Summary of Contents for Fluke 730G
- Page 1 730G, 730GA, 730RG Pressure Calibrators Users Manual October 2018 (English) © 2018 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ......................How to Contact Fluke.................... Safety Information....................Standard Equipment ..................... Display ........................Control Panel ....................Function Keys ....................Connections..................... Connect and Zero the Product................Menus ........................Main Menu ....................... Instrument Setup ..................... Date/Time ....................10 Measure Mode Menu.................. - Page 4 730G, 730GA, 730RG Users Manual...
-
Page 5: Introduction
Introduction The Fluke 730G, 730GA, and 730RG Pressure Calibrators (the Product) are portable field pressure calibration tools for lab or field use. The battery-operated product performs pressure calibration of transmitters, pressure switches, pressure sensors, and gauges with pressure calibration software. The Product also supplies basic ®... -
Page 6: Safety Information
Do not put battery cells and battery packs near heat or fire. Do not put in sunlight. • Use only Fluke approved power adapters to charge the battery. • Disconnect the battery charger and move the Product or battery to a cool, nonflammable location if the rechargeable battery becomes hot (>50 °C) during the charge period. - Page 7 batteries should be disposed of by a qualified recycler or hazardous materials handler per local regulations. Contact your authorized Fluke Service Center for recycling information. This product complies with the WEEE Directive marking requirements. The affixed label indicates that you must not discard this electrical/electronic product in domestic household waste.
-
Page 8: Standard Equipment
730G, 730GA, 730RG Users Manual Standard Equipment Table shows the standard equipment that comes with the Product. Table 2. Standard Equipment 10K PSI 700 BAR Item Description Item Description Fitting, 1/4 in NPT-Female x 1/4 in The Product BSP-Male ... -
Page 9: Display
Pressure Calibrators Display Display Table shows the items on the display. Table 3. Display 17/07/30 15:30 MEAS V 7.000 20.000 100% Zero Save Menu Item Description Item Description Measured voltage, current, or Mode display temperature value Time and date display Soft keys ... -
Page 10: Control Panel
730G, 730GA, 730RG Users Manual Control Panel Use the control panel to select functions and options. Table lists the functions of the buttons on the control panel. Table 4. Control Panel MEAS V 17/07/30 15:30 7.000 20.000 100% Zero Save... -
Page 11: Connections
Pressure Calibrators Display Connections Table shows the connections of the Product. Table 6. Connections Item Description Function COM port Provide common ground. Measure mA or V dc. V or mA port Supply loop power. Supply the Product with power. Ac power supply/battery ... -
Page 12: Connect And Zero The Product
730G, 730GA, 730RG Users Manual Connect and Zero the Product Connect and zero the Product prior to use and calibration. To set up the Product: 1. Wrap the threads of the pressure port with PTFE tape. 2. Connect the pressure port of the Product to an output of an approved pump. See Figure 1. -
Page 13: Menus
Pressure Calibrators Menus Menus Use the menus to change and view settings. Main Menu Table lists the submenus available in the main menu. Table 7. Main Menu Submenu Description Measure Mode Menu. Measure Mode Set the measurement mode. See Leakage Test. -
Page 14: Date/Time
730G, 730GA, 730RG Users Manual Table 8. Setup Menu (cont.) Item Option Description Never 5 minutes Set the time after which the Product automatically turns off when Power off there is no user interaction. 15 minutes 30 minutes Factory mode Reset the Product to original settings. -
Page 15: Volt Mode
Pressure Calibrators Menus Volt Mode In Volt mode, the Product shows the pressure and loop voltage measurements. Figure shows the voltage measurement connections. Voltage Output Device MEAS V 17/07/30 15:30 7.000 20.000 100% Zero Save Menu 10K PSI 700 BAR Figure 2. -
Page 16: Ma+24V Mode
730G, 730GA, 730RG Users Manual mA+24V Mode In mA+24V mode, the Product outputs 24 V dc as it shows the pressure and loop current measurements. Use this mode to power a transmitter without a separate power supply. Figure shows the mA+24V Mode connections. -
Page 17: Error Test
Pressure Calibrators Menus Error Test Do an error test to check for pressure leaks in the device under test (DUT). Table lists the options in the Error Test menu. Table 10. Error Test Item Option Description Volt Cfg. M (Configure Set the measurement mode to use for the error test. -
Page 18: Min Max Value
730G, 730GA, 730RG Users Manual Pressure - Pressure Current - 4 mA measure measure Error % = Pressure - Pressure 16 mA 20mA Figure 6. Current Error Percentage Calculation Figure shows the formula used to calculate the voltage error percentage. -
Page 19: Hart Communication (Hart)
Pressure Calibrators Menus Figure 8. Switch Connection HART Communication (HART) Use the Product to communicate with HART devices. Auto power off is disabled when you use the HART menus. When you exit the HART menus, auto power off returns to its previous state. Note Loop output trim is supported for transmitter devices, but it is not supported for actuator devices. - Page 20 730G, 730GA, 730RG Users Manual Table lists the items in the HART menu. Table 11. HART Menu Item Option Description View the measured values of the HART device connected to the Cont. (Continue) Product. See Table 12. Svc. (Service) Service the HART device. See Table 13.
- Page 21 Pressure Calibrators Menus Table lists the items in the Svc. (Service) menu. Table 13. Service Menu for HART Device Item Description Loop Test Tests the output loop of the HART device. Output Trim Adjust the output loop of the HART device. Pressure Zero Trim Set the zero point of the primary variable.
-
Page 22: Hart Connections Internal Loop Power, Internal Resistance
730G, 730GA, 730RG Users Manual HART Connections Internal Loop Power, Internal Resistance To use the Product in-circuit to provide 24 V loop power and 250 Ω resistance: 1. Connect the Product to the HART device. See Figure 9. 2. Select Menu > Measure Mode > HART Comm.. -
Page 23: External Loop Power, Internal Resistance
Pressure Calibrators Menus External Loop Power, Internal Resistance To use the Product in-circuit to provide 250 Ω resistance with an external 24 V loop power supply: 1. Connect the Product to the HART device. See Figure 10. 2. Select Menu > Measure Mode > HART Comm.. 3. -
Page 24: External Loop Power, External Resistance
730G, 730GA, 730RG Users Manual External Loop Power, External Resistance To use the Product across a circuit with an external 24 V loop power supply and an external 250 Ω resistor. 1. Connect the Product to the HART device. See Figure 11. -
Page 25: Data Memory
Pressure Calibrators Accessories Data Memory Use Data Memory to view and delete saved screen shots. To use the Product to save, review, and delete screen shots: 1. On the home screen, push to take a screen shot of the display. 2. -
Page 26: Clean The Product
730G, 730GA, 730RG Users Manual Clean the Product W Caution To prevent damage to the Product, do not use abrasives, isopropyl alcohol, or solvents to clean the case or display. Clean the case with a damp cloth and a weak soap solution. To clean the display, use a pressurized can of air or a dry nitrogen-ion gun, if available, to blow off the particulates from the display. -
Page 27: Replace The Battery
Pressure Calibrators Maintenance Figure 12. Charge the Battery Replace the Battery To replace the battery (See Figure 13): 1. Remove the holster. 2. Use a Phillips screwdriver to loosen the captive screw on the battery door. 3. Remove and replace the battery. 4. -
Page 28: Specifications
730G, 730GA, 730RG Users Manual Figure 13. Replace the Battery Specifications Accuracy Specifications Ranges and Resolutions. Available Input Ranges ..........See Accuracy 730G Ranges Positive Pressure (730G01, 730G02).......±0.2 % Full Scale Positive Pressure (all other ranges)......±0.05 % Full Scale Vacuum (730G01, 730G02)........±0.2 % Full Scale Vacuum (all other ranges) ........±0.1 % Full Scale... -
Page 29: Mechanical Specifications
Output..............15 V dc, 2 A Temperature Operating With Battery ............As specified by the manufacturer of the battery Without Battery 730G01, 730G02, 730G04, 730G05, all 730RG ..........0 °C to 50 °C All other 730G, 730GA ........-10 °C to 55 °C... -
Page 30: Safety
Without battery 730G01, 730G02, 730G04, 730G05, all 730RG..........-20 °C to 70 °C All other 730G, 730GA ........-40 °C to 70 °C Relative Humidity............. <+10 °C, non condensing ≤90 % RH (10 °C to 30 °C) ≤75 % RH (30 °C to 40 °C) ≤45 % RH (40 °C to 50 °C) -
Page 31: Ranges And Resolutions
Pressure Calibrators Specifications Ranges and Resolutions Model Sensor Range Resolution Burst Pressure -10 inH 0 to 10 inH 0.001 inH 3 psi 730G01 NPH-8-002.5DH 210 mbar -20 mbar to 20 mbar 0.001 mbar -1 psi to 1 psi 0.0001 psi 5 psi 730G02 NPH-8-007DH... - Page 32 730G, 730GA, 730RG Users Manual...
