Binding

10 / 34
To establish a connection with the transmitter, the Graupner HoTT
receiver must first be "bound" to at least one model memory in "its"
Graupner HoTT transmitter. This process is generally called "bind-
ing". However, the methods to be used are not always the same, so
the following step-by-step instructions apply only to binding a HoTT
S1034 Falcon 12 plus to any transmitter:
Binding step-by-step
• If the Graupner S1034 Falcon 12 plus is already bound to a spe-
cific transmitter and this binding should be maintained, the
transmitter should ideally be switched on before the receiver. At
the latest, however, within approximately 15 seconds from the
moment when the receiver is switched on, the red LED of the
receiver is constantly on.
Attention
As soon as the LED starts to flash, the Graupner Falcon 12 plus
is in bind mode. From this point on there is the risk that the Fal-
con 12 plus unintentionally binds to a transmitter, which is casu-
ally in bind mode at the same time, whereupon the model can
run uncontrolled at any time. The distance between transmitter
and Falcon 12 plus should be at least 0.5 m, otherwise the
receiver of the Falcon 12 plus can be overdriven.
• If the Graupner Falcon 12 plus is unbound or it should be bound
to another transmitter or only the model memory has to be
changed than the previous one, proceed as follows:
1. Prepare the transmitter or model memory to be bound accord-
ing to the instructions for binding.
2. Switch on the copter power supply.
3. The LED of the Falcon 12 plus lights constantly red.
4. Approximately 15 seconds after the Falcon 12 plus is switched
on, its red LED starts to flash, indicating that the Falcon 12
plus is now in bind mode.
5. Start the transmitter-side binding according to the instruc-
tions of the transmitter.
6. If the red LED of the Falcon 12 plus goes out within about
three seconds, the binding process has been completed suc-
cessfully.
7. Your transmitter/Falcon 12 plus combination is ready for
operation.
If the LED on the Graupner S1034 Falcon 12 plus remains still
red, the "binding" has failed. Change the positions of the associ-
ated antennas and try the entire procedure again.
