Summary of Contents for International Concepts CU-15
- Page 1 ASSEMBLY INSTRUCTIONS Description : MEDIA CABINET RTA Item No. : CU-15 ITEM NO. : CU-15 Printed in Vietnam REVISED MAR 24, 2016 - 1 -...
-
Page 2: Before Assembly
Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO. : CU-15 Printed in Vietnam REVISED MAR 24, 2016 - 2 -... -
Page 3: Part List
(ɸ6.5x11mm) Short pan head Short screw screw (M3.5x15mm) (M3.5x15mm) Knob Long screw (ɸ30x30mm) (M4x30mm) Long pan head screw Steel band (M4 x 25mm) Allen key (M4x80mm) ITEM NO. : CU-15 Printed in Vietnam REVISED MAR 24, 2016 - 3 -... - Page 4 Insert rail (H) into side panels (C) and (D) as shown below. Then attach shelves (E) and (F) (from step 1) to right side panel (C) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (11). ITEM NO. : CU-15 Printed in Vietnam...
- Page 5 Slide back panel (I) into grooves of top (A), and side panels (C) and (D). Then attach back panel to the unit with pan head screws (5) as shown below. Tighten with a screwdriver. ITEM NO. : CU-15 Printed in Vietnam...
- Page 6 Attach steel band (10) to the unit with screws (6) and attach steel band (10) to the wall with screw (7) as shown below (to secure the product and prevent tipping). Tighten with a screwdriver. ITEM NO. : CU-15 Printed in Vietnam...
