- Page 1 ASSEMBLY INSTRUCTIONS Description : DROPLEAF PEDESTAL TABLE Item No. : T-42DP ITEM NO.: T- 42DP Printed in Vietnam REVISED MAR 09, 2015 - 1 -...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect.
- Page 3 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Large flat Large lock washer washer (8.5x19mm) (8.5x13mm) Hexagon nut Wrench (M8x13mm) (13mm)
- Page 4 STEP 2 Put the mounting plate (D) on top of the pedestal, and attach with bolts (8), and washers (5), and (6). Tighten with the Allen key (9). Insert the wood slides (E) into the groove of the mouting plate. STEP 3 Carefully place the base (from step 2) on the bottom side of the top (A).
- Page 5 STEP 4 Hold the dropleaf push and slide the wooden piece from underneath the table top . To lower the dropleaf, carefully hold the dropleaf with one hand and slide the wooden piece from underneath the table top towards the center of the top. Then, gently lower the leaf and place in the down position ITEM NO.: T- 42DP Printed in Vietnam...
