- Page 1 700G Series Pressure Gauge Users Manual November 2011 Rev. 1, 10/13 © 2011-2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for three years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ........................1 How to Contact Fluke ..................... 1 Standard Equipment....................... 2 Safety Information ......................2 Hazard Location Information/Approvals ..............3 Special Conditions for Safe Use ................3 Symbols ........................4 Display and Buttons ....................... 5 Operation ........................ - Page 4 700G Series Users Manual Set Sample Rate ....................8 Set Tare ....................... 8 Function Lock ....................... 8 Supervisory Mode ..................... 8 Available Pressure Ranges ..................9 How to Set a Custom Engineering Unit or Scale............9 Battery Life ........................9 Maintenance ........................
-
Page 5: List Of Tables
List of Tables Table Title Page Symbols ..........................4 Display and Buttons ......................5... - Page 6 700G Series Users Manual...
-
Page 7: List Of Figures
List of Figures Figure Title Page The Product ........................... 5 Change the Batteries ......................11... - Page 8 700G Series Users Manual...
-
Page 9: Introduction
Introduction How to Contact Fluke The 700G Series Pressure Gauges (the Product) are To contact Fluke, call one of the following telephone high-accuracy digital pressure test gauges. Accurate to numbers: 0.05 % FS, the Products can be used as a calibration •... -
Page 10: Standard Equipment
700G Series Users Manual • Standard Equipment Replace the batteries when the low battery indicator () shows to prevent The Product ships with: incorrect measurements. • Protective Cover • Do not use and disable the Product if it • is damaged. Three AA Batteries (installed) •... -
Page 11: Hazard Location Information/Approvals
These areas are also any damage that can cause a safety concern. If referred to as hazardous locations, see NFPA 70 Article necessary, return the Product for evaluation to Fluke. 500. Refer to the How to Contact Fluke section. -
Page 12: Symbols
Category: With reference to the equipment types in the WEEE Directive Annex I, this product is classed as category 9 "Monitoring and Control Instrumentation" product. Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information. -
Page 13: Display And Buttons
Pressure Gauge Display and Buttons Display and Buttons The Display and Buttons are shown in Figure 1. The Buttons are explained in Table 2. PRESSURE 700G31 10K PSIG GAUGE 10K PSI 700 BAR gsn001.eps Figure 1. The Product... - Page 14 700G Series Users Manual Table 2. Display and Buttons Item Function Push to turn the Product on. Push again to turn it off. Zeros the display. In Configure Mode, push the button to move forward through the menus. Note ...
- Page 15 Pressure Gauge Table 2. Display and Buttons (cont.) Item Function Item Function ¼ inch NPT Connector MIN MAX records minimum and maximum Pressure Display pressure values and saves them in memory. Push to show maximum Engineering Units (MAX) indication.
-
Page 16: Operation
700G Series Users Manual engineering units. See the Supervisory Mode section for Operation instructions to set up custom units. The subsequent sections tell you how to operate the Set Auto Off Product. Push to turn on the Product. Auto Off can be set in 1-minute increments from 1 to 30 The analog bar graph at the bottom of the display shows minutes or you can turn off the function for continuous the applied-pressure level relative to the full range of the... -
Page 17: Set Sample Rate
Pressure Gauge Operation Set Sample Rate Function Lock This function finds how often pressure is sampled and the When set, access to each of the settable parameters display is updated. Selections are 0.5, 1, 3, and 10 above can be turned “off” to prevent unauthorized samples/second. -
Page 18: Available Pressure Ranges
700G Series Users Manual each parameter. To move to the next parameter, push How to Set a Custom Engineering Unit or Scale . The last menu selection in Supervisory mode is SET FACTR. You can set a multiplier factor from 0.001 to You can access, lock, or unlock these functions: 100 to make a custom scale. -
Page 19: Maintenance
Pressure Gauge Maintenance Maintenance How to Change the Batteries Warning How to Clean the Product Clean the Product with a soft cloth dampened with water To prevent possible electrical shock, fire, or or water and weak soap. personal injury, batteries must only be changed in an area known to be non- Caution hazardous. -
Page 20: Accessories
700G Series Users Manual Accessories RS-232 Interface The Product includes an RS-232 interface. Remove the Product holster and the input jack is on the back of the Product. You can use serial communication to configure and calibrate the Product and move measurement data from the Product to a PC. -
Page 21: Specifications
See Ranges and Resolution table for available ranges in psi plus equivalent ranges and resolution for all engineering units. Accuracy 700G Ranges Positive Pressure ................±0.05 % FS Positive Pressure (700G01, 700G02) ..........±0.1 % FS Vacuum ................... ±0.1 % FS Temperature Compensation ............15 °C to 35 °C (59 °F to 95 °F) to rated accuracy Note: For temperatures from -10 °C to 15 °C and 35 °C to 55 °C, add .003 % FS/°C... -
Page 22: Media Compatibility
Users Manual Media Compatibility 700G01, 700G02, 700G04, 700G05, 700RG05 ......any clean dry non-corrosive gas All other ranges, 15 psi to 1000 psi..........any liquids or gases compatible with 316 stainless steel Above 1000 psi ................any non-flammable, non-toxic, non-explosive, non-... -
Page 23: Mechanical Specifications
Pressure Gauge Specifications Mechanical Specifications Dimensions ..................11.4 x 12.7 (cm), depth = 3.7 cm (4.5 x 5 (in), depth= 1.5 in) Pressure Connection ................¼ in NPT Male Housing .................. Cast ZNAL Display 5-1/2 Digits, 16.53 mm (0.65 in) high 20-Segment bar graph, 0 to 100 % Power Battery ................... -
Page 24: Ranges And Resolution
700G Series Users Manual Ranges and Resolution Model Number 700G01 700G02 700G04 700G05 700G06 700G27 700G07 700G08 700G10 700G29 700G30 700G31 Pressure Range 1000 2000 3000 5000 10000 (psi) Vacuum Range -0.4 (psi) Burst Pressure 1200 2000 4000 8000 10000... - Page 25 Pressure Gauge Specifications Model Number 700G01 700G02 700G04 700G05 700G06 700G27 700G07 700G08 700G10 700G29 700G30 700G31 Pressure 1000 2000 3000 5000 10000 Range (psi) Vacuum -0.4 Range (psi) Burst Pressure 1200 2000 4000 8000 10000 15000 20000 (psi) Proof Pressure...
- Page 26 700G Series Users Manual Model Number 700GA4 700GA5 700GA6 700GA27 700RG05 700RG06 700RG07 700RG08 700RG29 700RG30 700RG31 Pressure 15 PSIA 30 PSIA 100 PSIA 300 PSIA 1000 3000 5000 10000 Range (psi) Vacuum 0 PSIA 0 PSIA 0 PSIA 0 PSIA Range (psi) Burst Pressure...
- Page 27 Pressure Gauge Specifications Model Number 700GA4 700GA5 700GA6 700GA27 700RG05 700RG06 700RG07 700RG08 700RG29 700RG30 700RG31 Pressure 15 PSIA 30 PSIA 100 PSIA 300 PSIA 1000 3000 5000 10000 Range (psi) Vacuum 0 PSIA 0 PSIA 0 PSIA 0 PSIA Range (psi) Burst Pressure...
- Page 28 700G Series Users Manual...
