Jumper and Switch Settings
Before applying power to the CAPA13S, please make sure all of the jumper
and switch are in factory default positions.
Jumper/Switch Description
eDP Voltage Selection
JP1
Default: +3.3V
Restore BIOS Optimal Defaults
SW1
Default: Normal Operation
Auto Power On
SSW1
Default: Disable
Note: Please contact your local vendors if any damaged or missing items. DO
NOT apply power to the board if there is any damaged component.
Board Layout
Top View
Rear I/O
2
Setting
1-2 Close
Release
1-2 Close
©
Copyright 2021 Axiomtek Co., Ltd.
Version A1 June 2021
Printed in Taiwan
Bottom View
Installing Cooling Fan
©
