C34 Classic™ Direct Vent
Freestanding Gas Stove
MODELS:
C34-NG11 Natural Gas
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
2017
920-092f
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
C34-LP11 Propane
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
ANSI Z21.88-
Homeowner: Please keep these instructions for future reference.
CSA 2.33-2017
Owners &
Installation Manual
C34 Video
www.regency-fire.com
03.31.22
