4000 SERIES (4+1)
VANDAL RESISTANT
DOOR ENTRY SYSTEM
TECHNICAL MANUAL
EDITION 1.1A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Videx 4000 Series

Summary of Contents for Videx 4000 Series

  • Page 1 4000 SERIES (4+1) VANDAL RESISTANT DOOR ENTRY SYSTEM TECHNICAL MANUAL EDITION 1.1A...

  • Page 2: Table Of Contents

    CONTENTS PAGE Manual introduction System introduction System components 3 – 13 Codelock programming instructions 15 – 16 Accessories 13 – 14 Installation Cable size guide Testing the system Panel care Accessories connection guide 17 – 18 Single entrance single button audio wiring diagram Single or multiple entrance, multiple button audio wiring diagram Single entrance video system wiring diagram Multiple entrance video system wiring diagram...

  • Page 3: Manual Introduction

    The information in this manual is intended as an installation and commissioning guide for the vandal resistant 4000 Series door entry systems. This manual should be read carefully before the installation commences. Any damage caused to the equipment due to faulty installations where the information in this manual has not been followed is not the responsibility of Videx Security Ltd.
  • Page 4 AMPLIFIER (Art.136) The amplifier is the most important part of the system and controls the operation of the system including speech, door release call to apartment etc. It contains a microprocessor which controls all of these features. Amplifier module connections Connection Function Receive speech from apartment...
  • Page 5 Amplifier speech volume POTS Speech volume adjustments are carried out at the door panel using a small trimmer driver. Adjustment for Adjustment for speech volume at the speech volume level apartment at the door station CAMERA (Art.VR4KCMM – Mono & Art.VR4KCMC - Colour) The camera module is available in both mono and colour and can be set for either coax installations or non-coax installations.
  • Page 6 Proximity module connections Connection Function Colour 0V power connection Grey 12Vdc power connection White Serial data connection to controller Yellow Red LED control line (Also controls the internal sounder) Brown Green LED control line (Also controls the internal sounder) Green CODE LOCK (Art.VR4KCLM) The codelock module can be powered from 12-24V AC or DC and includes three dry contact relay outputs and two switched 0V push to exit button inputs which can be used to...
  • Page 7 Art.520MR This power supply combines both a 520M and a 506 relay into one and can be used instead of the 520M on multiple door video systems. Outputs of 12Vdc (200mA), 8Vdc (300mA) and 13Vac (1A) are available. The dc outputs are designed to power the amplifier modules only and must not be used to power other devices such as lock releases etc.
  • Page 8 TELEPHONE Art.3111 The Art.3111 is a white ABS plastic wall mounting electronic call telephone and includes a lock release push button and spare dry contact button. There is a three position call volume control external to the top left side of the telephone. Art.3011 Smart line phone includes a lock release push button only.
  • Page 9 VIDEOPHONES & MONITORS Art.3312 The Art.3312 (3412 for colour) includes a lock release push button, camera recall button and three dry contact push to make spare push buttons for other services. Coax and non- coax video can be used by setting the relevant dip- switches.
  • Page 10 Art.3313 The Art.3313 (3413 for colour) includes a lock release push button and two dry contact push to make spare push buttons for other services. An Art.3980 back plate is required with this videophone. CONNECTIONS:- Terminal Signal Function +12V OUT +12V out to power video splitter Camera recall (●...
  • Page 11 Art.5418 The 5418 colour Eclipse is available surface, flush and with a handset. Features include full duplex speech, door release, latching relay, 2x momentary outputs and timed privacy. A 5980 back plate or flush box is required for mounting CONNECTIONS:- Terminal Signal Function...
  • Page 12 5418 VIDEO SETUP & PROGRAMMING 3 Way dip-switch Video Mode Coax video signal Balanced video signal Switch 3 = Video end of line resistor To enter programming mode to carryout the following settings, press the two following buttons at the same time (left button of the volume control and the right button of the colour intensity control) (far left button and far right button together).

  • Page 13: Accessories

     Press the “ ” button again to set the privacy duration. Each time the button is pressed, it will increase the privacy duration by 15 minutes (starting from 0 up to a maximum of 20 hours i.e. pressing the button 8 times = 2 hours up to a maximum of 80 presses for 20 hours). ...

  • Page 14: Installation

    INSTALLATION The wiring diagram towards the back of this manual should be followed carefully. Heavy duty conductors on wiring diagrams are shown heavily outlined, these wires should be doubled up. Check that all components are free from damage before installing (Do not proceed with installation in the event of damage).

  • Page 15: Codelock Programming Instructions

    VR4KCLM CODELOCK INITIAL PROGRAMMING All programming is carried out using the codelock keypad. The programming menu is protected by an engineer’s code. The factory default engineers code is 111111 (6x1). This code can be changed to any four to eight digit code during the program but must be different to the codes used to gain entry.
  • Page 16 VR4KCLM CODELOCK REPROGRAMMING GUIDE Engineers code Enter the Relay 1 code engineer’s code Relay 2 code Relay 3 code RED Light will Press Enter Relay 1 Time illuminate * Relay 2 Time Re-Enter the Alternatively enter a Relay 3 Time new engineer’s engineer’s code (4-8 digits)

  • Page 17: Cable Size Guide

    CABLE SIZE GUIDE Suitable cables for this system are CW1308 and YY cable (Other similar cables are also suitable) Care should be taken to avoid excessive voltage drop. Follow the guide lines below. Connections from door panel to telephones/videophones. Connections 100m 200m 300m...
  • Page 18 Adding the 4800 codelock to a panel PAGE 18 of 24 VR4K (4+1) SERIES TECHNICAL MANUAL VER1.1A...

  • Page 19: Single Entrance Single Button Audio Wiring Diagram

    The diagrams in this manual are examples. If you require a special diagram to show a particular installation, please e-mail your request to tech@videx-security.com along with your parts list and a description of your system. PAGE 19 of 24 VR4K (4+1) SERIES TECHNICAL MANUAL...

  • Page 20: Single Or Multiple Entrance, Multiple Button Audio Wiring Diagram

    PAGE 20 of 24 VR4K (4+1) SERIES TECHNICAL MANUAL VER1.1A...

  • Page 21: Single Entrance Video System Wiring Diagram

    PAGE 21 of 24 VR4K (4+1) SERIES TECHNICAL MANUAL VER1.1A...

  • Page 22: Multiple Entrance Video System Wiring Diagram

    PAGE 22 of 24 VR4K (4+1) SERIES TECHNICAL MANUAL VER1.1A...

  • Page 23: Troubleshooting Guide

    TROUBLE SHOOTING SYMPTOM TEST No speech from the door panel to the Check terminal 2 on the amplifier for continuity to terminal 2 on the telephone. telephone. Check the voltage drops to approx. 1Vdc after the handset is lifted. (If not try another telephone) If all else fails try another amplifier at the door station No speech from the telephone to the door Check terminal 1 on the door panel amplifier for...
  • Page 24 Northern Office Videx Security Ltd Unit 4-7 Chillingham Ind. Est. Newcastle Upon Tyne NE6 2XX TEL 0870 300 1240 FAX 0191 224 5678 Southern Office 1 Osprey Trinity Park Trinity Way London E4 8TD FAX 0208 523 5825 TECHNICAL SUPPORT tech@videxuk.com...
