TITLE
FLIGHT CONTROLS - LOWER CABLE GUARD INSPECTION
EFFECTIVITY
MODEL
560XL
The equivalent of this service letter has been incorporated on production airplanes -5090 and On.
REASON
To verify the left and right wing aileron quadrant lower guard attach rivets are correctly installed and do not
touch the aileron quadrant or cables.
DESCRIPTION
This service letter gives instructions to examine the left and right aileron quadrants to see if the lower
guard attach rivets are correctly installed and do not touch the aileron quadrant or cables.
COMPLIANCE
RECOMMENDED. This service letter should be accomplished during a scheduled maintenance period
or phase inspection.
MANPOWER
WORK PHASE
Inspection
Modification (both ailerons)
Sep 9/2003
To obtain satisfactory results, procedures specified in this publication must be accomplished in accordance with accepted industry mainte-
nance practices and prevailing government regulations. Cessna Aircraft Company is not responsible for the quality of work performed in
complying with the requirements herein if the work is accomplished at other than a Cessna-owned Citation Service Center.
Cessna Aircraft Company, Citation Marketing Division, P.O. Box 7706, Wichita, Kansas 67277, U.S.A. 1-316-517-6000, Telefax 1-316-517-8500
SERVICE LETTER
SERIAL NUMBERS
-5001 thru -5089
COPYRIGHT © 2003
SL560XL-27-07
MAN-HOURS
1.0
8.0
560XL-27-07
Page 1 of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Textron Cessna 560XL
Summary of Contents for Textron Cessna 560XL
- Page 1 SERVICE LETTER Citation SL560XL-27-07 TITLE FLIGHT CONTROLS - LOWER CABLE GUARD INSPECTION EFFECTIVITY MODEL SERIAL NUMBERS 560XL -5001 thru -5089 The equivalent of this service letter has been incorporated on production airplanes -5090 and On. REASON To verify the left and right wing aileron quadrant lower guard attach rivets are correctly installed and do not touch the aileron quadrant or cables.
- Page 2 SERVICE LETTER Citation SL560XL-27-07 WARRANTY Eligibility: Affected airplanes that were still within the Cessna five (5) year airframe warranty period on the original issue of this service letter. Parts: Authorized Citation Service Facilities, individual operators, or other maintenance facilities may submit a Credit Claim Form for the parts kit(s) required for accomplishment of this service letter, provided the work is completed and the claim submitted by the expiration date shown below.
- Page 3 SERVICE LETTER Citation SL560XL-27-07 Remove each aileron that does not have the rivet butts on the upper surface of the lower guard installed to specification. (Refer to the Maintenance Manual, Chapter 27, Aileron Control Cables - Maintenance Practices.) If the left aileron must be removed, prior to aileron removal, record the amount of aileron trim tab deflection when the aileron trim control knob is centered.
- Page 4 SERVICE LETTER Citation SL560XL-27-07 Figure 1. Lower Cable Guard Inspection (Sheet 1) Sep 9/2003 560XL-27-07 Page 4...
