SiPass Driver for PXC Modular and PXC-36
These installation instructions cover the connection of
the Siemens SiPass Driver to the SiPass system
only.
For hardware installation of the PXC Modular, see
PXC Modular Series Installation Instructions
the
(553-638).
For hardware installation of the PXC-36, see the
PXC Compact 36 Installation Instructions
(553-504).

Product Description

The Siemens SiPass Driver enables communication
between the APOGEE® Automation System and the
Siemens SiPass system.
Product Numbers
License
LSM-INT-SBTSPSS
License to enable the Siemens SiPass
Driver on PXC Modular or PXC-36
hardware.
PXC Modular Series
PXC00-PE96.A
PXC Modular, Ethernet or RS-485
ALN, 96 FLN nodes
PXC00-E96.A
PXC Modular, BACnet/IP or MS/TP
ALN, 96 FLN nodes
PXC100-PE96.A
PXC Modular, Ethernet or RS-485
ALN, 96 FLN nodes, TX-I/O module
support
PXC100-E96.A
PXC Modular, BACnet/IP or MS/TP
ALN, 96 FLN nodes, TX-I/O module
support
PXX-485.3
Expansion Module, three RS-485 FLN
connections
Item Number: 565-722, Rev. BA
PXC Compact Series
PXC36-PE.A
PXC Compact, 36 point, Ethernet/IP or
RS-485 ALN
PXC36-E.A
PXC Compact, 36 point, BACnet/IP or
MS/TP ALN
Accessories
538-670
Trunk Interface II, 115V
538-675
Trunk Interface II, 230V
536-004
RS-232 Cable
Caution Notation
CAUTION
Equipment damage or loss of data may
occur if you do not follow a procedure as
specified.
Expected Installation Time
30 minutes
Required Tools and Materials
Flat-blade screwdriver (1/8-inch blade width).
Wire strippers.
Cabling and connectors. See the
Driver to the SiPass System
CAUTION
Always wear an electro-static discharge
(ESD) wrist strap and discharge
accumulated static before touching field
panel components.
Installation Instructions
Document No. 565-722
August 2, 2013
Connecting the
section.
Page 1 of 2
