What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
Vesa Studio Monitor
Mount for Stand
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
PhotoBooth Studio Kit - Camera
Platform
A s s e m b l y M a n u a l
22" Telescoping Arm
Articulating Arm
statutes or in writing by the Publisher.
(P-PTBH-01)
All rights reserved.
1
Camera Platform
Cold Shoe Mount
(Baby Stud Adapter with
1/4" 20 female thread on
one side and 3/8" female
thread
on the other side)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PROAIM P-PTBH-01
Summary of Contents for PROAIM P-PTBH-01
- Page 1 PhotoBooth Studio Kit - Camera Platform (P-PTBH-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
- Page 2 Monitor Mount Setup Mount the monitor mount on the C-stand and tighten it using the back knob. Note: Monitor Mount is the best way to mount your LCD monitor on a C-stand, light-stand, or other stands with 5/8" baby pins/studs. ...
- Page 3 Articulating Arm Setup Loosen the knob of the articulating arm, and open the arm completely. Align and insert the arm into the thread on the monitor mount. Note: The articulating arm is movable and helps move the camera's direction. ...
- Page 4 Insert the 22" telescoping arm into the monitor mount and secure it with the help of the knob. Note: You can use the Proaim 20" Telescoping Arm for everything from overhead lighting to stand extension. Note: Twist the knob, and the aluminum arm telescopes from 11.5"...
- Page 5 Image showing Monitor Mount, Articulating Arm, Camera Platform, 22" Telescoping Arm & Cold Shoe Mount assembled adequately. Insert the umbrella into the clamp and secure it correctly with the knob. Note: This umbrella has been specially designed for the photobooth setup. ...
- Page 6 YOUR PROAIM PHOTOBOOTH STUDIO KIT - CAMERA PLATFORM ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
