Power; Interface Connections; Figure 2-16. Analog Digital Converter Board/Integrator Multiplexor Board Interconnection Diagram - Hologic QDR 4500 Technical Manual

Power

The Integrator/Multiplexor board receives +/-15V and +5V from the Analog To Digital board.
The +/-15V is passed through this board to the Solid State Detector boards. Voltage regulators,
located on this board, convert this voltage to +/-12V to power circuitry contained on this board.
Analog and digital returns are kept separate.

Interface Connections

Figure 2-16 shows the interconnections between the Analog/Digital Converter board and the
Integrator/Multiplexor board. Table 2-22 describes the interface signals and identifies the
interconnection connector and pin assignments.
ANALOG/DIGITAL
CONVERTOR
BOARD
Figure 2-16. Analog Digital Converter Board/Integrator Multiplexor
Section 2 - Functional Description
MA1, MA2
MB1, MB2
MC1, MC2
MD1, MD2
MUX0 - MUX3
MGN1, MGN2
GPL1, GPL2
LTCH1, LTCH2
INTEG
DISC
TSTEN
BB0
BB1
BB2
BB3
+15V
15V_RTN
-15V
+5V
GND
Board Interconnection Diagram
INTEGRATOR/MULTIPLEXOR
BOARD
