Ultimate™ U39 Freestanding Gas Stove
MODELS: U39-NG13 Natural Gas
Warning
Fire or Explosion Hazard
Failure to follow safety warnings exactly could result in
serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
04.05.18 -- updated log instructions
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
920-439
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
U39-LP13 Propane
Installer: Please complete the details on the back cover
ANSI Z21.88-2019
and leave this manual with the homeowner.
CSA 2.33-2019
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
www.regency-fire.com
01.05.22
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products U39-NG13
Summary of Contents for Regency Fireplace Products U39-NG13
- Page 1 Owners & Ultimate™ U39 Freestanding Gas Stove Installation Manual www.regency-fire.com MODELS: U39-NG13 Natural Gas U39-LP13 Propane Warning Fire or Explosion Hazard Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 REGENCY ® ULTIMATE Direct Vent Freestanding Gas Stove To the New Owner: Congratulations! You are the owner of a state-of-the-art ULTIMATE Direct Vent Gas Stove by FPI Fireplace Products International Ltd. The Regency Gas Series of hand crafted appliances has been designed to provide you with all the warmth and charm of ®...
-
Page 3: Table Of Contents
table of contents Dimensions ..............4 Aeration Adjustment ............30 On Demand Pilot Light ..........30 Copy of Safety Label for U39 Gas Stove ....5 Log Set Installation ............31 Log Set Installation ............33 Installation Wiring Diagrams ............37 Gas Installation Checklist ..........7 Optional Wall Thermostat ...........38 Before You Start .............9 DC Spark Igniter Battery Install ........38 Important Message ............10... -
Page 4: Dimensions
dimensions 9 13 16 " (250mm) ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. Regency U39-13 ULTIMATE™ Freestanding Gas Stove ®... -
Page 5: Copy Of Safety Label For U39 Gas Stove
1.6" WC/C.E. (0.40kPa) B 6" /150mm Fonctionnant à une altitude entre 0 et 2000 pi : Model U39-NG13: Factory Equipped for Altitude 0-2000 ft. E 2" /50mm Min. Ceiling Height from top of unit / Min. Plafond Orifi ce size Dimensions de l’orifi... - Page 6 requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...
-
Page 7: Gas Installation Checklist
installation Gas Installation Checklist REGENCY GAS INSTALLATION CHECKLIST This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority. Customer: Date Installed: Install Address:... - Page 8 installation REGENCY GAS INSTALLATION CHECKLIST Finishing If applicable, is only noncombustible material installed in the noncombustible areas? Do clearances meet installation and manual requirements? Do the mantels and/or projections comply with the installation manual? If applicable, was the solid fuel fireplace warning plate installed? Appliance Media Setup Do commands from the remote or wall switch light the pilot and main burner? Are the burner media/log set, glass door, and screen installed per instructions in the manual?
-
Page 9: Before You Start
installation Important Information on the WARNING: FAILURE TO INSTALL THIS IF THE BARRIER BECOMES DAMAGED, U39-13 APPLIANCE CORRECTLY WILL VOID THE BARRIER SHALL BE REPLACED YOUR WARRANTY AND MAY CAUSE A WITH THE MANUFACTURER'S BARRIER MODEL U39-13 SERIOUS HOUSE FIRE. FOR THIS APPLIANCE. -
Page 10: Important Message
Fuels: when used with a Listed Millivolt Thermostat. of gas indicated on the rating plate. U39-NG13 is approved for use with natural gas. Some areas may have further requirements, This appliance is not convertible for check local codes before installation. -
Page 11: General Safety Information
installation General Safety Installation Before leaving this unit with the customer, the installer must ensure that the appliance is firing Information Checklist correctly and operation fully explained to customer. 1. The appliance installation must conform with 1. Locate your appliance. Refer to the following local Canadian Electrical Code. -
Page 12: Manufactured Mobile Home Additional Requirements
installation Safety Screen A) Cross Corner Installation B) Room Divider C) Island Attach the safety screen by placing screen D) Flat on Wall over the glass door. E) Flat on Wall Corner F) Flush with Wall/ Alcove To remove, lift up slightly and pull away from unit. -
Page 13: Exterior Vent Terminal Locations
installation Exterior Vent Terminal Locations Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 18"(46cm) 18"(46cm) from the center line of the terminal (check with the local code) -
Page 14: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
installation 4” x 6-5/8” Rigid Pipe Cross Reference Chart Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI. 4" X 6-5/8" RIGID PIPE CROSS REFERENCE CHART Note: Olympia Ventis DV venting is only approved for certain models. See list of approved models in cross-reference chart. Components from different Manufacturers may not be mixed. - Page 15 installation Description Simpson *Selkirk *American Metal *Metal-Fab™ *Security *ICC Excel *Olympia Direct Vent Pro ® Direct Temp™ Products® Sure Seal Secure- Vent® Direct Ventis DV*** Amerivent Direct Attic Insulation Shield 12" 46DVA-IS 4DAIS12 4DIS SV4RSA VDV-AIS04 Attic Insulation Shield 4DAIS12 TM-4AS - Cold Climates 36"...
-
Page 16: Rigid Pipe Venting Systems
installation Rigid Pipe Venting Systems Horizontal or Vertical Terminations Alternate Horizontal Ter- mination Caps WARNING: Do not combine venting components from different venting systems. However use of the the AstroCap and FPI Riser is acceptable with all systems. This product has been evaluated by Intertek for using a Rigid Pipe Adaptor in conjunction When using Rigid Vent other than with Duravent Direct-Vent, Selkirk Direct-Temp,... -
Page 17: Installation Precautions
installation Installation Precautions These venting systems are engineered products that have been designed and tested for use with the U39-LP13. The warranty will be voided and serious fire, health or other safety hazards may result from any of the following actions: 1. -
Page 18: Rigid Pipe Venting Arrangements
installation Rigid Pipe Venting Arrangements Horizontal Terminations for All Vertical Termination Systems for Venting Systems Residential Manufactured and Mobile Homes The shaded areas in the diagram below show all allowable combinations of vertical runs with The shaded area in the diagram below shows all horizontal terminations. - Page 19 installation Horizontal Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows Option H + H1 3' Min. 2' Max. 5' Min. 3' Max. 8' Min. 4' Max. With these options, maximum total pipe length is 30 feet with minimum of 8 feet total vertical and maximum 4 feet total horizontal.
-
Page 20: Dv Stove Horizontal Vent Kit Installation
installation DV Stove Horizontal Vent Kit (# 946-116 & #946-216) DV Stove Horizontal Vent Kit 2 ft. (Part # 946-116) or 4 ft. (Part # 946-216) includes all the parts needed to install the U39 with minimum horizontal and vertical vent dimensions. For installations that require longer vertical and/or horizontal vents see the "Dura-vent Termination Kit” and “Component" sections. Qty. - Page 21 installation Dismantle all pipe sections including vent terminal. 3. Attach the 4" dia. flex liner to the vent terminal ensuring that the flex overlaps the collar of the vent terminal by a minimum of 1-3/8"(35mm). Use Mill-Pac to seal and secure with 3 of the #8 x 1/2"...
-
Page 22: Dura-Vent Termination Kit
installation Dura-Vent Termination Kit Dura-Vent Venting Components Minimum components for a Dura-Vent Horizontal Installation: You will require the following components with Planning Your Dura-Vent Dura-Vent Horizontal Termination Kit your new Regency ® Direct Vent Freestanding Gas Installation Wall Thimble (required for combus- Stove. -
Page 23: Dura-Vent Horizontal Terminations
installation Dura-Vent Horizontal Note: Note: a) Twist-lock procedure: Four indentations, located a) The horizontal run of vent should have a 1/4 inch Terminations on the female ends of pipes and fittings, are rise for every 1 foot of run towards the termination. designed to slide straight onto the male ends Never allow the vent to run downward. -
Page 24: Dura-Vent Vertical Terminations
installation Dura-Vent Vertical Terminations Note: If installing termination on a siding covered Below Grade Installation wall, a vinyl siding standoff or furring strips must If the Snorkel Termination must be installed below be used to ensure that the termination is not grade, i.e. -
Page 25: Cathedral Ceilings
installation 4. Assemble the desired lengths of black pipe and Offset Chart Roof Pitch Minimum Vent Height elbows necessary to reach from the appliance adaptor up though the Round Support Box. Feet Meters Insure that all pipes and elbow connections are flat to 7/12 0.61 in the fully twist-locked position and sealed. -
Page 26: Converting A Class-A Metal Chimney To A Direct Vent System
installation Converting a Class-A Metal 1. Remove the existing chimney cap. If the support extends above the roof, cut it flush with the top of the roof. Nail the support to the Chimney to a Direct Vent System 2. Measure the distance from the top end of the frame opening using (8) 3"... -
Page 27: System Data
installation Gas Connection System Data U39-13 The gas connection is a 3/8" NPT 90 elbow. The gas Altitude for 0 to 2000 feet line can be rigid pipe or to make installation easier, use a listed flexible connector and/or copper tubing if allowed by local codes. -
Page 28: Conversion From Ng To Lp
installation Conversion from NG to LPG using SIT 829 NOVA Gas Valve Conversion from NG to LP THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! IF IN DOUBT DO NOT DO THIS CONVERSION !! 6. R emove four screws to remove the ac- Each Kit contains one LPG 12. Remove burner orifice with a 1/2"... -
Page 29: Conversion To Lower Btu Rating
installation Gas Pipe Pressure Testing Conversion to High Elevation CONVERSION TO HIGH ELEVATION The appliance must be isolated from the gas supply THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER piping system by closing its individual manual shut- THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS off valve during any pressure testing of the gas IF IN DOUBT DO NOT DO THIS CONVERSION !! -
Page 30: Sit 829 Valve Description
2. Electronically Operated Hi/Lo 3. Pilot Adjustment U39 with 38,000 Btu/h 4. Thermocouple Connection - option U39-NG13 Natural Gas: Full open 5. Outlet Pressure Tap U39-LP13 Propane: Full open 6. Inlet Pressure Tap 7. Pilot Outlet U39 with 35,000 Btu/h 8. -
Page 31: Log Set Installation
installation U38 / U39 Log Set Installation LOG SET INSTALLATION Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot operation. The gas log kit contains the following: Place the Middle Left Log B on the two pins as shown. - Page 32 U38 / U39 installation 6 Place Front Right Log E on the two pins as shown. Side View Bracket The bottom right edge of Log G must sit snugly against the bracket Place the notch in Center Log F over Log E and across the cut-out on Log A.
- Page 33 U38 / U39 installation 11. Using the harder coal like embers carefully spread these around the OUTSIDE of the burner (1 cup on each side). Do not place or use these hard material embers on top of the burner. Coal Embers--outside burner only! 12.
-
Page 34: Log Set Installation
installation LOG SET INSTALLATION Driftwood Log Set Installation Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot operation. The driftwood log kit contains the following: Place the Middle Left Log B on the two pins as shown. - Page 35 installation 6 Place Front Right Log E on the two pins as shown. Side View Bracket The bottom right edge of Log G must sit Place the notch in Center Log F over snugly against the bracket Log E and across the cut-out on Log A. 9.
- Page 36 installation 11. Using the harder coal like embers carefully spread these around the OUTSIDE of the burner (1 cup on each side). Do not place or use these hard material embers on top of the burner. Coal Embers--outside burner only! 12.
-
Page 37: Wiring Diagrams
installation Wiring Diagrams NOTE: Even if the fan is not purchased This heater does not require a 120V A.C. supply (Do not cut the ground terminal off under any for operation. In case of a power failure, the burner circumstances.) with the unit, it is still a good idea switch and the optional remote control/thermostat to bring power to the receptacle box... -
Page 38: Optional Wall Thermostat
installation Optional Wall Thermostat DC Spark Igniter Battery Install 5. Open the battery compartment door on the DC spark box A wall thermostat may be installed if desired. Connect the wires as per the wiring diagrams. 6. Install battery into DC spark box. Note that the wires are connected to the "TH"... -
Page 39: First Fire
operating instructions First Fire NOTE: This appliance will operate during power 5. Press and release the ON/OFF button on the outages. Only the fan will not operate until power remote handheld transmitter. An audible beep The first fire in your stove is part of the paint curing is restored. -
Page 40: Copy Of Lighting Plate Instructions
operating instructions Copy Of Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 41: Automatic Convection Fan Operation
operating instructions Automatic Convection Fan Normal Operation Operating Sounds of Gas Appliances The fan operates on this appliance with the remote control supplied. The fan will turn on as the stove It is possible that you will hear some sounds from comes up to operating temperature. -
Page 42: Proflame Gtmf System Operating Instructions
operating instructions Proflame GTMF System Operating Instructions System Description Operating Procedure Initializing the System for the first time The Proflame Remote Control System consists of three elements: 1. Proflame Transmitter. Install the 4 AA batteries into the receiver battery bay. Note the polarity of the battery and insert into the battery bay as indicated on the Battery cover (+/-). - Page 43 operating instructions Turn on the Appliance Room Thermostat (Transmitter Operation) Press the ON/OFF Key on the Transmitter. The Transmitter display will show all active Icons on the screen. At the same time the Receiver connects the The Remote Control can operate as a room thermostat. The thermostat thermopile to the gas valve millivolt coil and the appliance main burner turns can be set to a desired temperature to control the comfort level in a room.
- Page 44 operating instructions Fan Speed Control Key Lock If the appliance is equipped with a hot air circulating fan, the speed of the fan This function will lock the keys to avoid unsupervised operation. can be controlled by the Proflame system. The fan speed can be adjusted through six (6) speeds.
-
Page 45: Maintenance Maintenance Instructions
maintenance Maintenance Incorrect flame pattern will have small, probably DO NOT USE THIS APPLIANCE IF ANY yellow flames, not coming into proper contact with Instructions PART HAS BEEN UNDER WATER. the rear of the burner or thermopile. IMMEDIATELY CALL A QUALIFIED 1. -
Page 46: Log Replacement
maintenance Panel Glass Installing Glass Log Replacement Replacement The unit should never be used with broken logs. Turn 1. Place glass assembly into door frame. off the gas valve and allow the unit to cool before 1. Remove the door from the unit and place on a opening door to carefully remove the logs. -
Page 47: Fan Maintenance
maintenance Fan Maintenance To Remove U39 Fan from front of Unit: If your fan requires maintenance or replacement, Unclip these 1. Unplug or disconnect power source to stove. 2 wires access to the fan is through the plate on the rear Access wall of the firebox. -
Page 48: Valve Replacement
maintenance Valve Replacement If the valve requires maintenance or replacement, 8. Disconnect the gas at the valve. Access through use the following instructions: the front (with access panel removed) The gas line may also be accessed by removing the rear pedestal cover plate. -
Page 49: Gas Maintenance
maintenance Gas Maintenance Gas Maintenance Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter • Pressure relief gaskets/doors • Ohms reading on flame sense (electronic •... -
Page 50: Main Assembly
parts list Main Assembly Part # Description Part # Description 732-929 Safety Screen 730-019 Rear Panel 560-921 Louver Assy - Brush Nickel 730-565 Firebox Baffle 630-520 False Top Assembly 560-922 Louver Assy - Black 923R Starter Collar 732-513 Relief Door Assembly 936-194 Gasket-Starter Collar/Air Passage 732-022... -
Page 51: Burner & Log Assembly
parts list Burner & Log Assembly Part # Description 734-574/P Valve Assembly- Natural Gas 734-576/P Valve Assembly - Propane 911-268 Valve Only- Natural Gas 911-270 Valve Only - Propane 910-038/P Pilot Assy - S.I.T. - 3 Flame NG 910-039/P Pilot Assy - S.I.T. - 3 Flame LP 904-688 #32 Orifice - NG at 38,000 Btu/h 904-644... -
Page 52: Door Assembly
parts list Door Assembly Part # Description 732-943 Black Wrap Door - Complete 732-944 Brushed Nickel Wrap Door - Complete 101. 732-570 Door Gasket Kit 105. Ceramic Paper 107. 936-243 Glass Gasket 111. Door Frame Fibre Paper 208. 940-325/P Wrap Glass 209. - Page 53 notes Regency U39-13 ULTIMATE™ Freestanding Gas Stove ®...
-
Page 54: Warranty
warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below. - Page 55 warranty At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you).
- Page 56 warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
- Page 57 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 60 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ U38-39 Video Printed in Canada Regency is a trademark of FPI Fireplace Products International Ltd. ® © Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
