Page 1
Preface Overview SIPROTEC4 Parametrization in DIGSI Multifunction protection with DNP V3.00 Device Profile control Communication-Interfaces 7SJ61 / 7SJ62 / 7SJ63 6MD63 Glossary Communication module Index DNP 3.0 Cover Communication Database and Device Profile Document Bus mapping Revision: 1.0 Edition: June 2000 C53000-L1840-A001-01...
Page 2
Registered trademarks Your suggestions are welcome. SIPROTEC® und DIGSI® are registered trademarks of Siemens AG. Subject to change without prior notice. Other designations in this manual may be trademarks that if used by third parties for their own purposes may violate the rights of the owner.
Page 3
Preface The manual is devided into the following topics: Contents of this manual • Overview • Parametrization in DIGSI • DNP V3.00 Device Profile • Communication-Interfaces This manual describes the data in the DNP messages standard mapping Additional of the SIPROTEC devices. literature The following additional manuals inform you about the function, operation, assembly and commissioning of the SIPROTEC devices:...
Page 4
4.2 and DNP communication module. See our catalog of courses for a list of available courses or contact our Training courses training center in Nuremberg. If you have questions to the SIPROTEC devices, contact your Siemens Questions representative. 7SJ61/62/63 6MD63 DNP3.0 Device Profile Document...
Page 5
Revision index Modified chapters / Edition Reasons of modification pages First edition June 8 , 2000 7SJ61/62/63 6MD63 DNP3.0 Device Profile Document C53000-L1840-A001-01...
Overview Overview This document describes the DNP standard mapping for SIPROTEC4 Mapping: devices. • Standard mapping one specifies the analog values for the voltage range of 32.767 kV and two DNP index points for double point commands. • Standard mapping two specifies the analog values for the voltage range of 327.67 kV and two DNP index points for double point commands.
Page 10
Overview Specifications The communication database profile in the SIPROTEC-device 7SJ61-63 and 6MD63 with the DNP3.0 protocol is grouped into twelve object types. These are: • Binary Input with Status (object 01, variation 02): These points represents the state of a digital input-channel or an internal software-information-point.
Page 11
• Time and Date (object 50, variation 01): The time and date object is an information object that represents the absolute time of day and date. This object are used for time- synchronization. The absolute time is recorded as milliseconds since midnight, January 1 , 1970, at zero hours, zero minutes, zero seconds and milliseconds.
Parametrization in DIGSI Parametrization in DIGSI Parametrization in DIGSI The SIPROTEC-device is designed so that the users can select only the group of data points in which they are interested. Users can select ® mappings by the protection data processing program DIGSI .
Page 14
Parametrization in DIGSI Edit only the numbers. Editing anything else will cause unexpected problems. Only those SIPROTEC objects can transmitted or controlled by DNP which are listed in the DNP V3.00 Device Profile All these objects are already contained in the standard parameter set and they can identified by their name or their „Internal object no.“...
Page 15
Parametrization in DIGSI The messages in DNP input direction allow: • polling of switching devices‘ status and binary inputs, • transmission of annunciations, measurands and meter values to the DNP master. The messages in DNP output direction allow: • command outputs through the output relays of the SIPROTEC device (external commands), •...
DNP V3.00 Device Profile Device Profile Document DNP V3.00 DEVICE PROFILE DOCUMENT Vendor Name: SIEMENS AG Device Name: SIPROTEC 7SJ61, 7SJ62, 7SJ63 & 6MD63 Highest DNP Level Supported: Device Function: ? Master C Slave For Requests DNP-L2 For Responses DNP-L2...
Page 20
DNP V3.00 Device Profile Requires Data Link Layer Confirmation: ? Never ? Always ? Sometimes If 'Sometimes', when? ______________________________________________ C Configurable If 'Configurable', how? by the protection data processing program DIGSI Requires Application Layer Confirmation: ? Never ? Always (not recommended) C When reporting Event Data (Slave devices only) C When sending multi-fragment responses (Slave devices only) ? Sometimes...
Page 21
DNP V3.00 Device Profile FILL OUT THE FOLLOWING ITEM FOR SLAVE DEVICES ONLY: TimeSync Information: a.) TimeSync Period ? Never ? Fixed at ________seconds C Configurable, range ____1____to __86400_seconds b.) Maximum time base drift over 10 minute interval: ____30__ms c.) Maximum Internal Time Reference Error when set via DNP: _____1__ms d.) Maximum Delay Measurement error: ____20__ms...
DNP V3.00 Device Profile Control Relay Output Blocks/Binary Output Status(mapping 1 and 2) Note: The table below describes the control relay output blocks / binary outputs for the standard mapping 1 and 2. Binary Output Status Points Object Number: 10 Request Function Codes supported: 1 (Read) Default Variation reported when variation 0 requested: 2 (Binary Output Status) Control Relay Output Blocks/Binary Output Status...
DNP V3.00 Device Profile Control Relay Output Blocks/Binary Output Status(mapping 3 and 4) Note: The table below describes the control relay output blocks / binary outputs for the standard mapping 3 and 4. Binary Output Status Points Object Number: 10 Request Function Codes supported: 1 (Read) Default Variation reported when variation 0 requested: 2 (Binary Output Status) Control Relay Output Blocks/Binary Output Status...
Page 41
DNP V3.00 Device Profile The following index points are identical chap. 3.4 3-25 7SJ61/62/63 6MD63 DNP3.0 Device Profile Document C53000-L1840-A001-01...
DNP V3.00 Device Profile Analog Inputs Note: For each measured value in the table below show in the column “Scaling“ the scaling values defined in standard mappings 1 to 4, e.g. (for "Va =“): 1: 32.767 kV - applies to standard mapping 1 2: 327.67 kV - applies to standard mapping 2 3: 32.767 kV...
Page 44
DNP V3.00 Device Profile Analog Inputs Static (Steady-State) Object Number: 30 Change Event Object Number: 32 Request Function Codes supported: 1 (read) Static Variation reported when variation 0 requested: 02 (16-Bit Analog Input) Change Event Variation reported when variation 0 requested: 02 (Analog Change Event without Time) Point Default...
Page 45
DNP V3.00 Device Profile Analog Inputs Static (Steady-State) Object Number: 30 Change Event Object Number: 32 Request Function Codes supported: 1 (read) Static Variation reported when variation 0 requested: 02 (16-Bit Analog Input) Change Event Variation reported when variation 0 requested: 02 (Analog Change Event without Time) Point Default...
Page 46
DNP V3.00 Device Profile Analog Inputs Static (Steady-State) Object Number: 30 Change Event Object Number: 32 Request Function Codes supported: 1 (read) Static Variation reported when variation 0 requested: 02 (16-Bit Analog Input) Change Event Variation reported when variation 0 requested: 02 (Analog Change Event without Time) Point Default...
Page 47
DNP V3.00 Device Profile Analog Inputs Static (Steady-State) Object Number: 30 Change Event Object Number: 32 Request Function Codes supported: 1 (read) Static Variation reported when variation 0 requested: 02 (16-Bit Analog Input) Change Event Variation reported when variation 0 requested: 02 (Analog Change Event without Time) Point Default...
Communication-Interfaces Communication-Interfaces There are two communication modules available for the protection devices 7SJ61/62/63 and 6MD63: • Universal asynchronous interfacemodule with potential isolated RS485 Interface, • Universal asynchronous interfacemodule with fiber optical link interface. Technical Data RS485 modul Connection 9-pin D-SUB port; signals A, B, RTS, VCC1 and GND1 (s.
Communication-Interfaces Technical Data Fiber Optical Link modul Connection Optical interface, Rx and Tx, 820nm, BFOC/2.5 Protocol Half-duplex Maximum Distance of Transmission 1.25 miles for glass fiber 62.5/125 µm Optical Link Signal Attenuation Minimum 8 dB for glass fiber 62.5/125 µm Character idle state Factory setting “Light off”...
Glossary Glossary asynchronous interface module with (electrical) isolated RS485 interface for the SIPROTEC devices from Siemens. asynchronous interface module with optical interface for the SIPROTEC devices from Siemens. Automatic Recloser Continuous Function Chart Double Command Parameterization system for SIPROTEC devices...
Index Index additional manuals.........i Optical Link modul........4-2 Analog Input .......1-2,3-2,3-27 output direction..........2-3 Binary Input....1-2,2-2,2-3,3-1,3-5,3-6 Response time........1-3,3-5 Binary Output....1-2,2-2,3-1,3-4,3-20 RS485 modul..........4-1 CFC-Incoming annunciations....2-2 standard mapping ......i,1-1,2-2 CFC-Output indications......2-2 Subset Level........3-1,3-3 Class Data ..........1-3 communication database ......1-2 communication module......ii,4-1 Time and Date......1-3,3-2,3-3 Control Relay....1-2,3-1,3-4,3-20,3-23 Counter......1-2,3-1,3-5,3-24,3-26 Validity............ii...
Page 54
Index 7SJ61/62/63 6MD63 DNP3.0 Device Profile Document C53000-L1840-A001-01...
