- Page 1 ASSEMBLY INSTRUCTIONS Description : ADIRONDACK CHAIR Item No. : C-519 ITEM NO.: C-519 Printed in Vietnam REVISED DEC 06, 2016 - 1 -...
-
Page 2: Before Assembly
BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect. -
Page 3: Part List
PART LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Seat frame Back frame Front leg Cross bar (L-R) Supporter (L-R) (L-R) HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. - Page 4 STEP 1 Attach front legs (D) to seat (A) with bolts (2) and canopies (3) and attach crossbar (C) to front legs (D) with bolts (2) as shown below. Tighten with Allen keys (5). STEP 2 Attach supporters (F) to the seat (A) with bolts (2) and canopies (3) and shown below. Tighten with Allen keys (5).
- Page 5 STEP 3 Attach back (B) to the seat (A) with bolt (1) and attach back (B) to supporters (F) with bolts (2) as shown below. Tighten with Allen key (5). STEP 4 Attach arms (E) to supporters (F) with bolts (2) as shown below. Tighten with Allen key (5). Attach arms (E) to the front legs (D) with screws (4) as shown below.
- Page 6 STEP 5 Attach Somer’s Pointe (6) to back frame (B) with nails (7) as shown below. ITEM NO.: C-519 Printed in Vietnam REVISED DEC 06, 2016 - 6 -...
