- Page 1 ASSEMBLY INSTRUCTIONS Description : FRANKLIN 54 IN ENTERTAINMENT CENTER Item No. : TV-56 ITEM NO.: TV-56 Printed in Vietnam REVISED JAN 16, 2016 - 1 -...
-
Page 2: Before Assembly
BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect. -
Page 3: Part List
PART LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Side panel (L-R) Vertical panel Bottom panel (L-R) Center Shelf Side shelf Door (L-R) Back panel Glass... - Page 4 STEP 1 Attach glass sections (E) to back of doors (D), and lock it. Attach knobs (4) to doors (D) with pan head screws (5) as shown below. Tighten with a screwdriver. STEP 2 Attach panels (G) to top (A) and bottom panel (B) with bolts (1), and washers (2) and (3) as shown below.
- Page 5 STEP 3 Attach side panels (F) to the unit with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (7). STEP 4 Attach back panel (I) to the unit with pan head screws (8) as shown below. Tighten with the screwdriver.
