- Page 1 700G Series Pressure Gauges Users Manual November 2011, Rev. 2, 8/17 English © 2011-2017 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction....................How to Contact Fluke ................Safety Information ..................Ex-Hazardous Areas ................. Display and Buttons................... Control Panel..................... Basic Operation ..................Setup the Product..................Set Tare ....................Supervisory Mode................. Set Custom Unit/Scale................Maintenance ....................Clean the Product ................. - Page 4 700G Series Users Manual...
-
Page 5: Introduction
The Product includes password protect to lock and unlock the functions. The Product ships with a Protective Cover, three AA Batteries (installed), and an NPT/metric Adapter. How to Contact Fluke To contact Fluke, call one of the following telephone numbers: • Technical Support USA: 1-800-44-FLUKE (1-800-443-5853) •... -
Page 6: Safety Information
If the Product is exposed to overpressure or sudden physical shock (such as a drop), examine the Product for damage that can cause a safety concern. If necessary, return the Product to Fluke for evaluation. • The battery door must be closed and locked before you operate the Product. - Page 7 Pressure Gauges • Batteries must only be changed in an area known to be non-hazardous. Explosion hazard. • Remove the batteries if the Product is not used for an extended period of time, or if stored in temperatures above 50 °C. If the batteries are not removed, battery leakage can damage the Product.
-
Page 8: Ex-Hazardous Areas
700G Series Users Manual Ex-Hazardous Areas An Ex-hazardous area as used in this manual refers to an area made hazardous by the potential presence of flammable or explosive vapors. These areas are also referred to as hazardous locations, see NFPA 70 Article 500. Display and Buttons Table 2 lists the features of the Product. -
Page 9: Control Panel
Pressure Gauges Control Panel The control panel is used to change settings or select functions and options. Table 3 lists the functions of the buttons on the Control Panel. Table 3. Control Panel Item Default Function Setup Mode Function Zeros the display. Note Within a function, push to move forward ... -
Page 10: Setup The Product
700G Series Users Manual Setup the Product Use the Setup menu to view and change settings. To change settings: 1. Push to open the Setup menu. 2. Push again to select a function. 3. Push to select an option. /... -
Page 11: Set Tare
Pressure Gauges Set Tare Use to set a constant offset value to subtract from a pressure measurement. Note If you record a Tare value, the pressure value that shows on the display is not the actual pressure applied to the gauge. For example, if a tare is set at 30 psi and the measured pressure is 37 psi, 7 psi shows on the display. -
Page 12: Maintenance
700G Series Users Manual To set a factor: 1. Go to Supervisory mode. 2. Push until SET FACTR shows on the display. 3. Push to select a factor. 4. Push to set the option and go back to the previous function, or push to set the option and ... - Page 13 Pressure Gauges To replace the batteries (See Figure 1.): 1. Use a Phillips screwdriver to loosen the captive screw on the battery door. 2. Remove the battery door and seal. 3. Replace the batteries. For more information, see Specifications. 4. Replace the battery door and seal. Note Align the battery door and seal properly with the Product to protect the Product from moisture and dust.
-
Page 14: Rs-232 Interface
Available Input Ranges ........See Ranges and Resolution tables for available ranges in psi plus equivalent ranges and resolution for all pressure units. Accuracy 700G Ranges Positive Pressure (700G01, 700G02)..±0.1 % Full Scale Positive Pressure (all other ranges)....±0.05 % Full Scale Vacuum............±0.1 % Full Scale Temperature Compensation .......15 °C to 35 °C (59 °F to 95 °F) to rated accuracy... - Page 15 Pressure Gauges Environmental Temperature Operating ..........-10 °C to +55 °C (+14 °F to +131 °F) Storage With Batteries ........Per battery manufacturer’s specification, not to exceed storage specification without batteries. Without Batteries .........-40 °C to +70 °C (-40 °F to +158 °F) Altitude Operating ..........2000 m Storage ...........12 000 m...
- Page 16 700G Series Users Manual Ranges and Resolution (700G) Model Number 700G01 700G02 700G04 700G05 700G06 700G27 700G07 700G08 700G10 700G29 700G30 700G31 Pressure Range 1000 2000 3000 5000 10000 (psi) Vacuum Range -0.4 (psi) Burst Pressure 1200 2000 4000 8000...
- Page 17 Pressure Gauges Ranges and Resolution (700GA and 700RG) Model Number 700GA4 700GA5 700GA6 700GA27 700RG05 700RG06 700RG07 700RG08 700RG29 700RG30 700RG31 Pressure Range 15 PSIA 30 PSIA 100 PSIA 300 PSIA 30 1000 3000 5000 10000 (psi) Vacuum Range 0 PSIA 0 PSIA 0 PSIA 0 PSIA...
- Page 18 700G Series Users Manual...
