- Page 1 ASSEMBLY INSTRUCTIONS Description : MAINE LADDERBACK W/WOOD SEAT Item No. : C-2170 ITEM : C-2170 Printed in Vietnam REVISED DEC 19, 2011 - 1 -...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take the time to read and follow the assembly instructions carefully. Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment.
- Page 3 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Short bolt Medium bolt (M6x40mm) (M6x60mm) Long bolt Lock Washer (M6x80mm) (M6.5x11mm) Flat Washer...
- Page 4 STEP 2 Attach front legs (D) to the seat frame with bolts (2), washers (5) and (4). Tighten with Allen key (6). Attach side stretchers (E) to front and back legs with screws (7). Tighten with a screwdriver. STEP 3 Attach seat (C) to top of the seat frame (from Step 2) with screws (7).
