Electronic Assembly; Instrument - EKKO EK20R Service Manual

b. Electronic assembly
Intelligent instrument
NO Code
1
2 GB/T 70.1-2000
3 GB/T 93-1987
4 GB/T 95-2002
5 1232SE-2421
6
7
8
9 1232SE-2421
10
11
12
13
14
15
16
Name
Aluminum plate
Hexagon socket head
screws
Elastic washer
Flat washer
Ac controller
Article copper connection
Article copper connection
The fuse
Ac controller
Fender bracket
buzzer
Electronic flasher
Main contactor
Article copper connection
Article copper connection
Aluminum plate
28
Specificati Quantit
on y
δ/10 1
M6×16 8
Φ6 8
Φ6 8
1
B- 1
B+ 2
300A 2
1
1
1
1
1
B+ 1
B+ 4
Remark
