Page 1 SERIAL NUMBER Model 172S REGISTRATION NUMBER NAV III Avionics - GFC 700 AFCS Serials 172S10468, 172S10507, 172S10640 and 172S10656 and On This publication includes the material required to be furnished to the pilot by 14 CFR 23. COPYRIGHT © 2007 ORIGINAL ISSUE - 20 DECEMBER 2007 CESSNA AIRCRAFT COMPANY WICHITA, KANSAS, USA...
Page 3 CESSNA INTRODUCTION MODEL 172S NAV III GFC 700 AFCS PILOT’S OPERATING HANDBOOK FAA APPROVED AIRPLANE FLIGHT MANUAL CESSNA MODEL 172S NAV III AVIONICS OPTION - GFC 700 AFCS SERIALS 172S10468, 172S10507, 172S10640 172S10656 AND ON ORIGINAL ISSUE - 20 DECEMBER 2007 REVISION 2 - 18 NOVEMBER 2010 PART NUMBER: 172SPHBUS-02 172SPHBUS-02...
Page 5 CESSNA INTRODUCTION MODEL 172S NAV III GFC 700 AFCS CONGRATULATIONS Congratulations on your purchase and welcome to Cessna ownership! Your Cessna has been designed and constructed to give you the most in performance, value and comfort. This Pilot’s Operating Handbook has been prepared as a guide to help you get the most utility from your airplane.
Page 6 INTRODUCTION CESSNA MODEL 172S NAV III GFC 700 AFCS PERFORMANCE - SPECIFICATIONS *SPEED: Maximum at Sea Level ......126 KNOTS Cruise, 75% Power at 8500 Feet.
Page 7 OIL CAPACITY ........8 QUARTS ENGINE: Textron Lycoming ......IO-360-L2A...
Page 8 INTRODUCTION CESSNA MODEL 172S NAV III GFC 700 AFCS COVERAGE The Pilot’s Operating Handbook (POH) in the airplane at the time of delivery from Cessna Aircraft Company contains information applicable to the Model 172S Nav III airplanes by serial number and registration number shown on the Title Page.
Page 9 CESSNA INTRODUCTION MODEL 172S NAV III GFC 700 AFCS ORIGINAL ISSUE AND REVISIONS This Pilot’s Operating Handbook and FAA Approved Airplane Flight Manual is comprised of the original issue and any subsequent revisions. To make sure that information in this manual is current, the revisions must be incorporated as they are issued.
Page 10 INTRODUCTION CESSNA MODEL 172S NAV III GFC 700 AFCS REVISION FILING INSTRUCTIONS REGULAR REVISIONS Pages to be removed or inserted in the Pilots’ Operating Handbook and FAA Approved Airplane Flight Manual are determined by the Log of Effective Pages located in this section. This log contains the page number and revision level for each page within the POH.
Page 11 CESSNA INTRODUCTION MODEL 172S NAV III GFC 700 AFCS IDENTIFYING REVISED MATERIAL A bar will extend the full length of deleted, new, or revised text added on new or previously existing pages. This bar will be located adjacent to the applicable text in the margin on the left side of the page. A bar in the footer will indicate a revision to the header/footer, a new page, format or spelling/grammar changes and/or that information has slipped to or from that page.
Page 12 INTRODUCTION CESSNA MODEL 172S NAV III GFC 700 AFCS WARNINGS, CAUTIONS AND NOTES Throughout the text, warnings, cautions and notes pertaining to airplane handling and operations are utilized. These adjuncts to the text are used to highlight or emphasize important points. WARNING OPERATING PROCEDURES,...
Page 13 CESSNA INTRODUCTION MODEL 172S NAV III GFC 700 AFCS LOG OF EFFECTIVE PAGES Use this page to determine the currency and applicability of your POH. Pages affected by the current revision are indicated by an asterisk (*) preceding the pages listed under the Page Number column. Revision Level Date of Issue Revision Level Date of Issue Original Issue...
Page 14 INTRODUCTION CESSNA MODEL 172S NAV III GFC 700 AFCS LOG OF EFFECTIVE PAGES (Continued) Page Page Revision Number Status Number Original Revised 3-3/3-4 thru 3-22 Original 3-23 Revised 3-24 thru 3-33 Original * 3-34 thru 3-35 Revised 3-36 thru 3-39/3-40 Original * 4-1 thru 4-4 Revised...
Page 15 CESSNA INTRODUCTION MODEL 172S NAV III GFC 700 AFCS LOG OF EFFECTIVE PAGES (Continued) Page Page Revision Number Status Number 7-1 thru 7-6 Original * 7-7 thru 7-10 Revised 7-11 thru 7-21 Original * 7-22 Revised 7-23 thru 7-25 Original 7-26 Revised 7-27 thru 7-37...
Page 17 CESSNA INTRODUCTION MODEL 172S NAV III GFC 700 AFCS SERVICE BULLETIN CONFIGURATION LIST The following is a list of Service Bulletins that are applicable to the operation of the airplane, and have been incorporated into this manual. This list contains only those Service Bulletins that are currently active. Number Title Airplane Serial...
Page 19 CESSNA INTRODUCTION MODEL 172S NAV III GFC 700 AFCS TABLE OF CONTENTS SECTION GENERAL ........1 LIMITATIONS .
Page 21: Table Of Contents
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS GENERAL TABLE OF CONTENTS Page Three View - Normal Ground Attitude ......1-3 Introduction .
Page 23: Three View - Normal Ground Attitude
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS THREE VIEW - NORMAL GROUND ATTITUDE Figure 1-1* (Sheet 1 of 2) 172SPHBUS-02 U.S.
Page 24 SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS THREE VIEW - NORMAL GROUND ATTITUDE NOTE • Wing span shown with standard strobe lights installed. • Wheel base length is 65.0 inches. • Propeller ground clearance is 11.25 inches. •...
Page 25: Introduction
DESCRIPTIVE DATA ENGINE Number of Engines: 1 Engine Manufacturer: Textron Lycoming Engine Model Number: IO-360-L2A Engine Type: Normally aspirated, direct drive, air-cooled, horizontally opposed, fuel injected, four cylinder engine with 360.0 cu. in. displacement.
Page 26: Fuel
SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS DESCRIPTIVE DATA (Continued) FUEL WARNING USE OF UNAPPROVED FUELS MAY RESULT IN DAMAGE TO THE ENGINE AND FUEL SYSTEM COMPONENTS, RESULTING IN POSSIBLE ENGINE FAILURE. Approved Fuel Grades (and Colors): 100LL Grade Aviation Fuel (Blue) Grade Aviation Fuel (Green) NOTE...
Page 27: Oil
Oil and continue to use until a total of 50 hours has accumulated or oil consumption has stabilized. MIL-L-22851 or SAE J1899 Aviation Grade Ashless Dispersant Oil: Oil conforming to Textron Lycoming Service Instruction No 1014, and all revisions and supplements thereto, must be used after first 50 hours or oil consumption has stabilized.
Page 28: Maximum Certificated Weights
SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS DESCRIPTIVE DATA (Continued) MAXIMUM CERTIFICATED WEIGHTS Ramp Weight: Normal Category ......2558 POUNDS Utility Category .
Page 29: Standard Airplane Weights
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS DESCRIPTIVE DATA (Continued) STANDARD AIRPLANE WEIGHTS Standard Empty Weight ......1663 POUNDS Maximum Useful Load, Normal Category .
Page 30: Symbols, Abbreviations And Terminology
SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS SYMBOLS, ABBREVIATIONS AND TERMINOLOGY GENERAL AIRSPEED TERMINOLOGY AND SYMBOLS KCAS Knots Calibrated Airspeed is indicated airspeed corrected for position and instrument error and expressed in knots. Knots calibrated airspeed is equal to KTAS in standard atmosphere at sea level.
Page 31: Meteorological Terminology
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS SYMBOLS, ABBREVIATIONS AND TERMINOLOGY (Continued) METEOROLOGICAL TERMINOLOGY Outside Air Temperature is the free air static temperature. It may be expressed in either degrees Celsius or degrees Fahrenheit. Standard Temperature Standard Temperature is 15°C at sea level pressure altitude and decreases by 2°C for each 1000 feet of altitude.
Page 32 SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS SYMBOLS, ABBREVIATIONS AND TERMINOLOGY (Continued) ENGINE POWER TERMINOLOGY (Continued) Rich Mixture Increased proportion of fuel in the fuel-air mixture supplied to the engine. As air density increases, the amount of fuel required by the engine increases for a given throttle setting.
Page 33: Airplane Performance And Flight Planning Terminology
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS SYMBOLS, ABBREVIATIONS AND TERMINOLOGY (Continued) AIRPLANE PERFORMANCE AND FLIGHT PLANNING TERMINOLOGY Demonstrated Crosswind Velocity Demonstrated Crosswind Velocity is the velocity of the crosswind component for which adequate control of the airplane during takeoff and landing was actually demonstrated during certification tests.
Page 34: Weight And Balance Terminology
SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS SYMBOLS, ABBREVIATIONS AND TERMINOLOGY (Continued) WEIGHT AND BALANCE TERMINOLOGY Reference Datum Reference Datum is an imaginary vertical plane from which all horizontal distances are measured for balance purposes. Station Station is a location along the airplane fuselage given in terms of the distance from the reference datum.
Page 35 CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS SYMBOLS, ABBREVIATIONS AND TERMINOLOGY (Continued) WEIGHT AND BALANCE TERMINOLOGY (Continued) Basic Empty Weight Basic Empty Weight is the standard empty weight plus the weight of optional equipment. Useful Load Useful Load is the difference between ramp weight and the basic empty weight.
Page 36: Metric/Imperial/U.s. Conversion Charts
SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS METRIC/IMPERIAL/U.S. CONVERSION CHARTS The following charts have been provided to help international operators convert U.S. measurement supplied with the Pilot’s Operating Handbook into metric and imperial measurements. The standard followed for measurement units shown is the National Institute of Standards Technology (NIST), Publication 811, "Guide for the Use of the International System of Units (SI)."...
Page 37: Weight Conversions
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS WEIGHT CONVERSIONS Figure 1-2 (Sheet 1 of 2) 172SPHBUS-00 1-17 U.S.
Page 38 SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS WEIGHT CONVERSIONS Figure 1-2 (Sheet 2) 172SPHBUS-00 1-18 U.S.
Page 39: Length Conversions
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS LENGTH CONVERSIONS Figure 1-3 (Sheet 1 of 4) 172SPHBUS-00 1-19 U.S.
Page 40 SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS LENGTH CONVERSIONS Figure 1-3 (Sheet 2) 172SPHBUS-00 1-20 U.S.
Page 41 CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS LENGTH CONVERSIONS Figure 1-3 (Sheet 3) 172SPHBUS-00 1-21 U.S.
Page 42 SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS LENGTH CONVERSIONS Figure 1-3 (Sheet 4) 172SPHBUS-00 1-22 U.S.
Page 43: Distance Conversions
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS DISTANCE CONVERSIONS Figure 1-4 172SPHBUS-00 1-23 U.S.
Page 44: Volume Conversions
SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS VOLUME CONVERSIONS Figure 1-5 (Sheet 1 of 3) 172SPHBUS-00 1-24 U.S.
Page 45 CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS VOLUME CONVERSIONS Figure 1-5 (Sheet 2) 172SPHBUS-00 1-25 U.S.
Page 46 SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS VOLUME CONVERSIONS Figure 1-5 (Sheet 3) 172SPHBUS-00 1-26 U.S.
Page 47: Temperature Conversions
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS TEMPERATURE CONVERSIONS Figure 1-6 172SPHBUS-00 1-27 U.S.
Page 48: Pressure Conversion
SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS PRESSURE CONVERSION HECTOPASCALS TO INCHES OF MERCURY Figure 1-7 172SPHBUS-00 1-28 U.S.
Page 49: Volume To Weight Conversion
CESSNA SECTION 1 MODEL 172S NAV III GENERAL GFC 700 AFCS VOLUME TO WEIGHT CONVERSION Figure 1-8 172SPHBUS-00 1-29 U.S.
Page 50 SECTION 1 CESSNA GENERAL MODEL 172S NAV III GFC 700 AFCS QUICK CONVERSIONS Figure 1-9 172SPHBUS-00 1-30 U.S.
Page 51 CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS OPERATING LIMITATIONS TABLE OF CONTENTS Page Introduction ..........2-3 Airspeed Limitations .
Page 53: Introduction
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS INTRODUCTION Section 2 includes operating limitations, instrument markings, and basic placards necessary for the safe operation of the airplane, its engine, standard systems and standard equipment. The limitations included in this section and in Section 9 have been approved by the Federal Aviation Administration.
Page 54: Airspeed Limitations
SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS AIRSPEED LIMITATIONS Airspeed limitations and their operational significance are shown in Figure 2-1. Maneuvering speeds shown apply to normal category operations. The utility category maneuvering speed is 98 KIAS at 2200 pounds.
Page 55: Airspeed Indicator Markings
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS AIRSPEED INDICATOR MARKINGS Airspeed indicator markings and their color code significance are shown in Figure 2-2. AIRSPEED INDICATOR MARKINGS KIAS VALUE OR MARKING SIGNIFICANCE RANGE Red Arc* 20 - 40 Low airspeed warning.
Page 56: Powerplant Limitations
MIL-L-6082 or SAE J1966 Aviation Grade Straight Mineral Oil or MIL-L-22851 or SAE J1899 Ashless Dispersant Oil. Oil must comply with the latest revision and/or supplement for Textron Lycoming Service Instruction No. 1014, must be used. Propeller Manufacturer: McCauley Propeller Systems...
Page 57: Powerplant Instrument Markings
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS POWERPLANT INSTRUMENT MARKINGS Powerplant instrument markings and their color code significance are shown in Figure 2-3. Operation with indications in the red range is prohibited. Avoid operating with indicators in the yellow range. POWERPLANT INSTRUMENT MARKINGS GREEN ARC RED LINE...
Page 58: Weight Limits
SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS WEIGHT LIMITS NORMAL CATEGORY Maximum Ramp Weight: ..... . 2558 POUNDS Maximum Takeoff Weight: .
Page 59: Center Of Gravity Limits
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS CENTER OF GRAVITY LIMITS NORMAL CATEGORY Center Of Gravity Range: Forward: 35.0 inches aft of datum at 1950 pounds or less, with straight line variation to 41.0 inches aft of datum at 2550 pounds.
Page 60: Maneuver Limits
SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS MANEUVER LIMITS NORMAL CATEGORY This airplane is certificated in both the normal and utility category. The normal category is applicable to aircraft intended for non aerobatic operations. These include any maneuvers incidental to normal flying, stalls (except whip stalls), lazy eights, chandelles, and turns in which the angle of bank is not more than 60°.
Page 61: Flight Load Factor Limits
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS MANEUVER LIMITS (Continued) UTILITY CATEGORY (Continued) Aerobatics that may impose high loads should not be attempted. The important thing to bear in mind in flight maneuvers is that the airplane is clean in aerodynamic design and will build up speed quickly with the nose down.
Page 62: Kinds Of Operations Limits
SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS KINDS OF OPERATIONS LIMITS The Cessna 172S Nav III airplane is approved for day and night, VFR and IFR operations. Flight into known icing conditions is prohibited. The minimum equipment for approved operations required under the Operating Rules are defined by 14 CFR 91 and 14 CFR 135, as applicable.
Page 63: Kinds Of Operations Equipment List
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS KINDS OF OPERATIONS EQUIPMENT LIST KIND OF OPERATION System, Instrument, Equipment and/or Function COMMENTS PLACARDS AND MARKINGS 1 - 172S Nav III - GFC 700 Accessible to pilot in flight.
Page 64 SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS KINDS OF OPERATIONS EQUIPMENT LIST (Continued) KIND OF OPERATION System, Instrument, Equipment and/or Function COMMENTS EQUIPMENT AND FURNISHINGS 1 - Seat Belt Assembly Each Seat Occupant 2 - Shoulder Harness Front Seat Occupants FLIGHT CONTROLS...
Page 65 CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS KINDS OF OPERATIONS EQUIPMENT LIST (Continued) KIND OF OPERATION System, Instrument, Equipment and/or Function COMMENTS LIGHTING 1 - PFD Bezel Lighting 2 - PFD Backlighting *Refer to Note 2. 3 - MFD Bezel Lighting 4 - MFD Backlighting *Refer to Note 3.
Page 66 SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS KINDS OF OPERATIONS EQUIPMENT LIST (Continued) KIND OF OPERATION System, Instrument, Equipment and/or Function COMMENTS NAVIGATION AND PITOT- STATIC SYSTEM 1 - G1000 Airspeed Indicator 2 - Standby Airspeed Indicator 3 - G1000 Altimeter 4 - Standby Altimeter 5 - G1000 Vertical Speed...
Page 67 CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS KINDS OF OPERATIONS EQUIPMENT LIST (Continued) KIND OF OPERATION System, Instrument, Equipment and/or Function COMMENTS VACUUM 1 - Engine Driven Vacuum Pump 2 - Vacuum Indicator ENGINE FUEL AND CONTROL 1 - Fuel Flow Indicator ENGINE INDICATING 1 - Tachometer (RPM)
Page 68: Fuel Limitations
SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS FUEL LIMITATIONS Total Fuel: .......56.0 U.S. GALLONS (28.0 GALLONS per tank) Usable Fuel (all flight conditions): .
Page 69: System Limitations
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS SYSTEM LIMITATIONS AUX AUDIO SYSTEM Use of the AUX AUDIO IN entertainment input is prohibited during takeoff and landing. Use of the AUX AUDIO IN entertainment audio input and portable electronic devices (PED), such as cellular telephones, games, cassette, CD or MP3 players, is prohibited under IFR unless the operator of the airplane has determined that the use of the Aux Audio...
Page 70: G1000 Limitations
SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS G1000 LIMITATIONS The current Garmin G1000 Cockpit Reference Guide (CRG) Part Number and System Software Version that must be available to the pilot during flight are displayed on the MFD AUX group, SYSTEM STATUS page.
Page 71: Garmin Gfc 700 Afcs (If Installed)
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS G1000 LIMITATIONS (Continued) The COM 1/2 (split COM) function of the Audio Panel is not approved for use. During COM 1/2 operation, transmission by one crew member inhibits reception by the other crew member. The fuel quantity, fuel used and fuel remaining functions of the G1000 are supplemental information only and must be verified by the pilot.
Page 72: Terrain Awareness And Warning System (Taws-B)
SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS G1000 LIMITATIONS (Continued) TERRAIN AWARENESS AND WARNING SYSTEM (TAWS-B) Use of the Terrain Awareness and Warning System (TAWS-B) to navigate to avoid terrain or obstacles is prohibited. TAWS-B is only approved as an aid to help the pilot to see-and-avoid terrain or obstacles.
Page 73: Placards
CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS PLACARDS The following information must be displayed in the form of composite or individual placards. 1. In full view of the pilot: (The "DAY-NIGHT-VFR-IFR" entry, shown on the example below, will vary with installed equipment). 2.
Page 74 SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS PLACARDS (Continued) 3. On the fuel selector valve: 4. Near both fuel tank filler cap: (Continued Next Page) FAA APPROVED 172SPHBUS-00 2-24 U.S.
Page 75 CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS PLACARDS (Continued) 5. On flap control indicator: 6. In baggage compartment: (Continued Next Page) FAA APPROVED 172SPHBUS-00 2-25 U.S.
Page 76 SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS PLACARDS (Continued) 7. A calibration card must be provided to indicate the accuracy of the magnetic compass in 30° increments. 8. Molded on the oil filler cap/dipstick: 9. Silk-screened on the instrument panel directly above the PFD: (Continued Next Page) FAA APPROVED 172SPHBUS-00...
Page 77 CESSNA SECTION 2 MODEL 172S NAV III OPERATING LIMITATIONS GFC 700 AFCS PLACARDS (Continued) 10. Silk-screened on the upper right instrument panel: 11. On auxiliary power plug door and second placard on battery box: 12. On the upper right side of the aft cabin partition: (Continued Next Page) FAA APPROVED 172SPHBUS-00...
Page 78 SECTION 2 CESSNA OPERATING LIMITATIONS MODEL 172S NAV III GFC 700 AFCS PLACARDS (Continued) 13. On the center overhead flood light control switch: FAA APPROVED 172SPHBUS-00 2-28 U.S.
Page 79 CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS EMERGENCY PROCEDURES TABLE OF CONTENTS Page Introduction ..........3-5 Airspeeds For Emergency Operations.
Page 80 SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS TABLE OF CONTENTS (Continued) Page ABNORMAL LANDINGS....... . 3-16 Landing With A Flat Main Tire .
Page 81 CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS TABLE OF CONTENTS (Continued) Page AMPLIFIED EMERGENCY PROCEDURES ....3-25 Engine Failure ......... 3-25 Maximum Glide .
Page 83: Introduction
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS INTRODUCTION Section 3 provides checklist and amplified procedures for coping with emergencies that may occur. Emergencies caused by airplane or engine malfunctions are extremely rare if proper preflight inspections and maintenance are practiced.
Page 84: Emergency Procedures
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS EMERGENCY PROCEDURES Procedures in the Emergency Procedures Checklist portion of this section shown in bold faced type are immediate action items which should be committed to memory. ENGINE FAILURES ENGINE FAILURE DURING TAKEOFF ROLL 1.
Page 85: Engine Failure During Flight (Restart Procedures)
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS ENGINE FAILURES (Continued) ENGINE FAILURE DURING FLIGHT (Restart Procedures) 1. Airspeed - 68 KIAS (best glide speed) 2. FUEL SHUTOFF Valve - ON (push full in) 3. FUEL SELECTOR Valve - BOTH 4.
Page 86: Forced Landings
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS FORCED LANDINGS EMERGENCY LANDING WITHOUT ENGINE POWER 1. Pilot and Passenger Seat Backs - MOST UPRIGHT POSITION 2. Seats and Seat Belts - SECURE 3. Airspeed - 70 KIAS - Flaps UP 65 KIAS - Flaps 10°...
Page 87: Ditching
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS FORCED LANDINGS (Continued) DITCHING 1. Radio - TRANSMIT MAYDAY on 121.5 MHz, (give location, intentions and SQUAWK 7700) 2. Heavy Objects (in baggage area) - SECURE OR JETTISON (if possible) 3.
Page 88: Fires
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS FIRES DURING START ON GROUND 1. MAGNETOS Switch - START (continue cranking to start the engine) IF ENGINE STARTS 2. Power - 1800 RPM (for a few minutes) 3.
Page 89: Engine Fire In Flight
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS FIRES (Continued) ENGINE FIRE IN FLIGHT 1. Mixture Control - IDLE CUTOFF (pull full out) 2. FUEL SHUTOFF Valve - OFF (pull full out) 3. FUEL PUMP Switch - OFF 4.
Page 90: Cabin Fire
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS FIRES (Continued) ELECTRICAL FIRE IN FLIGHT (Continued) IF FIRE HAS BEEN EXTINGUISHED AND ELECTRICAL POWER IS NECESSARY FOR CONTINUED FLIGHT TO NEAREST SUITABLE AIRPORT OR LANDING AREA 10. Circuit Breakers - CHECK (for OPEN circuit(s), do not reset) 11.
Page 91: Wing Fire
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS FIRES (Continued) WING FIRE 1. LAND and TAXI Light Switches - OFF 2. NAV Light Switch - OFF 3. STROBE Light Switch - OFF 4. PITOT HEAT Switch - OFF NOTE Perform a sideslip to keep the flames away from the fuel tank and cabin.
Page 92: Icing
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS ICING INADVERTENT ICING ENCOUNTER DURING FLIGHT 1. PITOT HEAT Switch - ON 2. Turn back or change altitude (to obtain an outside air temperature that is less conducive to icing) 3.
Page 93: Static Source Blockage
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS STATIC SOURCE BLOCKAGE (ERRONEOUS INSTRUMENT READING SUSPECTED) 1. ALT STATIC AIR Valve - ON (pull full out) 2. Cabin Vents - CLOSED 3. CABIN HT and CABIN AIR Control Knobs - ON (pull full out) 4.
Page 94: Abnormal Landings
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS ABNORMAL LANDINGS LANDING WITH A FLAT MAIN TIRE 1. Approach - NORMAL 2. Wing Flaps - FULL 3. Touchdown - GOOD MAIN TIRE FIRST (hold airplane off flat tire as long as possible with aileron control) 4.
Page 95: Electrical Power Supply System Malfunctions
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS ELECTRICAL POWER SUPPLY SYSTEM MALFUNCTIONS HIGH VOLTS ANNUNCIATOR COMES ON OR M BATT AMPS MORE THAN 40 1. MASTER Switch (ALT Only) - OFF 2. Electrical Load - REDUCE IMMEDIATELY as follows: a.
Page 96 SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS ELECTRICAL POWER SUPPLY SYSTEM MALFUNCTIONS (Continued) HIGH VOLTS ANNUNCIATOR COMES ON OR M BATT AMPS MORE THAN 40 (Continued) COM1 and NAV1 - TUNE TO ACTIVE FREQUENCY COM1 MIC and NAV1 - SELECT (COM2 MIC and NAV2 will be inoperative once AVIONICS BUS 2 is selected to OFF) NOTE When AVIONICS BUS 2 is set to OFF, the following items...
Page 97: Low Volts Annunciator Comes On Below 1000 Rpm
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS ELECTRICAL POWER SUPPLY SYSTEM MALFUNCTIONS (Continued) LOW VOLTS ANNUNCIATOR COMES ON BELOW 1000 1. Throttle Control - 1000 RPM 2. LOW VOLTS Annunciator - CHECK OFF LOW VOLTS ANNUNCIATOR REMAINS ON AT 1000 RPM 3.
Page 98 SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS ELECTRICAL POWER SUPPLY SYSTEM MALFUNCTIONS (Continued) IF LOW VOLTS ANNUNCIATOR REMAINS ON (Continued) NOTE • The main battery supplies electrical power to the main and essential buses until M BUS VOLTS decreases below 20 volts.
Page 99: Air Data System Failure
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS AIR DATA SYSTEM FAILURE RED X - PFD AIRSPEED INDICATOR 1. ADC/AHRS Circuit Breakers - CHECK IN (ESS BUS and AVN BUS 1). If open, reset (close) circuit breaker. If circuit breaker opens again, do not reset.
Page 100: Autopilot Or Electric Trim Failure (If Installed)
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS AUTOPILOT OR ELECTRIC TRIM FAILURE (if installed) AP OR PTRM ANNUNCIATOR(S) COME ON 1. Control Wheel - GRASP FIRMLY (regain control of airplane) 2. A/P TRIM DISC Button - PRESS and HOLD (throughout recovery) 3.
Page 101: Vacuum System Failure
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS VACUUM SYSTEM FAILURE LOW VACUUM ANNUNCIATOR COMES ON 1. Vacuum Indicator (VAC) - CHECK EIS ENGINE PAGE (make sure vacuum pointer is in green band limits) CAUTION IF VACUUM POINTER IS OUT OF THE GREEN BAND DURING FLIGHT OR THE GYRO FLAG IS SHOWN ON THE STANDBY ATTITUDE INDICATOR, THE STANDBY ATTITUDE INDICATOR MUST NOT BE USED FOR...
Page 102 SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS HIGH CARBON MONOXIDE (CO) LEVEL ADVISORY CO LVL HIGH ANNUNCIATOR COMES ON 1. CABIN HT Control Knob - OFF (push full in) 2. CABIN AIR Control Knob - ON (pull full out) 3.
Page 103: Amplified Emergency Procedures
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS AMPLIFIED EMERGENCY PROCEDURES The following Amplified Emergency Procedures provide additional information beyond that in the Emergency Procedures Checklists portion of this section. These procedures also include information not readily adaptable to a checklist format, and material to which a pilot could not be expected to refer in resolution of a specific emergency.
Page 104: Maximum Glide
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS MAXIMUM GLIDE Figure 3-1 172SPHBUS-00 3-26 U.S.
Page 105: Forced Landings
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS FORCED LANDINGS If all attempts to restart the engine fail and a forced landing is imminent, select a suitable field and prepare for the landing as discussed under the Emergency Landing Without Engine Power checklist.
Page 106: Landing Without Elevator Control
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS LANDING WITHOUT ELEVATOR CONTROL Trim for horizontal flight with an airspeed of approximately 65 KIAS and flaps set to 20° by using throttle and elevator trim controls. Then do not change the elevator trim control setting;...
Page 107: Emergency Operation In Clouds
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS EMERGENCY OPERATION IN CLOUDS If the engine-driven vacuum pump fails in flight, the standby attitude indicator will not be accurate. The pilot must then rely on the attitude and heading information (from the AHRS) shown on the PFD indicators.
Page 108: Emergency Descent Through Clouds (Ahrs Failed)
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS EMERGENCY OPERATION IN CLOUDS (Continued) EMERGENCY DESCENT THROUGH CLOUDS (AHRS FAILED) When returning to VFR flight after a 180° turn is not practical, a descent through the clouds to VFR conditions below may be appropriate. If possible, obtain an ATC clearance for an emergency descent through the clouds.
Page 109: Recovery From Spiral Dive In The Clouds (Ahrs Failed)
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS EMERGENCY OPERATION IN CLOUDS (Continued) RECOVERY FROM SPIRAL DIVE IN THE CLOUDS (AHRS FAILED) AHRS FAILURE If a spiral is entered while in the clouds, continue as follows: 1.
Page 110: Static Source Blocked
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS STATIC SOURCE BLOCKED If erroneous readings of the static source instruments (airspeed, altimeter and vertical speed) are suspected, the alternate static source air valve (ALT STATIC AIR) should be pulled ON, thereby supplying static pressure to these instruments from the cabin.
Page 111: Rough Engine Operation Or Loss Of Power
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS ROUGH ENGINE OPERATION OR LOSS OF POWER SPARK PLUG FOULING A slight engine roughness in flight may be caused by one or more spark plugs becoming fouled by carbon or lead deposits. This may be verified by turning the MAGNETOS switch momentarily from BOTH to either L or R position.
Page 112: Engine-Driven Fuel Pump Failure
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS ROUGH ENGINE OPERATION OR LOSS OF POWER (Continued) ENGINE-DRIVEN FUEL PUMP FAILURE Failure of the engine-driven fuel pump will be shown by a sudden reduction in the fuel flow indication (FFLOW GPH) immediately before a loss of power while operating from a fuel tank containing adequate fuel.
Page 113: Low Oil Pressure
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS ROUGH ENGINE OPERATION OR LOSS OF POWER (Continued) LOW OIL PRESSURE If the low oil pressure annunciator (OIL PRESS) comes on, check the oil pressure indicator (OIL PRES on ENGINE page or OIL PSI on SYSTEM page) to confirm low oil pressure condition.
Page 114: Electrical Power Supply System Malfunctions
SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS ELECTRICAL POWER SUPPLY SYSTEM MALFUNCTIONS Malfunctions in the electrical power supply system can be detected through regular monitoring of the main battery ammeter (M BATT AMPS) and the main electrical bus voltmeter (M BUS VOLTS); however, the cause of these malfunctions is usually difficult to determine.
Page 115: Insufficient Rate Of Charge
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS ELECTRICAL POWER SUPPLY SYSTEM MALFUNCTIONS (Continued) INSUFFICIENT RATE OF CHARGE When the overvoltage sensor circuit, or other fault, opens the alternator (ALT FIELD) circuit breaker and de-energizes the alternator, a discharge (-) current will be shown on the main battery ammeter and the low voltage annunciator (LOW VOLTS) will come on.
Page 116 SECTION 3 CESSNA EMERGENCY PROCEDURES MODEL 172S NAV III GFC 700 AFCS ELECTRICAL POWER SUPPLY SYSTEM MALFUNCTIONS (Continued) INSUFFICIENT RATE OF CHARGE (Continued) Main battery life can be extended by setting the MASTER switch (ALT and BAT) to OFF and operating the equipment on the ESS BUS from the standby battery.
Page 117: High Carbon Monoxide (Co) Level Annunciation
CESSNA SECTION 3 MODEL 172S NAV III EMERGENCY PROCEDURES GFC 700 AFCS HIGH CARBON MONOXIDE (CO) LEVEL ANNUNCIATION Carbon monoxide (CO) is a colorless, odorless, tasteless product of an internal combustion engine and is always present in exhaust fumes. Even minute quantities of carbon monoxide breathed over a long period of time may lead to dire consequences.
Page 119 CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS NORMAL PROCEDURES TABLE OF CONTENTS Page Introduction ..........4-3 Airspeeds For Normal Operation .
Page 120 SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS TABLE OF CONTENTS (Continued) Page AMPLIFIED NORMAL PROCEDURES..... 4-23 Preflight Inspection.
Page 121: Introduction
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS INTRODUCTION Section 4 provides procedures and amplified instructions for normal operations using standard equipment. Normal procedures associated with optional systems can be found in Section 9, Supplements. AIRSPEEDS FOR NORMAL OPERATION Unless otherwise noted, the following speeds are based on a maximum weight of 2550 pounds and may be used for any lesser weight.
Page 122: Normal Procedures
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS NORMAL PROCEDURES PREFLIGHT INSPECTION NOTE Visually check airplane for general condition during walk- around inspection. Airplane should be parked in a normal ground attitude, refer to Figure 1-1, to make sure that fuel drain valves allow for accurate sampling.
Page 123: Preflight Inspection
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS PREFLIGHT INSPECTION (Continued) CABIN 1. Pitot Tube Cover - REMOVE (check for pitot blockage) 2. Pilot's Operating Handbook - ACCESSIBLE TO PILOT 3. Garmin G1000 Cockpit Reference Guide - ACCESSIBLE TO PILOT 4.
Page 124: Empennage
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS PREFLIGHT INSPECTION (Continued) CABIN (Continued) 17. AVIONICS Switch (BUS 1) - OFF 18. AVIONICS Switch (BUS 2) - ON 19. Aft Avionics Fan - CHECK (verify fan is heard) 20.
Page 125: Right Wing
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS PREFLIGHT INSPECTION (Continued) RIGHT WING 1. Landing/Taxi Light(s) - CHECK (condition and cleanliness of cover) (If installed) 2. Wing Tiedown - DISCONNECT 3. Main Wheel Tire - CHECK (proper inflation and general condition (weather checks, tread depth and wear, etc.)) 4.
Page 126: Nose
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS PREFLIGHT INSPECTION (Continued) NOSE 1. Fuel Strainer Quick Drain Valve (located on bottom of fuselage) - DRAIN Drain at least a cupful of fuel (using sampler cup) from valve to check for water, sediment, and proper fuel grade before each flight and after each refueling.
Page 127: Left Wing
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS PREFLIGHT INSPECTION (Continued) NOSE (Continued) 6. Nosewheel Strut and Tire - CHECK (proper inflation of strut and general condition of tire (weather checks, tread depth and wear, etc.)) 7.
Page 128: Left Wing Leading Edge
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS PREFLIGHT INSPECTION (Continued) LEFT WING Leading Edge 1. Fuel Tank Vent Opening - CHECK (blockage) 2. Stall Warning Opening - CHECK (blockage) NOTE To check the system, place a clean handkerchief over the vent opening and apply suction;...
Page 129: Before Starting Engine
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS BEFORE STARTING ENGINE 1. Preflight Inspection - COMPLETE 2. Passenger Briefing - COMPLETE 3. Seats and Seat Belts - ADJUST and LOCK (verify inertia reel locking) 4. Brakes - TEST and SET 5.
Page 130: Starting Engine (With Battery)
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS STARTING ENGINE (With Battery) 1. Throttle Control - OPEN 1/4 INCH 2. Mixture Control - IDLE CUTOFF (pull full out) 3. STBY BATT Switch: a. TEST - (hold for 10 seconds, verify that green TEST lamp does not go off) b.
Page 131: Starting Engine (With External Power)
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS STARTING ENGINE (With Battery) (Continued) 17. Oil Pressure - CHECK (verify that oil pressure increases into the GREEN BAND range in 30 to 60 seconds) 18. AMPS (M BATT and BATT S) - CHECK (verify charge shown (positive)) 19.
Page 132 SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS STARTING ENGINE (With External Power) (Continued) 17. Mixture Control - SET to FULL RICH (full forward) until stable fuel flow is indicated (approximately 3 to 5 seconds), then set to IDLE CUTOFF (full aft) position.
Page 133: Before Takeoff
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS STARTING ENGINE (With External Power) (Continued) M BATT Ammeter - CHECK (verify battery charging, amps positive) g. LOW VOLTS Annunciator - CHECK (verify annunciator is not shown) WARNING IF M BATT AMMETER DOES NOT SHOW POSITIVE CHARGE (+ AMPS), OR LOW VOLTS ANNUNCIATOR DOES NOT GO OFF, REMOVE THE BATTERY FROM...
Page 134 SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS BEFORE TAKEOFF (Continued) 13. Autopilot - ENGAGE (if installed) (push AP button on either PFD or MFD bezel) 14. Flight Controls - CHECK (verify autopilot can be overpowered in both pitch and roll axes) 15.
Page 135 CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS BEFORE TAKEOFF (Continued) 27. CDI Softkey - SELECT NAV SOURCE CAUTION THE G1000 HSI SHOWS A COURSE DEVIATION INDICATOR FOR THE SELECTED GPS, NAV 1 OR NAV 2 NAVIGATION SOURCE.
Page 136: Takeoff
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS TAKEOFF NORMAL TAKEOFF 1. Wing Flaps - UP - 10° (10° preferred) 2. Throttle Control - FULL (push full in) 3. Mixture Control - RICH (above 3000 feet pressure altitude, lean for maximum RPM) 4.
Page 137: Enroute Climb
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS ENROUTE CLIMB 1. Airspeed - 70 - 85 KIAS 2. Throttle Control - FULL (push full in) 3. Mixture Control - RICH (above 3000 feet pressure altitude, lean for maximum RPM) NOTE For maximum performance climb speeds, refer to Section...
Page 138: Descent
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS DESCENT 1. Power - AS DESIRED 2. Mixture - ADJUST (if necessary to make engine run smoothly) 3. Altimeters: a. PFD (BARO) - SET b. Standby Altimeter - SET 4.
Page 139: Before Landing
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS BEFORE LANDING 1. Pilot and Passenger Seat Backs - MOST UPRIGHT POSITION 2. Seats and Seat Belts - SECURED and LOCKED 3. FUEL SELECTOR Valve - BOTH 4. Mixture Control - RICH 5.
Page 140: Balked Landing
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS LANDING (Continued) BALKED LANDING 1. Throttle Control - FULL (push full in) 2. Wing Flaps - RETRACT to 20° 3. Climb Speed - 60 KIAS 4. Wing Flaps - 10° (as obstacle is cleared), then UP (after reaching a safe altitude and 65 KIAS) AFTER LANDING 1.
Page 141: (Continued Next Page)
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS AMPLIFIED NORMAL PROCEDURES PREFLIGHT INSPECTION The preflight inspection, described in Figure 4-1 and adjacent checklist, is required prior to each flight. If the airplane has been in extended storage, has had recent major maintenance, or has been operated from rough runways, a more extensive exterior inspection is recommended.
Page 142 SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS PREFLIGHT INSPECTION (Continued) Outside storage for long periods may result in dust and dirt accumulation on the induction air filter, obstructions in airspeed system lines, water contaminants in fuel tanks, and insect/bird/rodent nests in any opening.
Page 143 CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS STARTING ENGINE In cooler weather, the engine compartment temperature drops off rapidly following engine shutdown and the injector nozzle lines remain nearly full of fuel. In warmer weather, engine compartment temperatures may increase rapidly following engine shutdown, and fuel in the lines will vaporize and escape into the intake manifold.
Page 144: Starting Engine
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS STARTING ENGINE (Continued) RECOMMENDED STARTER DUTY CYCLE Operate the starter motor for 10 seconds followed by a 20 second cool down period. This cycle can be repeated two additional times, followed by a ten minute cool down period before resuming cranking.
Page 145: Fuel Vapor Procedures
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS FUEL VAPOR PROCEDURES The engine fuel system can cause fuel vapor formation on the ground during warm weather. This will generally occur when the outside ambient air temperature is above 80°F. Vapor formation may increase when the engine fuel flows are lower at idle and taxi engine speeds.
Page 146: Taxiing
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS TAXIING When taxiing, it is important that speed and use of brakes be held to a minimum and that all controls be utilized, refer to Figure 4-2, Taxiing Diagram, to maintain directional control and balance.
Page 147 CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS TAXIING (Continued) TAXIING DIAGRAM NOTE Strong quartering tail winds require caution. Avoid sudden bursts of the throttle and sharp braking when the airplane is in this attitude. Use the steerable nosewheel and rudder to maintain direction.
Page 148: Before Takeoff
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS BEFORE TAKEOFF WARM UP If the engine idles, with the throttle against the idle stop, (approximately 675 RPM) and accelerates smoothly, the engine is warm enough for takeoff. Since the engine is closely cowled for efficient in-flight engine cooling, the airplane should be pointed into the wind to avoid overheating during prolonged engine operation on the ground.
Page 149: Elevator Trim
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS BEFORE TAKEOFF (Continued) ELEVATOR TRIM The elevator trim tab is in the takeoff position when the trim pointer is aligned with the index mark on the pedestal cover. Adjust the trim wheel during flight as necessary to make control wheel forces more neutral.
Page 150: Wing Flap Settings
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS TAKEOFF (Continued) WING FLAP SETTINGS Normal takeoffs use wing flaps UP - 10°. Using 10° wing flaps reduces the ground roll and total distance over an obstacle by approximately 10 percent.
Page 151: Enroute Climb
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS ENROUTE CLIMB Normal enroute climbs are performed with flaps up, at full throttle and 75 to 85 KIAS for the best combination of performance, visibility and engine cooling. The mixture should be full rich during climb at altitudes up to 3000 feet pressure altitude.
Page 152: Cruise
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS CRUISE Normal cruise is performed between 45% and 75% power. The engine RPM and corresponding fuel consumption for various altitudes can be determined by using the data in Section 5. NOTE Cruise flight should use 75% power as much as possible until the engine has operated for a total of 50 hours or oil...
Page 153 CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS CRUISE (Continued) CRUISE PERFORMANCE TABLE CONDITIONS: Standard Conditions Zero Wind ALTITUDE 75% POWER 65% POWER 55% POWER FEET KTAS NMPG KTAS NMPG KTAS NMPG Sea Level 11.2 12.0 12.8 4000 11.7...
Page 154: Leaning Using Exhaust Gas Temperature (Egt)
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS CRUISE (Continued) LEANING USING EXHAUST GAS TEMPERATURE (EGT) The cruise performance data in this POH is based on the recommended lean mixture setting determined from the maximum or peak EGT at power settings of 75% MCP and lower.
Page 155 (-) value, whether on the lean or rich side of the peak. NOTE The 172S engine manufacturer, Textron Lycoming, has not approved operation of the engine at fuel flow rates (mixture settings) less than necessary to reach peak EGT in the leanest cylinder (the first cylinder to reach peak EGT).
Page 156 SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS CRUISE (Continued) LEANING USING EXHAUST GAS TEMPERATURE (EGT) (Continued) EXHAUST GAS TEMPERATURE (EGT) EXHAUST GAS MIXTURE DESCRIPTION TEMPERATURE (EGT) RECOMMENDED LEAN (Pilot’s Operating Handbook) 50°F Rich of Peak EGT BEST ECONOMY Peak EGT Figure 4-4...
Page 157: Fuel Savings Procedures For Flight Training Operations
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS CRUISE (Continued) FUEL SAVINGS PROCEDURES FOR FLIGHT TRAINING OPERATIONS For best fuel economy during flight training operations, the following procedures are recommended. 1. After engine start and for all ground operations, set the throttle to 1200 RPM and lean the mixture for maximum RPM.
Page 158: Stalls
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS STALLS The stall characteristics are conventional and aural warning is provided by a stall warning horn which sounds between 5 and 10 knots above the stall in all configurations. Power off stall speeds at maximum weight for both forward and aft C.G.
Page 159 CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS SPINS (Continued) It is recommended that entries be accomplished at high enough altitude that recoveries are completed 4000 feet or more Above Ground Level (AGL). At least 1000 feet of altitude loss should be allowed for a 1-turn spin and recovery, while a 6-turn spin and recovery may require somewhat more than twice that amount.
Page 160 SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS SPINS (Continued) Regardless of how many turns the spin is held or how it is entered, the following recovery technique should be used: 1. VERIFY THAT THROTTLE IS IN IDLE POSITION AND AILERONS ARE NEUTRAL.
Page 161: Landing
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS LANDING NORMAL LANDING Normal landing approaches can be made with power on or power off with any flap setting within the flap airspeed limits. Surface winds and air turbulence are usually the primary factors in determining the most comfortable approach speeds.
Page 162: Crosswind Landing
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS LANDING (Continued) CROSSWIND LANDING When landing in a strong crosswind, use the minimum flap setting required for the field length. If flap settings greater than 20° are used in sideslips with full rudder deflection, some elevator oscillation may be felt at normal approach speeds.
Page 163: Cold Weather Operations
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS COLD WEATHER OPERATIONS Special consideration should be given to the operation of the airplane fuel system during the winter season or prior to any flight in cold temperatures. Proper preflight draining of the fuel system is especially important and will eliminate any free water accumulation.
Page 164: Starting
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS COLD WEATHER OPERATION (Continued) STARTING When air temperatures are below 20°F (-6°C), use an external preheater and an external power source whenever possible to obtain positive starting and to reduce wear and abuse to the engine and electrical system.
Page 165: Winterization Kit
CESSNA SECTION 4 MODEL 172S NAV III NORMAL PROCEDURES GFC 700 AFCS COLD WEATHER OPERATION (Continued) STARTING (Continued) Cold weather starting procedures are the same as the normal starting procedures. However, to conserve battery power the beacon light can be left off until the engine is started. Use caution to prevent inadvertent forward movement of the airplane during starting when parked on snow or ice.
Page 166: Hot Weather Operations
SECTION 4 CESSNA NORMAL PROCEDURES MODEL 172S NAV III GFC 700 AFCS HOT WEATHER OPERATIONS Refer to the general warm temperature starting information under Starting Engine in this section. Avoid prolonged engine operation on the ground. NOISE CHARACTERISTICS The certified takeoff noise level for the Model 172S at 2550 pounds maximum weight is 75.1 dB(A) per 14 CFR 36 Appendix G (through Amendment 36-21) and 78.2 dB(A) per ICAO Annex 16 Chapter 10 (through Amendment 4).
Page 167 CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS PERFORMANCE TABLE OF CONTENTS Page Introduction ..........5-3 Use of Performance Charts .
Page 169: Introduction
CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS INTRODUCTION Performance data charts on the following pages are presented so that you may know what to expect from the airplane under various conditions and to facilitate the planning of flights in detail with reasonable accuracy.
Page 170: Sample Problem
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS SAMPLE PROBLEM The following sample flight problem utilizes information from the various charts to determine the predicted performance data for a typical flight. Assume the following information has already been determined: AIRPLANE CONFIGURATION: Takeoff weight 2550 Pounds...
Page 171: Takeoff
CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS SAMPLE PROBLEM (Continued) TAKEOFF The takeoff distance chart, Figure 5-5, should be consulted, keeping in mind that distances shown are based on the short field technique. Conservative distances can be established by reading the chart at the next higher value of weight, altitude and temperature.
Page 172: Cruise
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS SAMPLE PROBLEM (Continued) CRUISE The cruising altitude should be selected based on a consideration of trip length, winds aloft and the airplane's performance. A typical cruising altitude and the expected wind enroute have been given for this sample problem.
Page 173: Fuel Required
CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS SAMPLE PROBLEM (Continued) FUEL REQUIRED The total fuel requirement for the flight may be estimated using the performance information in Figure 5-7 and Figure 5-8. For this sample problem, the time, fuel and distance to climb may be determined from Figure 5-7 for normal climb.
Page 174 SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS SAMPLE PROBLEM (Continued) FUEL REQUIRED (Continued) With an expected 10 knot head wind, the ground speed for cruise is predicted to be: 117 Knots -10 Knots 107 Knots Therefore, the time required for the cruise portion of the trip is: 342 Nautical Miles = 3.2 Hours 107 Knots The fuel required for cruise is:...
Page 175: Landing
CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS SAMPLE PROBLEM (Continued) LANDING A procedure similar to takeoff should be used for estimating the landing distance at the destination airport. Figure 5-11 presents landing distance information for the short field technique. The distances corresponding to 2000 feet and 30°C are as follows: Ground roll 650 Feet...
Page 176: Airspeed Calibration - Normal Static Source
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS AIRSPEED CALIBRATION NORMAL STATIC SOURCE CONDITIONS: Power required for level flight or maximum power descent. Flaps 50 60 70 80 90 100 110 120 130 140 150 160 KIAS 56 62 70 78 87 97 107 117 127 137 147 157 KCAS Flaps...
Page 177 CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS NOTE Windows and ventilators closed. Cabin heat, cabin air and defroster on maximum. Figure 5-1 (Sheet 2)* 172SPHBUS-01 5-11 U.S.
Page 178 SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS TEMPERATURE CONVERSION CHART Figure 5-2 172SPHBUS-00 5-12 U.S.
Page 179 CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS Figure 5-3* 172SPHBUS-02 5-13 U.S.
Page 180: Crosswind Component
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS CROSSWIND COMPONENT MAXIMUM DEMONSTRATED CROSSWIND VELOCITY Takeoff, Flaps UP ......20 KNOTS Takeoff, Flaps 10°...
Page 181: Short Field Takeoff Distance At 2550 Pounds
CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS SHORT FIELD TAKEOFF DISTANCE AT 2550 POUNDS CONDITIONS: Flaps 10° Full Throttle prior to brake release. Paved, Level, Dry Runway Lift Off: 51 KIAS Zero Wind Speed at 50 Feet: 56 KIAS 0°C 10°C...
Page 182: Short Field Takeoff Distance At 2400 Pounds
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS SHORT FIELD TAKEOFF DISTANCE AT 2400 POUNDS CONDITIONS: Flaps 10° Full Throttle prior to brake release. Paved, Level, Dry Runway Lift Off: 48 KIAS Zero Wind Speed at 50 Feet: 54 KIAS 0°C 10°C...
Page 183: Short Field Takeoff Distance At 2200 Pounds
CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS SHORT FIELD TAKEOFF DISTANCE AT 2200 POUNDS CONDITIONS: Flaps 10° Full Throttle prior to brake release. Paved, Level, Dry Runway Lift Off: 44 KIAS Zero Wind Speed at 50 Feet: 50 KIAS 0°C 10°C...
Page 184: Maximum Rate Of Climb At 2550 Pounds
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS MAXIMUM RATE OF CLIMB AT 2550 POUNDS CONDITIONS: Flaps UP Full Throttle Pressure Rate of Climb - FPM Climb Speed Altitude - KIAS -20°C 0°C 20°C 40°C Feet Sea Level 2000 4000 6000...
Page 185: Time, Fuel And Distance To Climb At 2550 Pounds
CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS TIME, FUEL AND DISTANCE TO CLIMB AT 2550 POUNDS CONDITIONS: Flaps UP Full Throttle Standard Temperature From Sea Level Pressure Climb Rate of Temp Altitude Speed Climb Time Fuel Used Distance °...
Page 186: Cruise Performance
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS CRUISE PERFORMANCE CONDITIONS: 2550 Pounds Recommended Lean Mixture 20°C BELOW STANDARD 20°C ABOVE Pressure STANDARD TEMP TEMPERATURE STANDARD TEMP Altitude Feet MCP KTAS GPH MCP KTAS GPH MCP KTAS GPH 2000 2550 11.1...
Page 187 CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS CRUISE PERFORMANCE CONDITIONS: 2550 Pounds Recommended Lean Mixture 20°C BELOW STANDARD 20°C ABOVE Pressure STANDARD TEMP TEMPERATURE STANDARD TEMP Altitude Feet MCP KTAS GPH MCP KTAS GPH MCP KTAS GPH 8000 2700 11.1...
Page 188: Range Profile
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS RANGE PROFILE 45 MINUTES RESERVE 53 GALLONS USABLE FUEL CONDITIONS: 2550 Pounds Standard Temperature Recommended Lean Mixture for Cruise at all altitudes Zero Wind NOTE • This chart allows for the fuel used for engine start, taxi, takeoff and climb, and the distance during a normal climb.
Page 189: Endurance Profile
CESSNA SECTION 5 MODEL 172S NAV III PERFORMANCE GFC 700 AFCS ENDURANCE PROFILE 45 MINUTES RESERVE 53 GALLONS USABLE FUEL CONDITIONS: 2550 Pounds Standard Temperature Recommended Lean Mixture for Cruise at all altitudes NOTE This chart allows for the fuel used for engine start, taxi, takeoff and climb, and the time during a normal climb.
Page 190: Short Field Landing Distance At 2550 Pounds
SECTION 5 CESSNA PERFORMANCE MODEL 172S NAV III GFC 700 AFCS SHORT FIELD LANDING DISTANCE AT 2550 POUNDS CONDITIONS: Flaps FULL Zero Wind Power IDLE Paved, Level, Dry Runway Maximum Braking Speed at 50 ft: 61 KIAS 0°C 10°C 20°C 30°C 40°C Total...
Page 191 CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST WEIGHT AND BALANCE/ EQUIPMENT LIST TABLE OF CONTENTS Page Introduction ..........6-3 Airplane Weighing Procedures .
Page 193: Introduction
CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST INTRODUCTION This section describes the procedure for establishing the basic empty weight and moment of the airplane. Sample forms are provided for reference. Procedures for calculating the weight and moment for various operations are also provided.
Page 194 SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS AIRPLANE WEIGHING PROCEDURES (Continued) 2. Level: a. Place scales under each wheel (minimum scale capacity, 1000 pounds). b. Deflate the nose tire and/or lower or raise the nose strut to properly center the bubble in the level (Refer to Figure 6-1 Sheet 1).
Page 195: Airplane Weighing Form
CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST AIRPLANE WEIGHING FORM Figure 6-1 (Sheet 1 of 2) 172SPHBUS-00 U.S.
Page 196 SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS AIRPLANE WEIGHING FORM Figure 6-1 (Sheet 2) 172SPHBUS-00 U.S.
Page 197: Sample Weight And Balance Record
CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST SAMPLE WEIGHT AND BALANCE RECORD Figure 6-2 172SPHBUS-00 U.S.
Page 198: Weight And Balance
SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS WEIGHT AND BALANCE The following information will enable you to operate your Cessna within the prescribed weight and center of gravity limitations. To determine weight and balance, use the Sample Loading Problem (Figure 6-3), Loading Graph (Figure 6-4), and Center of Gravity Moment Envelope (Figure 6-7) as follows: Enter the appropriate basic empty weight and moment/1000 from the...
Page 199: Baggage Tiedown
CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST WEIGHT AND BALANCE (Continued) BAGGAGE TIEDOWN A nylon baggage net having four tiedown straps is provided as standard equipment to secure baggage on the cabin floor aft of the rear seat (baggage area A) and in the aft baggage area (baggage area B).
Page 200: Sample Loading Problem
SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS SAMPLE LOADING PROBLEM WEIGHT AND MOMENT TABULATION SAMPLE YOUR ITEM DESCRIPTION AIRPLANE AIRPLANE Weight Moment Weight Moment (lbs) (lb-ins/ (lbs) (lb-ins/ 1000) 1000) 1 - Basic Empty Weight (Use the data pertaining to your airplane as it is presently equipped.
Page 201 CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST SAMPLE LOADING PROBLEM NOTE When several loading configurations are representative of your operations, it may be useful to fill out one or more of the above columns so specific loadings are available at a glance.
Page 202: Loading Graph
SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS LOADING GRAPH NOTE Line representing adjustable seats shows the pilot and front seat passenger center of gravity on adjustable seats positioned for average occupant. Refer to the Loading Arrangements diagram for forward and aft limits of occupant C.G.
Page 203: Loading Arrangements
CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST LOADING ARRANGEMENTS *Pilot and front seat passenger center of gravity on adjustable seats positioned for average occupant. Numbers in parentheses indicate forward and aft limits of occupant center of gravity range. **Arm measured to the center of the areas shown.
Page 204: Internal Cabin Dimensions
SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS INTERNAL CABIN DIMENSIONS NOTE • Maximum allowable floor loading is 200 pounds per square foot. • All dimensions shown are in inches. Figure 6-6 172SPHBUS-00 6-14 U.S.
Page 205: Center Of Gravity Moment Envelope
CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST CENTER OF GRAVITY MOMENT ENVELOPE Figure 6-7 172SPHBUS-00 6-15 U.S.
Page 206 SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS CENTER OF GRAVITY LIMITS Figure 6-8 172SPHBUS-00 6-16 U.S.
Page 207: Comprehensive Equipment List
CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST COMPREHENSIVE EQUIPMENT LIST Figure 6-9 is a comprehensive list of all Cessna equipment which is available for the Model 172S airplane equipped with Garmin G1000 Integrated Cockpit System and GFC 700 Autopilot (if installed) (Serials 172S10468, 172S10507, 172S10640 and 172S10656 and On).
Page 209 CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST ITEM NO EQUIPMENT LIST DESCRIPTION DRAWING INS. 11 - PAINT AND PLACARDS 11-01-S PAINT, OVERALL WHITE WITH COLOR STRIPE 0500531 19.2* 95.4* - OVERALL WHITE COLOR 18.4 91.5 - COLOR STRIPING...
Page 210 SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS ITEM NO EQUIPMENT LIST DESCRIPTION DRAWING INS. 25 - EQUIPMENT/FURNISHINGS 25-01-R SEAT, PILOT, ADJUSTABLE, LEATHER/VINYL 0719025-4 33.0 41.5 COVER 25-02-S SEAT, FRONT PASSENGER, ADJUSTABLE, 0719025-4 33.0 41.5 LEATHER/VINYL COVER...
Page 211 CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST ITEM NO EQUIPMENT LIST DESCRIPTION DRAWING INS. 26 - FIRE PROTECTION 26-01-S FIRE EXTINGUISHER 0501011-2 5.3* 43.0* - FIRE EXTINGUISHER, HAND TYPE A352GS 44.0 - MOUNTING CLAMP AND HARDWARE 1290010-1 42.2 27 - FLIGHT CONTROLS...
Page 212 SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS ITEM NO EQUIPMENT LIST DESCRIPTION DRAWING INS. 33 - LIGHTS 33-01-S MAP LIGHT IN CONTROL WHEEL 0706015 22.0 33-02-S COURTESY LIGHTS UNDER WING 0521101-8 61.0 33-03-S FLASHING BEACON 0506003-6...
Page 213 CESSNA SECTION 6 MODEL 172S NAV III WEIGHT AND BALANCE/ GFC 700 AFCS EQUIPMENT LIST ITEM NO EQUIPMENT LIST DESCRIPTION DRAWING INS. 37 - VACUUM 37-01-R ENGINE DRIVEN VACUUM PUMP - VACUUM PUMP - AA3215CC 0501135 -5.0 - COOLING SHROUD 1201998-1 -5.6 - FILTER...
Page 214 SECTION 6 CESSNA WEIGHT AND BALANCE/ MODEL 172S NAV III EQUIPMENT LIST GFC 700 AFCS ITEM NO EQUIPMENT LIST DESCRIPTION DRAWING INS. 73 - ENGINE FUEL AND CONTROL 73-01-R FUEL FLOW TRANDUCER - 680501K 0501168 -22.6 77 - ENGINE INDICATING 77-01-R ENGINE TACHOMETER SENSOR - 1A3C-2 0501168...
Page 215 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS AIRPLANE AND SYSTEMS DESCRIPTION TABLE OF CONTENTS Page Introduction ..........7-5 Airframe .
Page 216 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS TABLE OF CONTENTS (Continued) Page Cylinder Head Temperature ......7-34 Exhaust Gas Temperature .
Page 217 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS TABLE OF CONTENTS (Continued) Page Lighting Systems ........7-59 Exterior Lighting .
Page 219 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS INTRODUCTION This section provides description and operation of the airplane and its systems. Some equipment described herein is optional and may not be installed in the airplane. Refer to Section 9, Supplements, for details of other optional systems and equipment.
Page 220: Airframe
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS AIRFRAME (Continued) The rudder is constructed of a formed leading edge skin and spar with attached hinge brackets and ribs, a center spar, a wrap around skin, and a ground adjustable trim tab at the base of the trailing edge.
Page 221: Flight Controls
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS FLIGHT CONTROLS The airplane's flight control system, refer to Figure 7-1, consists of conventional aileron, rudder, and elevator control surfaces. The control surfaces are manually operated through cables and mechanical linkage using a control wheel for the ailerons and elevator, and rudder/brake pedals for the rudder.
Page 222 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FLIGHT CONTROLS AND TRIM SYSTEM Figure 7-1* (Sheet 1 of 2) 172SPHBUS-02 U.S.
Page 223 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS FLIGHT CONTROLS AND TRIM SYSTEMS Figure 7-1* (Sheet 2) 172SPHBUS-02 U.S.
Page 224: Instrument Panel
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS INSTRUMENT PANEL The instrument panel, refer to Figure 7-2, is of all metal construction and is installed in sections so equipment can be easily removed for maintenance.
Page 225: Center Panel Layout
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS INSTRUMENT PANEL (Continued) PILOT PANEL LAYOUT (Continued) Switches for the airplane electrical systems and equipment are found on an internally lighted subpanel found below the lower left corner of the PFD.
Page 226 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS INSTRUMENT PANEL (Continued) CENTER PANEL LAYOUT (Continued) The standby instrument cluster is in the center instrument panel below the audio panel. A conventional (mechanical) airspeed indicator and a sensitive aneroid altimeter are on each side of the vacuum-powered attitude indicator.
Page 227: Right Panel Layout
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS INSTRUMENT PANEL (Continued) RIGHT PANEL LAYOUT The Emergency Locator Transmitter (ELT) remote switch (ON/ARM/ TEST RESET) is positioned at the upper inboard corner of the right panel adjacent to the MFD.
Page 228 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS INSTRUMENT PANEL Figure 7-2 172SPHBUS-00 7-14 U.S.
Page 229 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS INSTRUMENT PANEL 1. MASTER Switch (ALT and BAT) 2. STBY BATT Switch 3. STBY BATT Test Annunciator 4. AVIONICS Switch (BUS 1 and BUS 2) 5. Primary Flight Display 6.
Page 230: Flight Instruments
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FLIGHT INSTRUMENTS The G1000 Integrated Cockpit System primary flight instrument indications are shown on the PFD. The primary flight instruments are arranged on the PFD in the basic T configuration. The Attitude Indicator (AI) and Horizontal Situation Indicator (HSI) are centered vertically on the PFD and are conventional in appearance and operation.
Page 231: Attitude Indicator
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS FLIGHT INSTRUMENTS (Continued) ATTITUDE INDICATOR The G1000 attitude indicator is shown on the upper center of the PFD. The attitude indication data is provided by the Attitude and Heading Reference System (AHRS).
Page 232: Airspeed Indicator
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FLIGHT INSTRUMENTS (Continued) AIRSPEED INDICATOR The G1000 vertical tape airspeed indicator is shown along the upper left side of the PFD. The airspeed indication data is provided by the air data computer unit.
Page 233: Horizontal Situation Indicator
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS FLIGHT INSTRUMENTS (Continued) HORIZONTAL SITUATION INDICATOR The Horizontal Situation Indicator (HSI) is found along the lower center area of the PFD. The heading indication data is provided by the AHRS and magnetometer units.
Page 234: Vertical Speed Indicator
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FLIGHT INSTRUMENTS (Continued) HORIZONTAL SITUATION INDICATOR (Continued) WARNING WHEN THE AUTOPILOT IS ENGAGED IN NAV, APR OR BC OPERATING MODES, IF THE HSI NAVIGATION SOURCE IS CHANGED MANUALLY, USING THE CDI SOFTKEY, THE CHANGE WILL INTERRUPT THE NAVIGATION SIGNAL TO THE AUTOPILOT AND WILL CAUSE THE AUTOPILOT TO REVERT TO ROL MODE...
Page 235: Ground Control
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS GROUND CONTROL Effective ground control while taxiing is accomplished through nosewheel steering by using the rudder pedals; left rudder pedal to steer left and right rudder pedal to steer right. When a rudder pedal is depressed, a spring loaded steering bungee, which is connected to the nose gear and to the rudder bars, will turn the nosewheel through an arc of approximately 10°...
Page 236: Wing Flap System
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS WING FLAP SYSTEM The single slot type wing flaps, refer to Figure 7-3, are extended or retracted by positioning the wing flap control lever on the instrument panel to the desired flap deflection position.
Page 237: Landing Gear System
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS LANDING GEAR SYSTEM The landing gear is of the tricycle type, with a steerable nosewheel and two main wheels. Wheel fairings are standard equipment for both the main wheels and nosewheel.
Page 238: Seats
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS SEATS The seating arrangement consists of two vertically adjusting crew seats for the pilot and front seat passenger, and a single bench seat with adjustable back for rear seat passengers. Seats used for the pilot and front seat passenger are adjustable forward and aft, and up and down.
Page 239 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS INTEGRATED SEAT BELT/SHOULDER HARNESS All seat positions are equipped with integrated seat belts/shoulder harness assemblies, Refer to Figure 7-4. The design incorporates an overhead inertia reel for the shoulder portion, and a retractor assembly for the lap portion of the belt.
Page 240: Integrated Seat Belt/Shoulder Harness
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS INTEGRATED SEAT BELT/SHOULDER HARNESS Figure 7-4* 172SPHBUS-01 7-26 U.S.
Page 241: Entrance Doors And Cabin Windows
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ENTRANCE DOORS AND CABIN WINDOWS Entry to and exit from the airplane is accomplished through either of two entry doors, one on each side of the cabin, at the front seat positions, Refer to Section 6 for cabin and cabin door dimensions.
Page 242: Control Locks
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ENTRANCE DOORS AND CABIN WINDOWS (Continued) Exit from the airplane is accomplished by rotating the door handle from the LOCK position, past the CLOSE position, aft to the OPEN position and pushing the door open.
Page 243: Engine Controls
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ENGINE The airplane is powered by a direct drive, horizontally opposed, four cylinder, overhead valve, air cooled, fuel injected engine with a wet sump lubrication system. The engine is a Lycoming Model IO-360-L2A rated at 180 horsepower at 2700 RPM.
Page 244 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ENGINE (Continued) ENGINE INSTRUMENTS The G1000 Engine Indication System (EIS) provides graphical indicators and numeric values for engine, fuel, and electrical system parameters to the pilot. The EIS is shown in a vertical strip on the left side of the PFD during engine starts and on the MFD during normal operation.
Page 245 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ENGINE (Continued) ENGINE INSTRUMENTS (Continued) RPM (TACHOMETER) Engine speed (RPM) is shown by the tachometer indicator found on all EIS pages. The tachometer indicator uses a circular scale with moving pointer and a digital value.
Page 246 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ENGINE (Continued) ENGINE INSTRUMENTS (Continued) FUEL FLOW Fuel flow is shown on the ENGINE page by the FFLOW GPH horizontal indicator. The indicator range is from 0 to 20 gallons per hour (GPH) with 2 GPH graduations, with a green band from 0 to 12 GPH.
Page 247 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ENGINE (Continued) ENGINE INSTRUMENTS (Continued) OIL PRESSURE (Continued) In cold weather, the oil pressure will initially be high (close to the upper red band when the engine is started). As the engine and oil warm up, the oil pressure will come down into the green band range.
Page 248: Cylinder Head Temperature
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ENGINE (Continued) ENGINE INSTRUMENTS (Continued) CYLINDER HEAD TEMPERATURE Cylinder head temperature (CHT) for all four cylinders are shown on the LEAN page. The cylinder with the hottest CHT is indicated by a cyan bar graph.
Page 249: New Engine Break-In And Operation
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ENGINE (Continued) NEW ENGINE BREAK-IN AND OPERATION The engine run-in was accomplished at the factory and is ready for the full range of use. It is suggested that cruising be accomplished at 75% power as much as practicable until a total of 50 hours has accumulated or oil consumption has stabilized.
Page 250: Ignition And Starter System
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ENGINE (Continued) IGNITION AND STARTER SYSTEM Engine ignition is provided by two engine driven magnetos, and two spark plugs in each cylinder. The left magneto fires the upper left and lower right spark plugs, and the right magneto fires the lower left and upper right spark plugs.
Page 251: Exhaust System
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ENGINE (Continued) EXHAUST SYSTEM Exhaust gas from each cylinder passes through a riser assembly to a common muffler, located below the engine, and then overboard through a single tailpipe.
Page 252: Fuel System
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FUEL SYSTEM The airplane fuel system, refer to Figure 7-6, consists of two vented integral fuel tanks (one tank in each wing), three-position selector valve, fuel reservoir tank, electrically-driven auxiliary fuel pump, fuel shutoff valve, and a fuel strainer.
Page 253: Fuel Distribution
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS FUEL SYSTEM (Continued) FUEL DISTRIBUTION Fuel flows by gravity from the two wing tanks to a three-position fuel selector valve, labeled BOTH, RIGHT and LEFT, and on to the fuel reservoir tank.
Page 254 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FUEL SYSTEM (Continued) FUEL INDICATING SYSTEM (Continued) The fuel quantity indicators detect low fuel conditions and incorrect sensor outputs. When fuel quantity is less than 5 gallons indicated (and remains less than this level for more than 60 seconds), LOW FUEL L (left) and/or LOW FUEL R (right) will be displayed in amber on the PFD and a tone will sound.
Page 255: Fuel Calculations
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS FUEL SYSTEM (Continued) FUEL CALCULATIONS NOTE Fuel calculations do not use the airplane’s fuel quantity indicators and are calculated from the last time the fuel was reset.
Page 256 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FUEL SYSTEM (Continued) Figure 7-6 172SPHBUS-00 7-42 U.S.
Page 257: Auxiliary Fuel Pump Operation
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS FUEL SYSTEM (Continued) AUXILIARY FUEL PUMP OPERATION The auxiliary fuel pump is used primarily for priming the engine before starting. Priming is accomplished through the fuel injection system. The engine may be flooded if the auxiliary FUEL PUMP switch is accidentally placed in the ON position for prolonged periods, with MASTER Switch ON and mixture rich, with the engine stopped.
Page 258: Fuel Return System
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FUEL SYSTEM (Continued) FUEL RETURN SYSTEM A fuel return system was incorporated to improve engine operation during extended idle operation in hot weather environments. The major components of the system include an orifice fitting located in the top of the fuel-air control unit (fuel servo), fuel return line, with check valve, and a fuel reservoir tank.
Page 259: Fuel Selector Valve
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS FUEL SYSTEM (Continued) FUEL SELECTOR VALVE The fuel selector is a three-position selector valve, labeled BOTH, RIGHT and LEFT. The fuel selector valve should be in the BOTH position for takeoff, climb, landing, and maneuvers that involve prolonged slips or skids of more than 30 seconds.
Page 260: Fuel Drain Valves
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS FUEL SYSTEM (Continued) FUEL DRAIN VALVES The fuel system is equipped with drain valves to provide a means for the examination of fuel in the system for contamination and grade. The system should be examined before each flight and after each refueling, by using the sampler cup provided to drain fuel from each wing tank sump, the fuel reservoir tank sump, the fuel selector valve drain and the...
Page 261: Electrical System
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ELECTRICAL SYSTEM The airplane is equipped with a 28-volt direct current (DC) electrical system, Refer to Figure 7-7. A belt-driven 60 ampere alternator powers the system. A 24-volt main storage battery is located inside the engine cowling on the left firewall.
Page 262 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ELECTRICAL SYSTEM (Continued) Figure 7-7 (Sheet 1 of 3) 172SPHBUS-00 7-48 U.S.
Page 263 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ELECTRICAL SYSTEM (Continued) Figure 7-7* (Sheet 2) 172SPHBUS-02 7-49 U.S.
Page 264 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ELECTRICAL SYSTEM (Continued) Figure 7-7 (Sheet 3) 172SPHBUS-00 7-50 U.S.
Page 265: G1000 Annunciator Panel
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ELECTRICAL SYSTEM (Continued) G1000 ANNUNCIATOR PANEL All system alerts, cautions and warnings are shown on the right side of the PFD screen adjacent to the vertical speed indicator. The following annunciations are supported: OIL PRESSURE LOW VACUUM...
Page 266: Standby Battery Switch
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ELECTRICAL SYSTEM (Continued) STANDBY BATTERY SWITCH The STBY BATT master switch is a three position (ARM-OFF-TEST) switch that tests and controls the standby battery system. The energy level of the battery shall be checked before starting the engine, Refer to Section 4, by placing the switch in the momentary TEST position and observing the correct illumination of the TEST lamp found to the right of...
Page 267 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ELECTRICAL SYSTEM (Continued) ELECTRICAL SYSTEM MONITORING ANNUNCIATIONS BUS VOLTAGE (VOLTMETERS) Voltage indication (VOLTS) for the main and essential buses is provided at the bottom of the EIS bar, along the left margin of the MFD or PFD, labeled M BUS E.
Page 268: Ammeters
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ELECTRICAL SYSTEM (Continued) ELECTRICAL SYSTEM MONITORING ANNUNCIATIONS (Continued) AMMETERS Current indication (AMPS) for both the main and standby batteries is provided at the bottom of the EIS bar, along the left margin of the MFD or PFD, labeled M BATT S.
Page 269: Low Voltage Annunciation
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ELECTRICAL SYSTEM (Continued) ELECTRICAL SYSTEM MONITORING ANNUNCIATIONS (Continued) LOW VOLTAGE ANNUNCIATION A signal from the ACU, located inside the power distribution module, provides the trigger for a red LOW VOLTS annunciation shown on the PFD.
Page 270: High Voltage Annunciation
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ELECTRICAL SYSTEM (Continued) ELECTRICAL SYSTEM MONITORING ANNUNCIATIONS (Continued) LOW VOLTAGE ANNUNCIATION (Continued) The ALT FIELD circuit breaker may open on occasion during normal engine starts due to transient voltages. Provided that normal alternator output is resumed after the ALT FIELD circuit breaker is reset, these occurrences are considered nuisance events.
Page 271: Circuit Breakers And Fuses
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS ELECTRICAL SYSTEM (Continued) CIRCUIT BREAKERS AND FUSES Individual system circuit breakers are found on the circuit breaker panel below the pilot's control wheel. All circuit breakers on ESSENTIAL BUS, AVIONICS BUS 1 and AVIONICS BUS 2 are capable of being opened, or disengaged from the electrical system, by pulling straight out on the outer ring for emergency electrical load management.
Page 272: External Power Receptacle
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS ELECTRICAL SYSTEM (Continued) EXTERNAL POWER RECEPTACLE A external power receptacle is integral to the power distribution module and allows the use of an external power source for cold weather starting or for lengthy maintenance work on electrical and avionics equipment.
Page 273: Lighting Systems
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS LIGHTING SYSTEMS EXTERIOR LIGHTING Exterior lighting consists of navigation lights on the wing tips and the tip of the rudder, landing/taxi lights located on the left wing leading edge, or landing/recognition/taxi lights on left and right wing leading edges if LED lights are installed, a flashing beacon mounted on top of the vertical stabilizer, and a strobe light on each wing tip.
Page 274: Interior Lighting
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS LIGHTING SYSTEMS (Continued) EXTERIOR LIGHTING (Continued) NOTE The strobes, flashing beacon and recognition lights (if installed) should not be used when flying through clouds or overcast; the flashing light reflected from water droplets or particles in the atmosphere, particularly at night, can produce vertigo and loss of orientation.
Page 275 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS LIGHTING SYSTEMS (Continued) INTERIOR LIGHTING (Continued) Avionics panel lighting consists of the PFD and MFD bezel and display lighting and audio panel lighting. Rotating the AVIONICS dimmer, found on the switch panel in the DIMMING group, controls the lighting level.
Page 276: Cabin Heating, Ventilating And Defrosting System
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS CABIN HEATING, VENTILATING AND DEFROSTING SYSTEM The temperature and volume of airflow into the cabin can be regulated by manipulation of the push-pull CABIN HT and CABIN AIR control knobs, Refer to Figure 7-8.
Page 277 CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS CABIN HEATING, VENTILATION AND DEFROSTING SYSTEM Figure 7-8 172SPHBUS-00 7-63 U.S.
Page 278: Pitot-Static System And Instruments
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS PITOT-STATIC SYSTEM AND INSTRUMENTS The pitot-static system uses a heated total pressure (pitot) head mounted on the lower surface of the left wing, external static port mounted on the left side of the forward fuselage and associated plumbing to connect the air data computer and the conventional pitot- static instruments to the sources.
Page 279: Vacuum System And Instruments
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS VACUUM SYSTEM AND INSTRUMENTS The vacuum system, Refer to Figure 7-9, provides the vacuum necessary to operate the standby attitude indicator. The system consists of one engine-driven vacuum pump, a vacuum regulator, the standby attitude indicator, a vacuum system air filter, and a vacuum transducer.
Page 280 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS VACUUM SYSTEM Figure 7-9 172SPHBUS-00 7-66 U.S.
Page 281: Clock/O.a.t. Indicator
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS CLOCK/O.A.T. INDICATOR A numerical time or clock window, based on GPS time, and an outside air temperature (O.A.T.) indicator window are provided along the lower edge of the PFD. The O.A.T. indicator uses an air temperature sensor located on top of the cabin.
Page 282: Standard Avionics
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS STANDARD AVIONICS The Garmin G1000 Avionics System is an integrated flight control and navigation system. The system combines primary flight instruments, communications, airplane system information and navigational information all displayed on two color displays.
Page 283: Audio Panel (Gma)
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS STANDARD AVIONICS (Continued) AUDIO PANEL (GMA) The audio panel for the G1000 system integrates all of the communication and navigation digital audio signals, intercom system and marker beacon controls in one unit. It is installed on the instrument panel between the PFD and the MFD.
Page 284: Air Data Computer (Gdc)
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS STANDARD AVIONICS (Continued) AIR DATA COMPUTER (GDC) The Air Data Computer (ADC) compiles information from the airplane's pitot-static system. The ADC unit is mounted behind the instrument panel, just forward of the MFD.
Page 285: Gfc 700 Automatic Flight Control System (Afcs) (If Installed)
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS STANDARD AVIONICS (Continued) GFC 700 AUTOMATIC FLIGHT CONTROL SYSTEM (AFCS) (if installed) Refer to the Garmin G1000 CRG for more information on system operation. CONTROL WHEEL STEERING (CWS) The Control Wheel Steering (CWS) button, located on the pilot’s control wheel, immediately disconnects the pitch and roll servos when activated.
Page 286 SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS GFC 700 SYSTEM SCHEMATIC Figure 7-10 172SPHBUS-00 7-72 U.S.
Page 287: Avionics Support Equipment
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS AVIONICS SUPPORT EQUIPMENT Avionics cooling fans, antennas, microphone and headset provisions, power converter and static discharge wicks support the operation of the avionics equipment installations. AVIONICS COOLING FANS Four DC electric fans provide forced air and ambient air circulation cooling for the G1000 avionics equipment.
Page 288: Antennas
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS AVIONICS SUPPORT EQUIPMENT (Continued) ANTENNAS Two dual-mode VHF COM/GPS antennas are mounted on the top of the cabin. The COM 1/GPS 1 antenna is mounted on the right side and the COM 2/GPS 2 antenna is mounted on the left side.
Page 289: Microphone And Headset Installations
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS AVIONICS SUPPORT EQUIPMENT (Continued) MICROPHONE AND HEADSET INSTALLATIONS Standard equipment for the airplane includes a hand-held microphone, an overhead speaker, two remote-keyed microphone switches on the control wheels, and provisions for communications headsets at each pilot and passenger station.
Page 290: Auxiliary Audio Input Jack
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS AVIONICS SUPPORT EQUIPMENT (Continued) AUXILIARY AUDIO INPUT JACK An auxiliary audio input jack (AUX AUDIO IN) is located on the center pedestal, Refer to Figure 7-2. It allows entertainment audio devices such as cassette, compact disc, and MP3 players to play music over the airplane's headsets.
Page 291: 12V Power Outlet
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS AVIONICS SUPPORT EQUIPMENT (Continued) 12V POWER OUTLET A power converter, located on the cabin side of the firewall just forward of the right instrument panel, reduces the airplane's 28 VDC power to 12 VDC.
Page 292: Static Dischargers
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS AVIONICS SUPPORT EQUIPMENT (Continued) STATIC DISCHARGERS Static dischargers are installed at various points throughout the airframe to reduce interference from precipitation static. Under some severe static conditions, loss of radio signals is possible even with static dischargers installed.
Page 293: Cabin Features
CESSNA SECTION 7 MODEL 172S NAV III AIRPLANE AND SYSTEM DESCRIPTION GFC 700 AFCS CABIN FEATURES EMERGENCY LOCATOR TRANSMITTER (ELT) Refer to Section 9, Supplements 1 or 2 for appropriate ELT operating information. CABIN FIRE EXTINGUISHER A portable Halon 1211 (Bromochlorodifluoromethane) fire extinguisher is installed in a holder on the floorboard between the front seats to be accessible in case of fire.
Page 294: Carbon Monoxide Detection System
SECTION 7 CESSNA AIRPLANE AND SYSTEM DESCRIPTION MODEL 172S NAV III GFC 700 AFCS CABIN FEATURES (Continued) CARBON MONOXIDE DETECTION SYSTEM The carbon monoxide (CO) detection system consist of a single detector located behind the instrument panel, powered by the airplane’s DC electrical system and integrated in the Garmin G1000 system with a warning annunciation and alert messages displayed on the PFD.
Page 295 CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE AIRPLANE HANDLING, SERVICE AND MAINTENANCE TABLE OF CONTENTS Page Introduction ..........8-3 Identification Plate .
Page 296 SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS TABLE OF CONTENTS (Continued) Page Fuel ..........8-15 Approved Fuel Grades (And Colors) .
Page 297: Introduction
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE INTRODUCTION This section contains factory recommended procedures for proper ground handling and routine care and servicing of your airplane. It also identifies certain inspection and maintenance requirements which must be followed if your airplane is to retain that new airplane performance and dependability.
Page 298: Identification Plate
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS IDENTIFICATION PLATE All correspondence regarding your airplane should include the Serial Number. The Serial Number, Model Number, Production Certificate Number (PC) and Type Certificate Number (TC) can be found on the Identification Plate, located on the aft left tailcone.
Page 299: Publications
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE PUBLICATIONS Various publications and flight operation aids are furnished in the airplane when delivered from the factory. These items are listed below. • Customer Care Program Handbook •...
Page 300: Airplane File
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS AIRPLANE FILE There are miscellaneous data, information and licenses that are a part of the airplane file. The following is a checklist for that file. In addition, a periodic check should be made of the latest Federal Aviation Regulations to ensure that all data requirements are met.
Page 301: Airplane Inspection Periods
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE AIRPLANE INSPECTION PERIODS FAA REQUIRED INSPECTIONS As required by U.S. Federal Aviation Regulations, all civil aircraft of U.S. registry must undergo a complete inspection (annual) each twelve calendar months.
Page 302: Cessna Customer Care Program
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS AIRPLANE INSPECTION PERIODS (Continued) CESSNA CUSTOMER CARE PROGRAM Specific benefits and provisions of the Cessna Warranty plus other important benefits for you are contained in your Customer Care Program Handbook supplied with your airplane.
Page 303: Alterations Or Repairs
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE ALTERATIONS OR REPAIRS It is essential that the FAA be contacted prior to any alterations on the airplane to ensure that airworthiness of the airplane is not violated. Alterations or repairs to the airplane must be accomplished by licensed personnel, utilizing only FAA Approved components and FAA Approved data, such as Cessna Service Bulletins.
Page 304: Tiedown
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS GROUND HANDLING (Continued) TIEDOWN Proper tiedown procedure is the best precaution against damage to the parked airplane by gusty or strong winds. To tiedown the airplane securely, proceed as follows: 1.
Page 305: Leveling
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE GROUND HANDLING (Continued) JACKING (Continued) To assist in raising and holding the nosewheel off the ground, ground anchors should be utilized at the tail tiedown point. NOTE Ensure that the nose will be held off the ground under all conditions by means of suitable stands or supports under...
Page 306: Servicing
GROUND HANDLING (Continued) FLYABLE STORAGE (Continued) If the airplane is to remain inactive for more than 30 days, consult the latest revision Textron Lycoming Service Letter L180 (www.lycoming.textron.com). It is recommended when storing the airplane for any period of time to keep fuel tanks full to minimize condensation in tanks.
Page 307: Oil
Oil and continue to use until a total of 50 hours has accumulated or oil consumption has stabilized. MIL-L-22851 or SAE J1899 Aviation Grade Ashless Dispersant Oil: Oil conforming to Textron Lycoming Service Instruction No 1014, and all revisions and supplements thereto, must be used after first 50 hours or oil consumption has stabilized.
Page 308: Capacity Of Engine Sump
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS (Continued) CAPACITY OF ENGINE SUMP The engine has a total capacity of 9 quarts, with the oil filter accounting for approximately 1 quart of that total. The engine oil sump has a capacity of 8 quarts.
Page 309: Fuel
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE FUEL APPROVED FUEL GRADES (AND COLORS) 100LL Grade Aviation Fuel (Blue) Grade Aviation Fuel (Green) NOTE Isopropyl alcohol or Diethylene Glycol Monomethyl Ether (DiEGME) may be added to the fuel supply in quantities not to exceed 1% (alcohol) or 0.15% (DiEGME) of total volume.
Page 310: Fuel Additives
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS FUEL (Continued) FUEL ADDITIVES Strict adherence to recommended preflight draining instructions as called for in Section 4 will eliminate any free water accumulations from the tank sumps. While small amounts of water may still remain in solution in the gasoline, it will normally be consumed and go unnoticed in the operation of the engine.
Page 311 CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE FUEL (Continued) FUEL ADDITIVES (Continued) Alcohol, if used, is to be blended with the fuel in a concentration of 1% by volume. Concentrations greater than 1% are not recommended since they can be detrimental to fuel tank materials.
Page 312 SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS FUEL MIXING RATIO Figure 8-1 172SPHBUS-00 8-18 U.S.
Page 313 CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE FUEL (Continued) FUEL ADDITIVES (Continued) Diethylene Glycol Monomethyl Ether (DiEGME) compound must be carefully mixed with the fuel in concentrations between 0.10% (minimum) and 0.15% (maximum) of total fuel volume. Refer to Figure 8-1 for a DiEGME-to-fuel mixing chart.
Page 314: Fuel Contamination
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS FUEL (Continued) FUEL CONTAMINATION Fuel contamination is usually the result of foreign material present in the fuel system, and may consist of water, rust, sand, dirt, microbes or bacterial growth.
Page 315: Landing Gear
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE LANDING GEAR Consult the following table for servicing information on the landing gear. COMPONENT SERVICING CRITERIA Nose Wheel (5.00-5, 6-Ply Rated Tire) 45.0 PSI Main Wheel (6.00-6, 6-Ply Rated Tire) 42.0 PSI Brakes MIL-H-5606...
Page 316: Cleaning And Care
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS CLEANING AND CARE WINDSHIELD AND WINDOWS The plastic windshield and windows should be cleaned with an airplane windshield cleaner. Apply the cleaner sparingly with soft cloths, and rub with moderate pressure until all dirt, oil scum and bug stains are removed.
Page 317: Painted Surfaces
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE CLEANING AND CARE (Continued) PAINTED SURFACES The painted exterior surfaces of your new Cessna have a durable, long lasting finish. Generally, the painted surfaces can be kept bright by washing with water and mild soap, followed by a rinse with water and drying with cloths or a chamois.
Page 318: Propeller Care
SECTION 8 CESSNA AIRPLANE HANDLING, SERVICE MODEL 172S NAV III AND MAINTENANCE GFC 700 AFCS CLEANING AND CARE (Continued) PROPELLER CARE Preflight inspection of propeller blades for nicks, and wiping them occasionally with an oily cloth to clean off grass and bug stains will assure long blade life.
Page 319: Interior Care
CESSNA SECTION 8 MODEL 172S NAV III AIRPLANE HANDLING, SERVICE GFC 700 AFCS AND MAINTENANCE CLEANING AND CARE (Continued) INTERIOR CARE To remove dust and loose dirt from the upholstery and carpet, clean the interior regularly with a vacuum cleaner. Blot up any spilled liquid promptly with cleansing tissue or rags.
Page 321 CESSNA SECTION 9 MODEL 172S NAV III SUPPLEMENTS GFC 700 AFCS SUPPLEMENTS INTRODUCTION The supplements in this section contain amended operating limitations, operating procedures, performance data and other necessary information for airplanes conducting special operations for both standard and optional equipment installed in the airplane. Operators should refer to each supplement to ensure that all limitations and procedures appropriate for their airplane are observed.

This manual is also suitable for:

Cessna c172s pim

Textron Cessna Skyhawk SP Pilot Operating Handbook

Table of Contents

Quick Conversions

Placards

Table of Contents

Table of Contents

Weight and Balance/ Equipment List

Table of Contents

Quick Links

Chapters

Related Manuals for Textron Cessna Skyhawk SP

Summary of Contents for Textron Cessna Skyhawk SP
