Serial Interface - Fluke 700G Series Calibration Manual

700G Series
Calibration Manual
Model
Number
Calibration
Point 2
Calibration
Point 3
Calibration
Point 4
Calibration
Point 5
Calibration
Point 6
Calibration
Point 7
Calibration
Point 8
Calibration
Point 9
Calibration
Point 10
Calibration
Point 11

Serial Interface

Use terminal communication software on a PC to set up terminal communication. An
RS-232 to USB cable is necessary. This cable comes with 700G/TRACK Software.
Use these terminal parameters:
•
•
•
•
•
•
20
Table 4. Calibration Points (Cont.)
700G10 700G29 700G30
1750.0 2625.0 4375.0
1500.0 2250.0 3750.0
1250.0 1875.0 3125.0
1000.0 1500.0 2500.0
750.0 1125.0 1875.0
500.0 750.0 1250.0
250.0 375.0 625.0
0.0 0.0 0.0
Bits per second: 9600
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
Local echo: on
700G31 700GA4 700GA5
9300 13.125 26.250
8000 11.000 22.500
6500 25.000 18.750
5000 9.375 15.000
3900 7.500 11.250
2800 5.625 7.500
1800 3.750 3.750
1000 1.875 0.300
500 0.300
0
700GA6 700GA27
87.50 262.50
75.00 225.00
62.50 187.50
50.00 150.00
37.50 112.50
25.00 75.00
12.50 37.50
0.40 0.50
