8
Technical Data
Measurands
Water activity (aw) / Water content (x)
Measuring range
Response time t
90
@ 20 °C (68 °F)
1)
Accuracy
Including hysteresis, non-linearity and repeatability
0...40 °C
(32...104 °F)
-40...120 °C
(-40...356 °F)
Resolution
Temperature (T)
Measuring range
1)
Accuracy
Resolution
Output
Digital interface
Protocol
Factory settings
Supported baud rates
Data types for measured values
General
Power supply class III
Power consumption, typ.
Electrical connection
Protection rating
Pressure rating
Probe material
3)
Cable jacket
Temperature working range
Storage conditions
Electromagnetic compatibility
Shock and vibration
Configuration and adjustment
1) Valid in fluids.
Traceable to international standards, administrated by NIST, PTB, BEV...
The accuracy statement includes the uncertainty of the factory calibration with an enhancement factor k=2 (2-times standard deviation). The accuracy
was calculated in accordance with EA-4/02 and with regard to GUM (Guide to the Expression of Uncertainty in Measurement).
2) USA & Canada class 2 supply required, max. supply voltage 30 V DC.
3) Please mind the mounting and installing instructions included in the user manual.
User Manual MOP301 Digital Moisture in Oil Immersion Probe
, typ.
(0...0.9 aw)
(0.9...1 aw)
(0...1 aw)
∆T [°C]
0.5
0.45
0.4
0.3
0.2
0.15
0.1
0
(EU) / class 2 (NA)
∆T [°C]
0...1 aw
0...100 000 ppm; actual range depends on the oil type, for non-
mineral transformer oil, specific solubility parameters are needed
(ppm output is valid in the range 0...100 °C
10 min. in still oil
±0.02 aw
±0.025 aw
±0.03 aw
0.0001 aw
-40...120 °C
(-40...248 °F)
∆T [°C]
0.01 °C
0
20
40
40
20
RS485 (MOP301 = 1 unit load)
Modbus RTU
9 600 Baud, parity even, 1 stop bit, Modbus address 70
9 600, 19 200, 38 400, 57 600, 76 800 and 115 200
FLOAT32 and INT16 registers
2)
8 - 35 V DC
40 mW (without termination resistor)
M12x1, 4 poles
IP66 / NEMA 4X
20 bar
(290 psi)
Stainless steel 1.4404
HFS 125XL, black, oil and fuel resistant
Sensing element + filter cap: -40...125 °C
Probe: -40...120 °C
(-40...248 °F)
Cable: -40...120 °C
(-40...248 °F)
M12 connector: -25...90 °C
-40...80 °C
(-40...176 °F)
0...95 %RH, non-condensing
EN 61326-1
EN 61326-2-3
Industrial Environment FCC Part15 ClassA
Tested acc. to EN 60068-2-6 and EN 60068-2-27
PCS10 Product Configuration Software (free download) and
configuration adapter
0.6
0.5
0.4
0.3
0.2
0.1
)
(32...212 °F)
T [°C]
T [°C]
60
80
100
120
(-40...257 °F)
(-13...194 °F)
ICES-003 ClassA
19
