Explorer Pro Pan Tilt Head for Camera Jib Crane
(PT-EXPR-02)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
15mtr Cable
Universal
3mtr Cable
12V AC Adapter
Adapter
Controller Box
2 x Camera Bolts
4 x Bolts
(Sizes: 1/4"-20 , 3/8"-16)
(Sizes: 1/4"-1")
Pro Pan Tilt Head
4 x Knobs
O-Ring
4 x Washers
4 x Bolts
4 x Bolts
Bolt
(Sizes: 1/4"-3/4")
(Sizes: 1/4"-5/8")
2 x Fuse
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
