE EQUIPMENT LIST AIRPLANE C.G. LOCATION - MILLIMETI:RS AFT OF DATUM (STA. 0.0) 9 75 9 25 1025 1075 1125 1175 1225 120 0 9 50 100 0 110 0 115 0 9 00 105 0 '1111 1 I 111 I , , ,...

  • Page 179: Comprehensive Equipment List

    CESSNA SECTION 6 MODEL 172A (180 HP) WEIGHT & BALANCE/ EQUIPMENT LIST COMPREHENSIVE EQUIPMENT LIST The following figure (Figure 6-9) is a comprehensive list of all Cessna equipment 172A (180 which is available for the Model HP) airplane. This comprehensive equipment list provides the following information in column form: In the ITEM No.
  • Page 180 SECTION 6 CESSNA WEIGHT & BALANCE/ EQUIPMENT LIST MODEL 172A (180 HP) ITEM EQUIPMENT L. I ST DESCRIPTION REF DRAWING No . INS. 11 • PLACARDS AND MARKINGS 11·01 ·R IFR DAY & NIGHT LIMITATIONS PLACARD 0505087·3 43.0 11·02-S PAINT, OVERALL EXTERIOR 0504051 95.4' 19.2'...
  • Page 183 CESSNA SECTION 6 MODEL 172A (180 HP) WEIGHT & BALANCE/ EQUIPMENT LIST ITEM EQUIPMENT LIST DESCRIPTION REF DRAWING INS. 28 • FUEL 28-01-R FUEL QUANTITY INDICATORS, LEFT & RIGHT S3281-1 14.4 28-02-R 5100- 00-1 AUXILIARY FUEL PUMP 31 - INDICATING/RECORDING SYSTEM 31-01-S CLOCK/OAT INDICATOR, DIGITAL M803B·2-0...
  • Page 184 SECTION 6 CESSNA WEIGHT & BALANCE / EQUIPMENT LIST MODEL 172R (180 HP) ITEM REF DRAWING EQUIPMENT LIST DESCRIPTION INS. 34-06-R COMPASS INSTL. MAGNETIC �513262-2 14.0 34-07-S 6.0' 13.0' GYRO, INSTALLATION (REQUIRES 37·01·S) p501135.1 - DIRECTIONAL GYRO S3330·1 14.0 • AL TITUOE GYRO 14.0 S3226-1 •...
  • Page 185 SECTION 6 CESSNA WEIGHT & BALANCE/ EQUIPMENT LIST MODEL 172R (180 HP) ITEM EQUIPMENT LIST DESCRIPTION REF DRAWING INS. 14.3 53280·1 37·02·R VACUUM/AMMETER INDICATOR 16.0 37·03-S LOW VACUUM WARNING LIGHT, VACUUM �50600 8·1 PUMP 53 • FUSELAGE 0513415• 2 16.3 53-01-S REFUELING STEPS AND HANDLE INSTL 56-WINDOWS...
  • Page 186 SECTION 6 CESSNA WEIGHT & BALANCE/ EQUIPMENT LIST MODEL 172R (180 HP) rTEM EQUIPMENT LIST DESCRIPTION REF DRAWING INS. 78-EXHAUST 78-01-R EXHAUST SYSTEM INSTALLATION 9954100·10 16.3. -20.0· -22.7 • MUFFLER & TAILPIPE WELD ASSY 9954100-9 • SHROUD ASSY, MUFFLER HEATER 9954100-3 ·22.7 79 ·...
  • Page 187 � AIRPLANE & SYSTEMS DESCRIPTIONS...
  • Page 188 AIRLANE & SYSTEMS .., DESCRIPTIONS...
  • Page 189 CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION SECTION 7 AIRPLANE & SYSTEMS DESCRIPTION TABLE OF CONTENTS Page Introduction ........Airframe .
  • Page 190 SECTION 7 CESSNA MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION TABLE OF CONTENTS (Continued) Page Air Induction System ......7-22 Exhaust System ....... 7-23 Fuel Injection System ......7-23 Cooling System ....... . 7-23 Propeller ........7-23 Fuel System ........
  • Page 191 SECTION 7 CESSN A MODEL 172R (180 HP) AIRPL ANE & SYSTEMS DESCRIPTION TABLE OF CONTENTS (Continued) Page Pitot-Static System And Instruments ....7-42 7-42 Airspeed Indicator ......7-43 Vertical Speed Indicator ......Altimeter ........7-43 7-43 ....

  • Page 193: Introduction

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION INTRODUCTION This section provides description and operation of the airplane and its systems. Some equipment described herein is optional and may not be installed in the airplane. Refer to the Supplements, , Section 9, for details of other optional systems and equipment.

  • Page 194: Flight Controls

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION The empennage (tail assembly) consists of a conventional verti­ cal stabilizer, rudder, horizontal stabilizer, and elevator. The vertical stabilizer consists of a spar, formed sheet metal ribs and reinforce­ ments, a wraparound skin panel, formed leading edge skin and a dorsal.
  • Page 195 CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION AILERON CONTROL SYSTEM RUDDER CONTROL SYSTEM 0585X1017 Figure 7-1. Flight Control and Trim Systems (Sheet 1 of 2) Nov 24/99...
  • Page 196 SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) ELEVATOR TRIM CONTROL SYSTEM 0585X1018 Figure 7-1. Flight Control and Trim Systems (Sheet 2 of 2) Nov 24/99 7- 8...

  • Page 197: Instrument Panel

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION INSTRUMENT PANEL The instrument panel (Refer to Figure 7-2) is of all-metal construction, and is designed in segments to allow related groups of instruments, switches and controls to be removed without removing the entire panel.
  • Page 198 SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) 0585C1040 Figure 7-2. Instrument Panel (Sheet 1 of 2) 7-10 Nov 24/99...
  • Page 199 CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION Oil Temperature and Oil Transponder ..Pressure Indicator -..Vacuum Gauge/Ammeter EL T Remote Test Button 22 . Hour Meter Fuel Quantity Indicator EGT/Fuel Flow Indicator -.. Glove Box Digital Clock / O.A.T.

  • Page 200: Copilot Side Panel Layout

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R {180 HP) COPILOT SIDE PANEL LAYOUT The copilot sub panel contains the hour meter, ELT switch, and room for expansion of indicators and other avionics equipment. Below this sub panel are the glove box, cabin heat and cabin air controls, and wing flap switch.

  • Page 201: Wing Flap System

    SECTION 7 CESSNA MODEL 172R (180 HP ) AIRPLANE & SYSTEMS DESCRIPTION WING FLAP SYSTEM The single-slot type wing flaps ( Refer to Figure 7-3 ) , are extended or retracted by positioning the wing flap switch lever on the instrument panel to the desired flap deflection position. The switch lever is moved up or down in a slotted panel that provides ) positions.

  • Page 202: Landing Gear System

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) LANDING GEAR SYSTEM The landing gear is of the tricycle type, with a steerable nose wheel and two main wheels. Wheel fairings are standard equipment for both the main and nose wheels. Shock absorption is provided by the tubular spring steel main landing gear struts and the air/oil nose gear shock strut.
  • Page 204 SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) STANDARD INTEGEATED SEATBELT/ SHOULDER HARNESS WITH INTERTIA REEL VERTICAL (HEIGHT} ADJUSTMENT CRANK SEAT BACK ANGLE BUTTON ..,...- - - - -�� -_ Ao � FORE AND AFT BUCKLE ADJUSTMENT PRESS TO (NON ADJUSTABLE} LEVER...

  • Page 205: Entrance Doors And Cabin Windows

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION A manually adjustable seat belt/shoulder harness assembly is available for all seats. To use the manually adjustable seat belt/shoulder harness, fasten and adjust the seat belt/shoulder harness first. Lengthen the seat belt as required by pulling on the release strap on the belt.

  • Page 206: Control Locks

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) NOTE Accidental opening of the cabin door in flight due to im­ proper closing does not constitute a need to land the air­ plane. The best procedure is to ·set up the airplane in a trimmed condition at approximately 75 KIAS, momentarily shove the door outward slightly, and forcefully close and lock the door.

  • Page 207: Engine

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION ENGINE The airplane is powered by a horizontally opposed, four cylinder, overhead valve, air cooled, fuel injected engine with a wet sump lubrication system. The engine is a Lycoming Model IO-360-L2A and is rated at 180 horsepower at 2700 RPM.
  • Page 208 SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) Markings for the oil temperature indicator indicate a normal op­ ° erating range of 100 to 245 F (green arc), and a maximum tem­ ° perature of 245 F (red line). Oil pressure signals are generated from an oil pressure line/transducer combination.

  • Page 209: New Engine Break-In And Operation

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION An exhaust gas temperature (EGT) indicator is located on the left instrument panel as part of the EGT/Fuel Flow indicator. Al thermocouple probe the tailpipe measures exhaust temperature and transmits it to the indicator. The indicator serves as a visual aid to help the pilot adjust mixture through monitoring of exhaust gas temperature.

  • Page 211: Fuel Injection System

    SECTION 7 CESSNA MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION EXHAUST SYSTEM Exhaust gas from each cylinder passes through riser assemblies to a muffler and tailpipe. Outside air is pulled in around shrouds which are constructed around the outside of the muffler to form heating chambers which supply heat to the cabin.
  • Page 212 SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) &WARNING UNUSABLE FUEL LEVELS FOR THIS AIRPLANE WERE DETERMINED IN ACCORDANCE WITH FEDERAL AVIATION REGULATIONS. FAILURE TO OPERATE THE AIRPLANE IN COMPLIANCE WITH FUEL LIMITATIONS SPECIFIED SECTION FURTHER REDUCE AMOUNT OF FUEL AVAILABLE IN FLIGHT.

  • Page 214: Fuel Venting

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION FUEL VENTING Fuel system venting is essential to system operation. Blockage of the system will result in decreasing fuel flow and eventual engine stoppage. Venting is accomplished by an interconnecting line from the right fuel tank to the left tank.
  • Page 215 CESSNA SECTION 7 MODEL 172A (180 HP) AIRPLANE & SYSTEMS DESCRIPTION FUEL QUANTITY INDICATORS FUEL QUANTITY TRANSMITTER LEFT FUEL TANK VENT (WITH CHECK VALVE) DRAIN VALVES (5 TOTAL) FUEL RESERVOIR TANK DRAIN FUEL SHUTOFF- VALVE KNOB FUEL STRAINER LEGEND FUEL SUPPLY VENT MECHANICAL LINKAGE...
  • Page 216 SECTION 7 CESSNA MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION NOTE When the fuel tanks are 1/4 full or less, prolonged uncoordinated flight such as slips or skids can uncover the fuel tank outlets. Therefore, if operating with one fuel tank dry or if operating on LEFT or RIGHT tank when 1/4 full or less, do not allow the airplane to remain in uncoordinated flight for periods in excess of 30 seconds.

  • Page 217: Brake System

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION BRAKE SYSTEM The airplane has a single-disc, hydraulically actuated brake onl each main landing gear wheel. Each brake is connected, by a hydraulic line, to a master cylinder attached to each of the pilot's rudder pedals.
  • Page 218 SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) r---------- ANNUNCIATO LOW VOLT ---Fl� GROUND I --------. Ei--------. POWE INI------� ALT INPUT ALTE NATO 1 ., , ::.: :.:..:: .::.; O::.:. c - -- -r--- CUIT EAKER ITIO I SWITCH --,,r m _ - - MAGN...
  • Page 219 CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION � Q)- TO HSI & GYRO (5) GYRO Q)--INSTR UMENTS ,..Ci\-- AND IGNITION 'Iii TO AUTO-PILOT(4,5) SWITCH (/) AUTO ""' PILOT � ���?> <.I) (,.-To FUEL PUMP <.I) Q)-To TRANSPONDER U XPOND ;J_ '3--To LANDING �...

  • Page 220: Annunciator Panel

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) The airplane uses a power distribution module (J-Box), located on the left forward side of the firewall, to house all relays used throughout the airplane electrical system. In addition, the alternator control unit and the external power connector are housed within the module.

  • Page 221: Master Switch

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) MASTER SWITCH The master switch is a split rocker-type switch labeled MASTER.I and is ON in the up position and off in the down position. The right half of the switch, labeled BAT, controls the battery power to the airplane.

  • Page 222: Avionics Master Switch

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) AVIONICS MASTER SWITCH Electrical power tor Avionics Bus 1 and Avionics Bus 2 is supplied through Primary Bus 2 and Primary Bus 1, respectively. A rocker switch, located between the primary and avionics buses, controls current flow to the avionics buses.

  • Page 223: Low Voltage Annunciation

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION LOW VOLTAGE ANNUNCIATION The low voltage warning annunciator is incorporated in annunciator panel and activates anytime voltage falls below 24.5 the l volts. If low voltage is detected, the red annunciation VOLTS will flash for approximately 10 seconds before illuminating steadily.

  • Page 224: Ground Service Plug Receptacle

    SECTION 7 CESSNA MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION GROUND SERVICE PLUG RECEPTACLE A ground service receptacle plug is integral to the power distribution module and allows the use of an external power source for cold weather starting, and during lengthy maintenance work on electrical and avionics equipment.

  • Page 225: Lighting Systems

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION NOTE Just before connecting an external power source (generator type or battery cart), the avionics master switch and the master switch should be turned OFF. If there is any question as to the condition of the battery, the following check should be made after engine has been started and external power source has been removed.

  • Page 226: Interior Lighting

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) The exterior courtesy lights (and the rear cabin dome light) are turned on by pressing the rear cabin light switch. Pressing the rear cabin light switch again will extinguish the three lights. The remaining exterior lights are operated by breaker/switches located on the lower left instrument panel.
  • Page 227 CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION Pedestal lighting consists of a single, hooded light located above the fuel selector.This light is controlled by rotating the PEDESTAL LT dimmer, located below the nav indicators. Rotating the dimmer clockwise increases light intensity, and rotating the dimmer counterclockwise decreases light intensity.

  • Page 228: Cabin Heating, Ventilating And Defrosting System

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP} CABIN HEATING, VENTILATING AND DEFROSTING SYSTEM The temperature and volume of airflow into the cabin can be regulated by manipulation of the push-pull CABIN HT and CABIN IAIR controls (Refer to Figure 7-8). Both controls are the double­ button locking type and permit intermediate settings.
  • Page 229 CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION EXHAUST RAM AIR HEATER MUFFLER VALVE SHROUD CABIN HEAT CONTROL DEFROSTER VENTILATING OUTLETS (2) AIR DOOR FORWARD CABIN FORWARD LOWER CABIN VENTILATING LOWER AIR OUTLET VENTILATING AIR OUTLET CABIN FLOOR AIR OUTLET REAR CABIN VENTILATING...

  • Page 230: Pitot-Static System And Instruments

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) PITOT-STATIC SYSTEM AND INSTRUMENTS The pitot-static system supplies ram air pressure to the airspeed indicator and static pressure to the airspeed indicator, vertical speed indicator and altimeter. The system is composed of a heated pilot tube mounted on the lower surface of the left wing, an external static port on the lower left side of the forward fuselage, and the associated plumbing necessary to connect the instruments to the...

  • Page 231: Vertical Speed Indicator

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION Limitation and range markings (in KIAS) include the white arc (40 to 85 knots), green arc (48 to 129 knots), yellow arc (129 to 163 knots), and a red line (163 knots). To find true airspeed, first determine pressure altitude and outside air temperature.

  • Page 232: Directional Indicator

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) ATTITUDE INDICATOR The attitude indicator is a vacuum/air-driven gyro that gives a visual indication of flight attitude. Bank attitude is presented by a pointer at the top of the indicator relative to the bank scale which has index marks at 10 , 20 , 30...
  • Page 233 CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION OVERBOARD VENT LINES CODE INLET AIR LOW VACUUM VACUUM SWITCHES (CONNECTED TO DISCHARGE ANNUNCIATOR PANEL) MANIFOLD VACUUM SYSTEM CHECK VALVE AIR FILTER L=;:----l -lt-----"Wli..,...� ' VACUUM GAUGE/ AMMETER DIRECTIONAL INDICATOR 0585C1014 Figure 7-9.

  • Page 234: Low Vacuum Annunciation

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R {180 HP) LOW VACUUM ANNUNCIATION Each engine-driven vacuum pump is plumbed to a common manifold, located forward of the firewall. From the tee, a single line runs into the cabin to operate the various vacuum system instruments.

  • Page 235: Standard Avionics

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION STANDARD AVIONICS Standard avionics for the Model 172R (180 HP) airplanes include the following equipment: Nav/Com Radio with Kl 208 or Kl 209A lndicato Head Transponder Audio Panel Emergency Locator Transmitter (EL T) For complete operating instructions on the standard and optional avionics systems, refer to the Supplements, Section 9.

  • Page 236: Static Dischargers

    SECTION 7 CESSNA AIRPLANE & SYSTEMS DESCRIPTION MODEL 172R (180 HP) The overhead speaker is located in the center overhead console. Volume and output for this speaker is controlled through the audio panel. Each control wheel contains a miniature push-to-talk switch. This switch allows the pilot or front passenger to transmit on the Com radios using remote mies.

  • Page 237: Cabin Features

    CESSNA SECTION 7 MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION CABIN FEATURES EMERGENCY LOCATOR TRANSMITTER (ELT) A remote switch/annunciator is installed on the top center location of the copilot's instrument panel for control of the EL T from the flight crew station. The annunciator, which is in the center of the rocker switch, illuminates when the EL T transmitter is transmitting.
  • Page 238 SECTION 7 CESSNA MODEL 172R (180 HP) AIRPLANE & SYSTEMS DESCRIPTION WARNING VENTILATE THE CABIN PROMPTLY AFTER SUC­ CESSFULLY EXTINGUISHING THE FIRE TO RE• DUCE THE GASES PRODUCED BY THERMAL DECOMPOSITION. 3. Anticipate approximately eight seconds of discharge dura­ tion. Fire extinguishers should be recharged by a qualified fire extin­...
  • Page 239 HANDLING SERVICE & MAINTtNANCE...
  • Page 240 '---\...
  • Page 241 CESSNA SECTIONS MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE SECTION 8 AIRPLANE HANDLING, SERVICE & MAINTENANCE TABLE OF CONTENTS Page Introduction ........Identification Plate .
  • Page 242 SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) TABLE OF CONTENTS (Continued) Page Capacity of Engine Sump ......8-15 Oil and Oil Filter Change .

  • Page 243: Introduction

    CESSNA SECTION 8 MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE INTRODUCTION This section contains factory recommended procedures for proper ground handling and routine care and servicing of your airplane. It also identifies certain inspection and maintenancel requirements which must be followed if your airplane is to retain that new airplane performance and dependability.

  • Page 244: Identification Plate

    SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) IDENTIFICATION PLATE All correspondence regarding your airplane should include the Serial Number. The Serial Number, Model Number, Production Certificate Number (PC) and Type Certificate Number (TC) can be found on the Identification Plate, located on the aft left tailcone. A lsecondary Identification Plate is also installed on the lower part of the left forward doorpost.

  • Page 245: United States Airplane Owners

    CESSNA SECTION 8 MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE UNITED STATES AIRPLANE OWNERS If your airplane is registered in the U. S., appropriate Cessna Owner Advisories will be mailed to you automatically according to the latest aircraft registration name and address which you have provided to the FAA.

  • Page 246: Airplane File

    SECTIONS CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172A (180 HP) The following additional publications, plus many other supplies lthat are applicable to your airplane, are available from your local Cessna Service Station. • Information Manual (contains Pilot's Operating Handbook Information) •...

  • Page 247: Airplane Inspection Periods

    SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) To be carried in the airplane at all times: Approvedl 1. Current Pilot's Operating Handbook and Airplane Flight Manual. 2. Weight and Balance, and associated papers (latest copy of the Repair and Alteration Form, FAA Form 337, if applicable).

  • Page 248: Cessna Inspection Programs

    SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) CESSNA INSPECTION PROGRAMS In lieu of the 100 hour and annual inspection requirements, an airplane may be inspected in accordance with a Progressive Care llnspection Program or a PhaseCard Inspection Program. Both programs offer systems which allow the work load to be divided into smaller operations that can be accomplished in shorter time periods.

  • Page 249: Cessna Customer Care Program

    CESSNA SECTION 8 MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE CESSNA CUSTOMER CARE PROGRAM Specific benefits and provisions of the Cessna Warranty plus other important benefits for you are contained in the Customer Carel Program Handbook supplied with your airplane. The Customer Care Program Handbook should be thoroughly reviewed and kept in the airplane at all times.

  • Page 250: Alterations Or Repairs

    SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172A {180 HP) A Maintenance Manual must be obtained prior to performing any ,.p reventive maintenance to ensure that proper procedures are rouowed. Your local Cessna Service Station should be contacted for further information or for required maintenance which must be accomplished by appropriately licensed personnel.

  • Page 251: Tie-Down

    CESSNA SECTION 8 MODEL 172A (180 HP) HANDLING, SERVICE & MAINTENANCE PARKING When parking the airplane, head into the wind and set the parking brake. Do not set the parking brake during cold weatherl when accumulated moisture may freeze the brakes, or when the brakes are overheated.

  • Page 252: Leveling

    SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) AcAur10N DO NOT APPLY PRESSURE ON THE ELEVATOR HORIZONTAL STABILIZER SURFACES. WHEN PUSHING ON THE TAILCONE, ALWAYS APPLY PRESSURE AT A BULKHEAD TO AVOID BUCKLING THE SKIN. If nose gear maintenance is required, the nose wheel may be raised off the ground by pressing down on a tailcone bulkhead, just forward of the horizontal stabilizer, and allowing the tail to rest on the tail tie-down ring.
  • Page 253 CESSNA SECTION 8 MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE & WARNING FOR MAXIMUM SAFETY, CHECK THAT THE IGNITION SWITCH IS OFF, THE THROTTLE IS CLOSED, THE MIXTURE CONTROL IS IN THE IDLE CUT OFF POSITION, AND THE AIRPLANE SECURED BEFORE ROTATING...

  • Page 254: Oil Specification

    MIL- L-22851 or SAE J1899 Aviation Grade Ashless Dispersant Oil: Oil conforming to Textron L ycoming Service Instruction No. 1014 , and all revision and supplements thereto, must be used after first 50 hours, or when oil consumption has stabilized.

  • Page 255: Capacity Of Engine Sump

    CESSNA SECTION 8 MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE CAPACITY OF ENGINE SUMP The engine has a total capacity of 9 quarts, with the oil filte accounting for approximately one quart of that total. The engine oil sump has a capacity of 8 quarts. The engine must not be operated on less than 5 quarts (as measured by the dipstick).

  • Page 256: Fuel

    SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) FUEL APPROVED FUEL GRADES (AND COLORS) 100LL Grade Aviation Fuel (Blue). 100 Grade Aviation Fuel (Green). NOTE lsopropyl alcohol or diethylene glycol monomethyl ether (DiEGME) may be added to the fuel supply in quantities not to exceed 1% (alcohol) or 0.15% (DiEGME) of total volume.
  • Page 257 CESSNA SECTION 8 MAINTENANCE MODEL 172R (180 HP) HANDLING, SERVICE & One exception to this can be encountered when operating under the combined effect of: use of certain fuels, with (2) high humidity conditions on the ground (3) followed by flight at high altitude and low temperature.
  • Page 258 SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) � 40 �. � . � - � q�- � �t�����iijt. = • B ' t , � · � · ,:I , �+. � .�� � _� � ..�30J_ H ++J::·r ➔...
  • Page 259 CESSNA SECTION 8 HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) 2. An alternate method that may be used is to premix the complete alcohol dosage with some fuel in a separate clean container (approximately 2-3 gallon capacity) and then transferring this mixture to the tank prior to the fuel operation.

  • Page 260: Fuel Contamination

    SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) FUEL CONTAMINATION Fuel contamination is usually the result of foreign material present in the fuel system, and may consist of water, rust, sand, dirt, microbes or bacterial growth. In addition, additives that are not compatible with fuel or fuel system components can cause the fuel to become contaminated.

  • Page 261: Landing Gear

    CESSNA SECTION 8 MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE LANDING GEAR Consult the following table for servicing information on the landing gear. COMPONENT SERVICING CRITERIA Nose Wheel (5.00-5, 6-Ply Rated Tire) 45.0 PSI Main Wheel (6.00-6, 6-Ply Rated Tire) 38.0 PSI Brakes MIL-H-5606...

  • Page 262: Painted Surfaces

    SECTION 8 CESSNA HANDLING, SERVICE & MAINTENANCE MODEL 172R (180 HP) Follow by carefully washing with a mild detergent and plenty of water. Rinse thoroughly, then dry with a clean moist chamois. Do not rub the plastic with a dry cloth since this builds up an electrostatic charge which attracts dust.

  • Page 263: Propeller Care

    CESSNA SECTION 8 MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE When the airplane is parked outside in cold climates and it is necessary to remove ice before flight, care should be taken to protect the painted surfaces during ice removal with chemical liquids.

  • Page 264: Interior Care

    CESSNA SECTION 8 MODEL 172R (180 HP) HANDLING, SERVICE & MAINTENANCE INTERIOR CARE To remove dust and loose dirt from the upholstery and carpet, clean the interior regularly with a vacuum cleaner. Blot up any spilled liquid promptly with cleansing tissue or rags. Do not pat the spot;...
  • Page 265 ..., ..., r­ ..
  • Page 266 "' �...
  • Page 267 CESSNA SECTION 9 MODEL 172R (180 HP) SUPPLEMENTS SUPPLEMENTS INTRODUCTION The supplements in this section contain expanded operational procedures for both standard and optional equipment installed in the airplane. Operators should refer to each supplement to ensure that all limitations and procedures appropriate for their airplane are observed.

  • Page 269: Model 172R180Hp

    SUPPLEMENT REVISION MODEL 172R180HP PILOT'S OPERATING HANDBOOK AND FAA APPROVED AIRPLANE FLIGHT MANUAL REVISION 2 4 OCTOBER 2001 PART NUMBER: 172R180USLOG02 INSERT THE FOLLOWING PAGES INTO THE SUPPLEMENT SECTION OF THE PILOT'S OPERATING HANDBOOK...
  • Page 270 �...
  • Page 271 CESSNA LOG OF APPROVED MODEL 172R (180 HP) SUPPLEMENTS LOG OF APPROVED SUPPLEMENTS NOTE IT IS THE AIRPLANE OWNER'S RESPONSIBILITY TO ASSURE THAT HE OR SHE HAS THE LATEST REVISION TO EACH SUPPLEMENT OF A PILOT'S OPERATING HANDBOOK AND THE LATEST ISSUED "LOG OF APPROVED SUPPLEMENTS."...
  • Page 272 LOG OF APPROVED CESSNA SUPPLEMENTS MODEL 172R (180 HP) LOG OF APPROVED SUPPLEMENTS SUPP. SUPPLEMENT NAME EQUIPMENT LEVEL INSTALLED Reserved Canadian Supplement Bendix/King KCS-55A Slaved Compass System with Kl-525A Horizontal Situation Indicator (HSI) Argentine Supplement � ,... Bendix/King KAP 140 2 Axis Autopilot with Altitude Preselect Reserved /<..
  • Page 273 � A Textron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 80001 AND ON SUPPLEMENT 1 BENDIX/KING KX 155A VHF NAV/COMM with Kl 208 or Kl 209A INDICATOR HEAD SERIAL NO • . _____ __ _ REGISTRATION NO .
  • Page 274 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 1 - FAA APPROVED MODEL 172R SUPPLEMENT 1 BENDIX/KING KX 155A VHF NAV /COMM with Kl 208 or Kl 209A INDICATOR HEAD The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 275 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 1 - FAA APPROVED SUPPLEMENT BENDIX/KING KX 155A NAV /COMM with Kl 208 or Kl 209A INDICATOR HEAD SECTION 1 GENERAL The Bendix/King KX 155A Nav/Comm, shown in Figure 1, consists of a panel-mounted receiver-transmitter and a Kl 208 or Kl 209A Indicator.
  • Page 276 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 1 - FAA APPROVED MODEL 172A The Comm portion incorporates an automatic squelch. override the automatic squelch, the Comm volume control knob is pulled out. Push the knob back in to reactivate the automatic squelch.
  • Page 277 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 1 - FAA APPROVED /22.l 3.00 I I 11.bD 39:Sb COMM KX 155A VHF NAV/COMM ... TO INDICATION FROM INDICATION @FLAG INDICATION KJ 209A INDICATOR 0585C1045 Kl 208 INDICATOR HEAD 0585C1046 0585C1047 Figure 1.
  • Page 278 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 1 - FAA APPROVED MODEL 172R NAV FUNCTION DISPLAYS ·\ 109.50 - + -- -- __ /\ __ -- -- -� VOA MODE: ACTIVE/BEARING, COi FORMAT VOA MODE: ACTIVE/BEARING, FLAG DISPLAY 109.50 VOR MODE: ACTIVE "BEARING TO" FUNCTION DISPLAY 109.50 VOR MODE: ACTIVE/BEARING, FLAG DISPLAY 110.90...
  • Page 279 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 1 - FAA APPROVED 1. OPERATING COMM FREQUENCY DISPLAY -- Displays COMM ACTIVE and COMM STANDBY frequencies with a "T" between them to indicate TRANSMIT and an "R" to indicate RECEIVE modes of operation. 2.
  • Page 280 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 1 - FAA APPROVED MODEL 172R 6. NAV/FREQUENCY TRANSFER BUTTON ( .: Ja Interchanges the NAV Active and STANDBY frequencies. Depressing the NAV frequency transfer button for 2 seconds or more will cause the display to go in to the ACTIVE ENTRY mode.
  • Page 281 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 1 - FAA APPROVED Another push of the mode button will cause the NAV display from ACTIVE/BEARING format ACTIVE/RADIAL format. In the RADIAL mode, the frequency inc/dee knobs channel the ACTIVE frequency window and depressing the frequency transfer button will cause the ACTIVE frequency to be placed in blind storage and the STANDBY frequency (in blind storage) to be displayed in the...
  • Page 282 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 1 - FAA APPROVED MODEL 172R 9. COMM FREQUENCY SELECTOR KNOB {INNER) -- This smaller knob is designed to change the indicated frequency in steps of 50-kHz when it is pushed in, and in 25-kHz steps when it is pulled out.
  • Page 283 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 1 - FAA APPROVED ) - - 12. COMM FREQUENCY TRANSFER BUTTON ( tE • Interchanges the frequencies in the USE and STANDBY displays. To tune the radio to the desired operating frequency, the desired frequency must be entered into the standby display and then the transfer button must be pushed.
  • Page 284 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 1 - FAA APPROVED MODEL 172R SECTION 2 LIMITATIONS There is no change to the airplane limitations when this avionic equipment is installed. SECTION 3 EMERGENCY PROCEDURES There is no change to the airplane emergency procedures when this avionic equipment is installed.
  • Page 285 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 1 - FAA APPROVED 6. Mic Button: a. To transmit -- Press button and speak in microphone. NOTE During COMM transmission, a lighted "T" will appear between the "COMM" and "STBY" displays to indicate that the transceiver is operating in the transmit code.
  • Page 286 CESSNA SECTION 9 - SUPPLEMENTS SUPPLEMENT 1 - FAA APPROVED MODEL 172R GLIDESLOPE OPERATION The glideslope receiver is automatically channeled when a localizer frequency is selected. A separate warning flag is provided to indicate usable signal conditions. PILOT CONFIGURATION This mode can be accessed by pressing and holding the NAV Mode Button for more than 2 seconds and then pressing the Nav Frequency Transfer Button for an additional 2 seconds, while continuing to hold the NAV Mode Button.
  • Page 287 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 1 - FAA APPROVED Subsequent presses of the MODE button sequences through SWRV, BRIM, SIDE, and then back to SWRV. Pressing the NAV Transfer Button momentarily exits Pilot configuration mode. The NAV returns to its pre-Pilot Config state with the new brightness and sidetone levels stored in nonvolatile memory.
  • Page 289 � A Textron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 80001 AND ON SUPPLEMENT 2 BENDIX/KING KT 76C TRANSPONDER WITH BLIND ENCODER SERIAL NO. _______ _ REGISTRATION NO. _____ _ This supplement must be inserted into Section 9 of the Pilot's Operating Handbook and FAA Approved Airplane Flight Manual.
  • Page 290 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 2 - FAA APPROVED MODEL 172A SUPPLEMENT 2 BENDIX/KING KT 76C TRANSPONDER with BLIND ENCODER The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 291 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 2 - FAA APPROVED SUPPLEMENT BENDIX/KING KT 76C TRANPONDER with BLIND ENCODER SECTION 1 GENERAL The Bendix/King Transponder (Type KT 76C), Shown in Figure 1, is the airborne component of an Air Traffic Control Radar Beacon System (ATCRBS).
  • Page 293 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172A SUPPLEMENT 2 - FM APPROVED 1200 rn rn m rn m m m rn 1. IDENT BUTTON (IDT) - When depressed, selects special identifier pulse to be transmitted with transponder reply to effect immediate identification of the airplane on the ground controller's display.
  • Page 294 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 2- FAA APPROVED MODEL 172R 3. MODE ANNUNCIATORS - Displays the operating mode of the transponder. 4. REPLY INDICATOR (R) - "R" is illuminated for momentarily when the transponder is replying to a valid interrogation and during the 18 ±...
  • Page 295 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 2 - FAA APPROVED SECTION 2 LIMITATIONS There is no change to the airplane limitations when this avionic equipment is installed. SECTION 3 EMERGENCY PROCEDURES TO TRANSMIT AN EMERGENCY SIGNAL: 1. Mode Selector Knob - ALT. 2.
  • Page 296 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 2 - FAA APPROVED MODEL 172R 2. Mode Selector Knob -- ON. NOTES • During normal operation with Mode Selector Knob in ON position, reply indicator flashes, indicating transponder replies to interrogations. • Mode A reply codes are transmitted in ALT also; however, Mode C codes are suppressed when the Mode Selector Knob is positioned to ON.
  • Page 297 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 2 - FM APPROVED TO PROGRAM VFR CODE: 1 . Mode Selector Knob -- SBY. 2. Numeric Keys 0-7 -- SELECT desired VFR code. 3. IDT Button -- PRESS AND HOLD. a. VFR Code Button -- PRESS (while still holding IDT button) to place new VFR code in nonvolatile memory for subsequent call up.
  • Page 300 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 3 - FAA APPROVED SUPPLEMENT 3 BENDIX/KING KMA 26 AUDIO SELECTOR PANEL The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 301 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 3 - FAA APPROVED SUPPLEMENT BENDIX/KING KMA 26 AUDIO SELECTOR PANEL SECTION 1 GENERAL The Bendix/King KMA 26 Audio Selector Panel is a combination audio amplifier, an audio distribution panel intercom, and a marker beacon receiver.
  • Page 302 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 3 - FAA APPROVED MODEL 172R 1. MARKER BEACON ANNUNCIATOR LIGHTS -- The three-light marker beacon receiver built into the KMA 26 gives a visual and aural signal when the ship's antenna passes over a 75 MHz beacon. The blue, amber, and white lights on the faceplate, as well as the audio tones, identify the beacon type.
  • Page 303 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172A SUPPLEMENT 3 - FAA APPROVED 4. AUDIO SELECT BUTTONS •• Push button audio selection is available for three Communications receivers ("COM 1 ", "COM 2", and "COM 3"), two Navigation receivers ("NAV 1" and "NAV 2"), the internal Marker Beacon receiver ("MKR"), one DME, one ADF, and one additional auxiliary receiver ("AUX").
  • Page 305 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 3 - FAA APPROVED SECTION 2 LIMITATIONS There is no change to the airplane limitations when this avionic equipment is installed. SECTION 3 EMERGENCY PROCEDURES In the event of an audio amplifier in the KMA 26, as evidenced by the inability to transmit in COM 1, 2 or 3.
  • Page 307 � A Textron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 80001 AND ON SUPPLEMENT 4 POINTER MODEL 3000-11 EMERGENCY LOCATOR TRANSMITTER SERIAL NO. _______ _ REGISTRATION NO. ______ _ This supplement must be inserted into Section 9 of the Pilot's Operating Handbook and FAA Approved Airplane Flight Manual.
  • Page 308 CESSNA SECTION 9 - SUPPLEMENTS SUPPLEMENT 4 - FAA APPROVED MODEL 172R SUPPLEMENT 4 POINTER MODEL 3000-11 EMERGENCY LOCATOR TRANSMITTER (EL T) The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 309 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172A SUPPLEMENT 4 - FAA APPROVED SUPPLEMENT POINTER MODEL 3000-11 EMERGENCY LOCATOR TRANSMITTER (EL T) SECTION 1 GENERAL This supplement provides information which must be observed when operating the Pointer Model 3000-11 Emergency Locator Transmitter.
  • Page 310 CESSNA SECTION 9 - SUPPLEMENTS SUPPLEMENT 4 - FAA APPROVED MODEL 172R In accordance with FAA regulations, the EL T's battery pack must be replaced after 2 years shelf or service life or for any of the ---...,_ following reasons: a.
  • Page 311 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 4 - FAA APPROVED OFF/RESET --Deactivates transmitter during handling, following rescue and to reset the automatic activation function. (The red annunciator in the center of the remote switch/annunciator should extinguish). 5. REMOTE SWITCH/ANNUNCIATOR (3-position rocker switch): ON -- Remotely activates the transmitter for test or emergency situations.
  • Page 312 SECTION 9 - SUPPLEMENTS CESSNA MODEL 172R SUPPLEMENT 4 - FM APPROVED 1. ENSURE ELT ACTIVATION: a. Position remote switch/annunciator to the ON position even if annunciator light is already on. b. If airplane radio is operable and can be safely used (no threat of fire or explosion), turn ON and select 121.5 MHz.
  • Page 313 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 4 - FAA APPROVED The ELT must be serviced in accordance with FAR Part 91.207. INSPECTIONfTEST 1. The emergency locator transmitter should be tested every 100 hours. NOTE Test should only be conducted within the first 5 minutes of each hour.
  • Page 314 CESSNA SECTION 9 - SUPPLEMENTS SUPPLEMENT 4 - FAA APPROVED MODEL 172R IN-FLIGHT MONITORING AND REPORTING Pilot's are encouraged to monitor 121.5 MHz and/or 243.0 MHz while in flight to assist in identifying possible emergency EL T transmissions. On receiving a signal, report the following information to the nearest air traffic control facility: 1.
  • Page 315 A Textron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 172R80001 ANDON SUPPLEMENT 5 BENDIX/KING KLN 89B GLOBAL POSITIONING SYSTEM (IFR) SERIAL NO. _______ _ REGISTRATION NO. ______ _ This supplement must be inserted into Section 9 of the P ilot's Operating Handbook and FAA Approved Airplane Flight Manual when the Global Positioning System is installed.
  • Page 316 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 5 - FAA APPROVED MODEL 172R SUPPLEMENT 5 BENDIX/KING KLN 89B GLOBAL POSITIONING ISYSTEM (IFR) The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 317 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 5 - FM APPROVED SUPPLEMENT 5 BENDIX/KING KLN 898 GLOBAL POSITIONING SYSTEM (IFR) SERVICE BULLETIN CONFIGURATION LIST The following is a list of Service Bulletins that are applicable to the operation of the airplane, and have been incorporated into this supplement.
  • Page 318 SECTION 9 - SUPPLEMENTS CESSNA MODEL 172R SUPPLEMENT 5 - FAA APPROVED SUPPLEMENT BENDIX/KING KLN 898 GPS NAVIGATION SYSTEM (IFR) SECTION 1 GENERAL WARNING THE KLN 89B IS NOT AUTHORIZED INSTRUMENT APPROACHES UNLESS OPERATIONAL REVISION STATUS UPGRADED TO "ORS 02" OR LATER, AS READ ON THE POWER-ON PAGE, AND THE HOST SOFTWARE IS UPGRADED TO "HOST 00880- 0004"...
  • Page 319 CESSNA SECTION 9 - SUPPLEMENTS SUPPLEMENT 5 - FAA APPROVED MODEL 172R The database card is an electronic memory containing information on airports, navaids, intersections, SID's, STAR's, instrument approaches, special use airspace, and other items of interest to the pilot. Every 28 days, Bendix/King receives new database information from Jeppesen Sanderson for the North American database region.
  • Page 320 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 5 - FAA APPROVED MODEL 172R NOTE Aircraft using GPS for oceanic IFR operations may use the KLN 898 to replace one of the other approved means of long range navigation. A single KLN 898 GPS installation may also be used on short oceanic routes which require only one means of long-range navigation.
  • Page 321 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 5 - FAA APPROVED 0585C1042 (MSG) 1. GPS MESSAGE ANNUNCIATOR LIGHT -- will begin flashing whenever the message prompt (a large "M" on the left side of the screen) on the KLN 89B GPS unit begins flashing to alert the pilot that a message is waiting.
  • Page 322 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 5 - FAA APPROVED MODEL 172R AwARNING TURN ANTICIPATION AUTOMATICALLY DISABLED FOR FAF WAYPOINTS AND THOSE USED EXCLUSIVELY IN SID/STARS WHERE OVERFLIGHT IS REQUIRED. FOR WAYPOINTS SHARED BETWEEN SID/STARS PUBLISHED EN ROUTE SEGMENTS (REQUIRING OVERFLIGHT IN THE SID/STARS), PROPER...
  • Page 323 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 5 - FM APPROVED 6. NAV/GPS SWITCH -- Toggles from Nav 1 to GPS and vice versa to control the type of navigation data to be displayed on the COi (Course Deviation Indicator). The No. 1 COi Omni Bearing Selector (OBS) provides analog course input to the NAV/GPS mode...
  • Page 324 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 5 - FAA APPROVED SECTION 2 LIMITATIONS 1. The KLN 89B GPS Pilot's Guide, PIN 006-08786-0000, dated May, 1995 (or later applicable revision) must be available to the flight crew whenever IFR GPS navigation is used. Operational Revision Status (ORS) of the Pilot's Guide must match the ORS level annunciated on the Self Test page.
  • Page 325 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 5 - FAA APPROVED 3) APR ACTV mode must be annunciated at the Final Approach Fix. 4) Accomplishment of ILS, LOG, LOG-BC, LOA, SDF, and MLS approaches are not authorized. 5) When an alternate airport is required by the applicable operating rules, it must be served by an approach based on other than GPS or Loran-C navigation.
  • Page 326 SECTION 9 • SUPPLEMENTS CESSNA SUPPLEMENT 5 • FAA APPROVED MODEL 172R SECTION 3 EMERGENCY PROCEDURES There are no changes to the basic airplane emergency procedures when the KLN 89B GPS is installed. 1. If the KLN 89B GPS information is not available or invalid, utilize remaining operational navigation equipment as required.
  • Page 328 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 5 - FAA APPROVED MODEL 172R APPROACH MODE SEQUENCING AND RAIM PREDICTION AwARNING FAMILIARITY WITH THE EN ROUTE OPERATION OF THE KLN 898 DOES NOT CONSTITUTE PROFICIENCY IN APPROACH OPERATIONS. DO NOT ATTEMPT APPROACH OPERATIONS IN (INSTRUMENT METEOROLOGICAL ATTAINING...
  • Page 334 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 6 - FAA APPROVED MODEL 172A SUPPLEMENT 6 BENDIX/KING KR 87 ADF AUTOMATIC DIRECTION FINDER The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 335 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 6 - FAA APPROVED SUPPLEMENT BENDIX/KING KR 87 ADFAUTOMATIC DIRECTION FINDER SECTION 1 GENERAL The Bendix/King Digital ADF is a panel-mounted, digitally tuned automatic direction finder. It is designed to provide continuous 1- kHz digital tuning in the frequency range of 200-kHz to 1799-kHz and eliminates the need for mechanical band switching.
  • Page 336 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 6 - FM APPROVED MODEL 172R 0585C1043 0585C1044 Figure 1. KR 87 Automatic Direction Finder (ADF) (Sheet 1 of 4) Dec 2/96 S6-4...
  • Page 337 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172A SUPPLEMENT FAA APPROVED 1. ANT/ADF MODE ANNUNCIATOR -- Antenna (ANT) is selected by the "out" position of the ADF button. This mode improves the audio reception and is usually used for station identification. The bearing pointer is deactivated and will park °...
  • Page 338 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 6 - FAA APPROVED MODEL 172R 5. FLIGHT TIMER AND ELAPSED TIMER MODE ANNUNCIATION -- Either the elapsed time (ET) or flight time (FLT) mode is annunciated here. 6. FREQUENCY SELECT KNOBS -- Selects the standby frequency when FRO is displayed and directly selects the active frequency whenever either of the time functions is selected.
  • Page 339 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 6 - FAA APPROVED 13.LUBBER LINE -- Indicates relative or magnetic heading of the aircraft. The heading must be manually input by the pilot with the heading (HOG) knob. 14. COMPASS CARD -- Manually rotatable card that indicates relative or magnetic heading of aircraft, as selected by HOG knob.
  • Page 340 SECTION 9 • SUPPLEMENTS CESSNA SUPPLEMENT 6 - FAA APPROVED MODEL 172A SECTION 2 LIMITATIONS There is no change to airplane limitations when the KR 87 ADF is installed. -----. SECTION 3 EMERGENCY PROCEDURES There are no changes to the basic airplane emergency �...
  • Page 341 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 6 - FAA APPROVED TO OPERATE BFO: 1. OFFNOL Control - ON. 2. BFO Button -- PRESS on. 3. ADF Selector Buttons (on audio control panel) -- SET to desired mode. 4. VOL Control - ADJUST to desired listening level. NOTE A 1000-Hz tone and Morse Code identifier is heard in the audio output when a CW signal is received.
  • Page 343 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 6 - FAA APPROVED ADF OPERATION NOTES: ERRONEOUS ADF BEARING DUE TO RADIO FREQUENCY PHENOMENA: In the U.S., the FCC, which assigns AM radio frequencies, occasionally will assign the same frequency to more than one station in an area.
  • Page 344 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 6 - F A APPROVED MODEL 172R SECTION 5 PERFORMANCE There is no change to the airplane performance when this avionic equipment is installed. However, the installation of an externally mounted antenna or related external antennas, will result in a minor reduction in cruise performance.
  • Page 345 A Textron Co-npany Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 80001 AND ON SUPPLEMENT 7 BENDIX/KING KAP 140 AUTOPILOT SERIAL NO. _______ _ ��=: : Alfi REGISTRATION NO . . ______ _ This supplement must be inserted into Section 9 of the Pilot's Operating Handbook and FAA Approved Airplane Flight Manual when the Global Positioning System is installed.
  • Page 346 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 7 - FAA APPROVED MODEL 172R SUPPLEMENT 7 BENDIX/KING KAP140 AUTOPILOT The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 347 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 7 - FAA APPROVED SUPPLEMENT BENDIX/KING KAP140 AUTOPILOT SECTION 1 GENERAL The Bendix/King KAP 140 is an all electric, single-axis (aileron control) autopilot system that provides lateral and directional control. Components are a computer, a turn coordinator, an aileron actuator, a course deviation indicator, and a directional gyro.
  • Page 348 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 7 - FAA APPROVED MODEL 172R NAV/COMM CONTROL PANEL - PILOT NAVIGATION SOURCE SELECTOR SWITCH CONTROL WHEEL DIRECTIONAL GYRO TURN COORDINATOR ACTUATOR AUTOPILOT COMPUTER AVIONICS 3 4 5 6 ELECTRICAL 05851054 Figure 1 . Bendix/King KAP 140 Autopilot, Operating Controls and Indicators (Sheet 1 of 2) S7-4 Dec 2/96...
  • Page 349 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 7 - FAA APPROVED Hl>G KAP 140 1. ROLL SERVO ANNUNCIATOR -- When illuminated, indicates failure of the roll servo and prevents engagement of the autopilot. (AP) 2. AUTOPILOT ENGAGE/DISENGAGE BUTTON -- When pushed, engages autopilot if all logic conditions are met.
  • Page 351 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 7 - FAA APPROVED SECTION 2 LIMITATIONS The following autopilot limitation must be adhered to: 1. The autopilot must be OFF during takeoff and landing. 2. During autopilot operation, the pilot, with seat belt fastened, must be seated in the left front seat.
  • Page 352 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 7 - FAA APPROVED MODEL 172R WARNING ATTEMPT RE-ENGAGE AUTOPILOT FOLLOWING AUTOPILOT MALFUNCTION. A, WARNING THE PILOT IN COMMAND MUST CONTINUOUSLY MONITOR AUTOPILOT WHEN ENGAGED, PREPARED DISCONNECT AUTOPILOT TAKE IMMEDIATE CORRECTIVE ACTION • INCLUDING MANUAL CONTROL OF THE AIRPLANE AND/OR PERFORMANCE OF EMERGENCY PROCEDURES AUTOPILOT...
  • Page 353 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 7 - FAA APPROVED Note that the emergency procedure for any malfunction is essen­ tially the same: immediately grasp the control wheel and regain air­ plane control while pressing and the holding the A/P DISC switch down.
  • Page 354 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 7 - FAA APPROVED MODEL 172A 2. AVIONICS MASTER - ON. 3. POWER APPLICATION AND SELF TEST A self test is performed upon power application to the computer. This test is a sequence of internal checks that validate proper system operation prior to allowing normal system operation.
  • Page 356 SECTION 9 - SUPPLEMENTS CESSNA MODEL 172R SUPPLEMENT 7 - FAA APPROVED 5. If the Course Deviation Indicator (COi) needle is less than 2 to 3 dots from the center: the HOG mode will disengage upon se­ lecting NAV mode; the NAV annunciator will illuminate and the capture/track sequence will automatically begin (after 5 sec­...
  • Page 357 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 7 - FAA APPROVED BACK COURSE APPROACH COUPLING 1. #1 OBS Knob -- SELECT the localizer front course inbound heading (as a memory aid). 2. REV Mode Selector Button -- PRESS. 3. Heading Selector Knob - ROTATE BUG to the localizer front course inbound heading.
  • Page 358 CESSNA SECTION 9 - SUPPLEMENTS SUPPLEMENT 7 - FAA APPROVED MODEL 172R MISSED APPROACH 1. A/P DISC - PRESS to disengage AP. 2. MISSED APPROACH - EXECUTE. 3. AP Button -- PRESS (if AP operation is desired). Note ROL ----.. annunciator ON.
  • Page 359 A Textron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 80001 AND ON SUPPLEMENT 8 WINTERIZATION KIT SERIAL NO. _______ _ REGISTRATION NO. _ _ _ __ _ �; � =: � This supplement must be inserted into Section 9 of the Pilot's Operating Handbook and FAA Approved Airplane Flight Manual when the winterization kit is installed.
  • Page 361 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172A SUPPLEMENT 8 - FAA APPROVED SUPPLEMENT WINTERIZA TION KIT SECTION 1 GENERAL The winterization kit consists of two cover plates (with placards) which attach to the air intakes in the cowling nose cap, a placard silk screened on the instrument panel, and insulation for the crankcase breather line.
  • Page 362 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 8 - FAA APPROVED MODEL 172R SECTION 3 EMERGENCY PROCEDURES There is no change to the airplane emergency procedures when the winterization kit is installed. SECTION 4 NORMAL PROCEDURES There is no change to the airplane normal procedures when the winterization kit is installed.
  • Page 363 � A Tex,ron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 17280001 AND ON SUPPLEMENT 9 DA VTRON MODEL 803 CLOCK/O.A. T. SERIAL NO. _______ _ RATION NO _____ _ REGIS This supplement must be inserted into Section 9 of the Pilot's Operating Handbook and FAA Approved Airplane Flight Manual when the Davtron Clock/O.A.T.
  • Page 364 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 9 - FAA APPROVED SUPPLEMENT 9 I DAVTRON MODEL 803 CLOCK/O.A.T. The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 365 C ESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 9 - FAA APPROVED SUPPLEMENT DIGITAL CLOCK/0.A.T. SECTION 1 GENERAL The Davtron Model 803 digital clock combines the features of a clock, outside air temperature gauge (0.A.T.) and voltmeter in a single unit.
  • Page 366 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 9 - FAA APPROVED MODEL 172R UPPER BUTTON UPPER LCD WINDOW LOWER LC WINDOW CONTROL 0785C1005 OAVTROII SELEC CONTROL BUTTON BUTTON Figure 1. Clock/OAT Gauge SECTION 4 NORMAL PROCEDURES TEST MODE The unit may be tested by holding the SELECT button down for three seconds.
  • Page 367 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 9 - FAA APPROVED CLOCK OPERATIONS The lower portion of the LCD window is dedicated to clock and timing operations. Pushing the SELECT button will sequence the window from universal time (UT) to local time (LT) to flight time (FT) to elapsed time (ET), and back again to universal time.
  • Page 368 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 9 - FAA APPROVED SETTING FLIGHT TIME FLASHING ALARM SELECT button select flight time (FT). Simultaneously press both the SELECT and the CONTROL buttons to enter the set mode. The tens of hours digit will start flashing. The set operation is the same as for UT.
  • Page 369 A Textron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 80001 AND ON SUPPLEMENT 10 BENDIX/KING KLN 89 GLOBAL POSITIONING SYSTEM (GPS) SERIAL NO. _______ _ REGISTRATION NO. ___ __ _ This supplement must be inserted into Section 9 of the Pilot's Operating Handbook and FAA Approved Airplane Flight Manual when the Global Positioning System is installed.
  • Page 370 SECTION 9 - SUPPLEMENTS CESSNA MODEL 172R SUPPLEMENT 10 - FAA APPROVED SUPPLEMENT 10 ..BENDIX/KING KLN 89 GLOBAL POSITIONING SYSTEM (GPS) The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 371 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 10 - FAA APPROVED SUPPLEMENT Bendix/King KLN 89 GPS SECTION 1 GENERAL The Bendix/King KLN 89 is a navigation system based on the Global Positioning Satellite network. It contains a database cartridge which may be updated by subscription.
  • Page 372 SECTION 9 - SUPPLEMENTS CESSNA MODEL 172A SUPPLEMENT 10 - FAA APPROVED SECTION 4 NORMAL PROCEDURES There is no change to basic airplane normal operating procedures with the KLN 89 GPS installed. SECTION 5 PERFORMANCE There is no change to the airplane performance when the KLN 89 GPS is installed.
  • Page 373 � A Textron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 80001 AND ON SUPPLEMENT 12 CANADIAN SUPPLEMENT SERIAL NO. _______ _ REGISTRATION NO. _____ _ This supplement must be inserted into Section 9 of the Pilot's Operating Handbook and FAA Approved Airplane Flight Manual when used for Canadian Operation.
  • Page 374 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 12 - FAA APPROVED MODEL 172R SUPPLEMENT 12 CANADIAN SUPPLEMENT The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 376 SECTION 9 • SUPPLEMENTS CESSNA SUPPLEMENT 12 - FM APPROVED MODEL 172R SECTION 3 EMERGENCY PROCEDURES There is no change to the airplane emergency procedures when used for Canadian operation. 'SECTION 4 NORMAL PROCEDURES There is no change to basic airplane normal operating procedures when used for Canadian operation.
  • Page 377 � A Textron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 17280694 AND ON SUPPLEMENT 13 BENDIX/KING KCS-55A SLAVED C OMPASS SYSTEM WITH Kl-525A HORIZONTAL SITUATION INDICATOR (HSI) SERIAL NO •. _______ _ REGISTRATION NO. ______ _...
  • Page 378 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 13 - FAA APPROVED MODEL 172R SUPPLEMENT 13 BENDIX/KING KCS-55A SLAVED COMPASS SYSTEM WITH Kl-525A HORIZONTAL SITUATION INDICATOR {HSI) The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 379 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 13 - FAA APPROVED SUPPLEMENT 13 BENDIX/KING SLAVED COMPASS KCS-SSA SYSTEM WITH Kl-525A HORIZONTAL SITUATION INDICATOR (HSI) SECTION 1 GENERAL The Bendix/King KCS-55A Slaved Compass System with Kl- 525A HSI Indicator is an additional navigation indicator option. The KCS-55A compass system...
  • Page 380 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 13 - FAA APPROVED MODEL 172R Figure 1. Horizontal Situation Indicator System (Sheet 1 of 2) 1. HORIZONTAL SITUATION INDICATOR (HSI) -- Provides a pictorial presentation of aircraft deviation relative to VOR/GPS radials and localizer beams. It also displays glide slope deviations and gives heading reference with respect to magnetic north.
  • Page 381 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 13 - FAA APPROVED 6. TO/FROM INDICATOR -- Indicates direction of VOA station relative to the selected course. Displays TO when a LOC frequency is selected. 7. DUAL GLIDE SLOPE POINTERS -- Displays deviation of airplane from an ILS glideslope.
  • Page 382 CESSNA SECTION 9 - SUPPLEMENTS SUPPLEMENT 13 - FAA APPROVED MODEL 172R Figure 2. KA-51 B Slaving Accessory and Compensator Unit 1. KA-51B SLAVING ACCESSORY AND COMPENSATOR UNIT -- Controls the KCS-55A Compass System. 2. MANUAUAUTOMATIC (FREE/SLAVE) COMPASS SLAVE ·-... SWITCH -- Selects either the manual or automatic slaving mode for the Compass System.
  • Page 385 A Taxtron Company Pilot's Operating Handbook and FAA Approved Airplane Flight Manual CESSNA MODEL 172R AIRPLANES 80001 AND ON SUPPLEMENT 14 ARGENTINE SUPPLEMENT SERIAL NO . . _______ _ REGISTRATION NO. _____ _ This supplement must be inserted into Section 9 of the Pilot's Operating Handbook and FAA Approved Airplane Flight Manual when used for Argentine Operation.
  • Page 386 SECTION 9 - SUPPLEMENTS CESSNA MODEL 172A SUPPLEMENT 14 - FAA APPROVED SUPPLEMENT 14 ARGENTINE SUPPLEMENT The following Log of Effective Pages provides the date of issue for original and revised pages, as well as a listing of all pages in the Supplement.
  • Page 387 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 14 - FAA APPROVED MODEL 172R � A Textron Company Pilot's Operating Handbook Argentine Airplane Flight Manual The Cessna Aircraft Company THIS PUBLICATION MUST BE CARRIED IN THE AIRPLANE AT ALL TIMES. Model 172R Serial No.
  • Page 388 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 14 - FAA APPROVED MODEL 172R THIS MANUAL WAS PROVIDED FOR THE AIRPLANE IDENTIFIED ON THE TITLE PAGE SUBSEQUENT REVISIONS SUPPLIED BY CESSNA AIRCRAFT COMPANY MUST BE PROPERLY INSERTED. The Cessna Aircraft Company, Aircraft Division Original Issue - 9 Mar 1999 ARGENTINE AIRPL.ANe F1.IGHT MANUAL I 8 MARCH 19�9 S14-4...
  • Page 391 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 14 - FAA APPROVED SECTION 2 LIMITATIONS The following information must be displayed in the form of composite or individual placards. 1. In full view of the pilot: (The "DAY-NIGHT-VFR-IFR" entry, shown on the example below, will vary as the airplane is equipped).
  • Page 392 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 14 - FAA APPROVED MODEL 172A On the fuel selector valve: TAKEOFF BOTH ALL FLIGHT LANDING 53.0 GAL. ATTITUDES FUEL SELECTOR --..· LEFT RIGHT 26.5 GAL. 26.5 GAL. LEVEL LEVEL FLIGHT FLIGHT ONLY ONLY Near the fuel tank filler cap: COMBUSTIBLE 1OOLU100 GRADO MINIMO COMBUSTIBLE DE AVIACION...
  • Page 393 CESSNA SECTION 9 - SUPPLEMENTS MODEL 172R SUPPLEMENT 14 - FAA APPROVED On baggage door: 54 KG MAXIMO � EQUIPAJE ADELANTE DE LA TRABA DE LA PUERTA DE EQUIPAJE. 22 KG MAXIMO EQUIPAJE POSTERIOR A TRABA DE LA PUERTA DE EQUIPAJE. MAXIMO: 54 KG COMBINADOS PARA INSTRUCCIONES DECARGA ADICIONALES.
  • Page 394 SECTION 9 - SUPPLEMENTS CESSNA SUPPLEMENT 14 - FAA APPROVED MODEL 172R On Upper Right Side of the Aft Cabin Partition: TRANSMISOR LOCALIZADOR DE EMERGENCIA INSTALADO DETRAS DE ESTA DIVISION DEBE CUMPLIR CON EL DNAR PARTE 91.207 On forward face of firewall adjacent to the battery: PRECAUCION 24 VOL TIOS D.C.
  • Page 396 ----...

This manual is also suitable for:

172r180hp

Table of Contents

Save PDF
