Regency Fireplace Products FireGenie FG37-NG Manual

Freestanding gas stove

Advertisement

Quick Links

Owners &
Installation
Your unit should be serviced
annually by an authorised service
person.
All manuals and user guides at all-guides.com
Freestanding Gas Stove
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Models: FG37-NG
FG37-LPG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FireGenie FG37-NG and is the answer not in the manual?

Questions and answers

Pasquale DiFilippo
May 21, 2025

When I try to go from pilot position to the on position the pilot light goes out I even tried to hold nob down for 5 minutes still goes out going from pilot to on I was having issues before this started the fire would not come on again until cooled down after turning it off and if I tapped the bottom of fire place it would come on

2 comments:
Mr. Anderson
May 24, 2025

The pilot light on the Regency Fireplace Products FireGenie FG37-NG could go out when switching from "pilot" to "on" due to improper vent restrictor settings or issues with the airflow. If the vent is too restricted, it can cause poor combustion or backdraft, leading to the pilot flame being extinguished. Adjusting the vent restrictor plate to ensure proper airflow may resolve the issue.

This answer is automatically generated

Pasquale
May 31, 2025

@Mr. Anderson The plumber replaced the thermocouple and the thermopile now the pilot stays on but still have an issue When I turn off the switch on while heater is hot the flames won’t come back on until heater cools down

Pasquale DiFilippo
June 1, 2025

The plumber replaced the thermocouple and the thermopile now the pilot stays on but still have an issue When I turn off the switch on while heater is hot the flames won’t come back on until heater cools down It’s a Genie F37N free standing fire place

1 comments:
Mr. Anderson
June 1, 2025

If the flames do not come back on in the Regency Fireplace Products FireGenie FG37-NG after turning off the switch while the heater is hot, it could be due to the safety system or thermal sensor preventing immediate reignition. The unit may require a cool-down period before it can restart.

This answer is automatically generated

Summary of Contents for Regency Fireplace Products FireGenie FG37-NG

  • Page 1 All manuals and user guides at all-guides.com Owners & Installation Freestanding Gas Stove Models: FG37-NG FG37-LPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Your unit should be serviced annually by an authorised service person.
  • Page 2: Specifications Diagram

    All manuals and user guides at all-guides.com Congratulations! You are the owner of a state-of-the-art Regency Rear Flued Room Sealed Freestanding Gas Stove by FPI Fireplace Products International. The Regency Gas Series of hand crafted appliances has been designed to provide you with all the warmth and charm of a woodstove, at the flick of a switch.
  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS Page Page Specifications diagram ..........2 Data Plate ..............4 Operating Instructions ..........19 Lighting Procedure ............ 19 Resetting the Unit ............. 19 Shutdown Procedure ..........19 Specifications ............. 5 First Fire ..............
  • Page 4: Data Plate

    All manuals and user guides at all-guides.com DATA PLATE NOTE: (Australia Only)
  • Page 5: Specifications

    All manuals and user guides at all-guides.com INSTALLATION IMPORTANT: SAVE THESE INSTRUCTIONS GENERAL SAFETY INFORMATION Note: Failure to follow the instructions could cause a malfunction of the heater which could result in death, serious bodily injury, and/or prop- erty damage. Failure to follow these instructions may also void your fire insurance and/or warranty.
  • Page 6: Installation Checklist

    All manuals and user guides at all-guides.com INSTALLATION LOCATING YOUR REGENCY GAS STOVE FG37-NG & FG37-LPG Clearances INSTALLATION FG37-NG & FG37-LPG CHECKLIST Reference Dimensions operation fully explained to customer. CLEARANCES TO COMBUSTIBLES This includes: COMBUSTION AND The farthest distance is correct if the two clearances VENTILATION AIR do not coincide.
  • Page 7: Exterior Flue Terminal Locations

    All manuals and user guides at all-guides.com INSTALLATION EXTERIOR FLUE TERMINATION LOCATIONS...
  • Page 8: Fluing Installation Precautions

    All manuals and user guides at all-guides.com INSTALLATION FLUING FLUING INSTALLATION PRECAUTIONS IMPORTANT SAFETY PRECAUTIONS FOR THE INSTALLER PLANNING YOUR FLUING INSTALLATION See page 7 for Exterior Flue Termination requirements.
  • Page 9: Fluing Arrangements - Vertical Terminations

    All manuals and user guides at all-guides.com INSTALLATION FLUING ARRANGEMENTS - VERTICAL TERMINATIONS FOR BOTH RESIDENTIAL & MANUFACTURED HOMES/MOBILE HOMES The shaded area in the diagram shows the allowable vertical The shaded areas in the two diagrams below show all allowable terminations installed in a masonry chimney.
  • Page 10: Fluing: Residential And Manufactured Homes/Mobile Homes Installation

    All manuals and user guides at all-guides.com INSTALLATION RESIDENTIAL AND MANUFACTURED HOMES/ MOBILE HOMES INSTALLATIONS Note: These are the minimum pieces required. Other parts may be required for your particular installation. Minimum components for a Horizontal Installation: Optional Components: HORIZONTAL INSTALLATIONS c) Snorkel Terminations: Diagram 1 Note:...
  • Page 11 All manuals and user guides at all-guides.com INSTALLATION NOTE: For Snorkel terminations in ABOVE grade installations, follow national or local code requirements. Below Grade Snorkel Installation Diagram 5 Hint: Apply sealant to female end. IMPORTANT: When connecting the pipe to the Riser Vent, apply Mill-Pac to the inner pipe on the Riser Vent Terminal, around the bead.
  • Page 12: Vertical Termination With Co-Linear Flex System

    All manuals and user guides at all-guides.com INSTALLATION VERTICAL TERMINATION WITH GAS CONNECTION CO-LINEAR FLEX SYSTEM THE APPLIANCE MUST NOT BE CONNECTED TO A CHIMNEY FLUE SERVING A SEPARATE SOLID FUEL BURNING APPLIANCE. keep the flexible liner as straight as possible Important: Always check for gas leaks with a soap and water solution or gas leak detector.
  • Page 13: Conversion From Ng To Lpg

    All manuals and user guides at all-guides.com INSTALLATION Conversion Kit for NG to LPG Model #516-969 Antenna Control Box Cover Pilot Pilot Pilot Orifice Assembly Extrusion Tube Jumper Location Jumper Burner Orifice Pilot Tube...
  • Page 14 All manuals and user guides at all-guides.com INSTALLATION Adjusting the Outlet Pressure Maximum pressure: NOTE: Minimum pressure: NOTE: Cable Electric Modulator WARNING:...
  • Page 15: Aeration Adjustment

    All manuals and user guides at all-guides.com INSTALLATION AERATION LOG SET ADJUSTMENT INSTALLATION Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until they are A)02-65 replaced. Broken logs can interfere with 10mm open the pilot operation.
  • Page 16: Door Installation

    All manuals and user guides at all-guides.com INSTALLATION DOOR INSTALLATION (Packaged Separately) G)02-48 A)02-65 A)02-65 D)02-46 B)02-56 E)02-45 C)02-44 Notch Cutout Diagram 1 G)02-48 E)02-45 E)02-45 Side View Bracket The bottom right edge of Log G)02-48 must sit snugly against the bracket Diagram 2 A)02-65 B)02-56...
  • Page 17: Gas Pipe Pressure Testing

    All manuals and user guides at all-guides.com INSTALLATION GAS PIPE PRESSURE LOUVRE TESTING INSTALLATION Note: To properly check gas pressure, both inlet and manifold pressures should be checked using the valve pressure ports on the valve. Note: Screw should be snug, but do not over tighten...
  • Page 18: Optional Remote Control Installation

    All manuals and user guides at all-guides.com INSTALLATION OPTIONAL FINAL CHECK REMOTE CONTROL CAUTION Any alteration to the product that causes sooting or carboning that results in dam- age to the exterior facia is not the respon- sibility of the manufacturer. WIRING...
  • Page 19: Operating Instructions

    All manuals and user guides at all-guides.com OPERATING INSTRUCTIONS OPERATING RESETTING FAN OPERATION INSTRUCTIONS THE UNIT SHUTDOWN Control Panel INSTRUCTIONS LIGHTING FIRST FIRE INSTRUCTIONS FIRST FIRE ADJUSTING FLAME HEIGHT NOTE: NOTE:...
  • Page 20: Normal Operating Sounds Of Gas Appliances

    All manuals and user guides at all-guides.com OPERATING INSTRUCTIONS SUMMARY OF NORMAL OPERATING PILOT ADJUSTMENT CONTROLS SOUNDS OF GAS APPLIANCES On/Off Button: nor- mal operating sounds NOTE: If you have an incorrect flame Flame: pattern, contact your Regency dealer for Increase - further instructions.
  • Page 21: Copy Of Lighting Plate Instructions

    All manuals and user guides at all-guides.com OPERATING INSTRUCTIONS COPY OF THE LIGHTING PLATE INSTRUCTIONS A ) BEFORE LIGHTING smell all around the appliance B) Do not use this appliance if any part has been area for gas. Be sure to smell next to the floor under water.
  • Page 22: Maintenance Instructions

    All manuals and user guides at all-guides.com MAINTENANCE MAINTENANCE GOLD-PLATED DOORS INSTRUCTIONS void the warranty.
  • Page 23: Latch Adjustment

    All manuals and user guides at all-guides.com MAINTENANCE LATCH ADJUSTMENT Do not remove the nuts under- neath the retainers. Note: Center glass retainers are glued to center glass. LOG REPLACEMENT Note: Improper positioning of logs may create carbon build-up and will al- The glass must have ter the unit’s performance which gasketing around it.
  • Page 24: Fan Maintenance

    All manuals and user guides at all-guides.com MAINTENANCE FAN MAINTENANCE Hint for pushing fan down onto pins - rub a bit NOTE: the unit of dish soap on the grommet so it will slide MUST NOT be operated without the fan more easily onto the pin.
  • Page 25: Removing Valve

    All manuals and user guides at all-guides.com MAINTENANCE REMOVING VALVE TRAY NOTE: Always shut off the gas and dis- connect the power supply before removing the valve. Ground 5 Pin Wire Molex Connector Manual Switch Reset Cables Cable...
  • Page 26: Electronic Components List

    All manuals and user guides at all-guides.com PARTS LIST ELECTRONIC COMPONENTS PARTS LIST 910-915 910-082 910-089 910-088 910-912 910-084 910-526 910-080 910-906 910-083 910-514 910-521, 910-522, 910-523 910-916 Fan Resistor Intermittent Pilot Direct Spark Ignitor Flame Cable Spark Cable Control Box Manual Control Valve Control Box Cable...
  • Page 27: Replacement Parts List

    All manuals and user guides at all-guides.com PARTS LIST FG37 MAIN ASSEMBLY Part # Description Part # Description Part # Description...
  • Page 28 All manuals and user guides at all-guides.com PARTS LIST FG37 BURNER & LOG ASSEMBLY Part # Description Part # Description...
  • Page 29 All manuals and user guides at all-guides.com PARTS LIST FG37 DOOR ASSEMBLIES Part # Description...
  • Page 30 All manuals and user guides at all-guides.com NOTES _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ____________________________________________________________ __________________________________________________________ ____________________________________________________________...
  • Page 31: Warranty

    All manuals and user guides at all-guides.com WARRANTY This limited Lifetime Warranty does not extend to or include paint, door or glass gasketing or trim. It does not cover installation and operational related problems such as over- firing, downdrafts or spillage caused by environmental con- ditions, nearby trees, buildings, hilltops, mountains, inade- quate flueing or ventilation, excessive offsets, negative air pressures caused by insufficient make up air, mechanical...
  • Page 32 All manuals and user guides at all-guides.com...

This manual is also suitable for:

Firegenie fg37-lpg
