Summary of Contents for ESD VME-DIO32-L
- Page 1 VME-DIO32-L Hardware Manual Doc. Nr.: M.1607.27 / Rev 1.0 Page 1 of 22 esd electronics gmbh Vahrenwalder Str. 207 • 30165 Hannover • Germany http://www.esd.eu Phone: +49 (0) 511 3 72 98-0 • Fax: +49 (0) 511 3 72 98-68...
- Page 2 design.
- Page 3 The changes in the document listed below affect changes in the hardware as well as changes in the description of the facts, only. Rev. Chapter Changes versus previous version Date First English manual for VME-DIO32-L 2022-03-18 Technical details are subject to change without further notice. VME-DIO32-L Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0...
- Page 4 This NOTICE statement contains the general mandatory sign and gives information that must be heeded and complied with for a safe use. INFORMATION INFORMATION Notes to point out something important or useful. Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0 Page 4 of 22 VME-DIO32-L...
-
Page 5: Safety Instructions
● The VME-DIO32-L may become warm during normal use. Always allow adequate ventilation around the VME-DIO32-L and use care when handling. ● Do not operate the VME-DIO32-L adjacent to heat sources and do not expose it to unnecessary thermal radiation. Ensure an ambient temperature as specified in the technical data. - Page 6 The intended use of the VME-DIO32-L is the operation as VME board with digital I/Os. The guarantee given by esd does not cover damages which result from improper use, usage not in accordance with regulations or disregard of safety instructions and warnings.
-
Page 7: Table Of Contents
Table 13: Order information software ................... 22 Table 14: Available manuals ......................22 List of Figures Figure 1: Block circuit diagram of VME-DIO32-L ................8 Figure 2: PCB top view of VME-DIO32-L ..................10 Figure 3: Front panel with LEDs and ADDR switch ............... 11 VME-DIO32-L Hardware Manual Doc. -
Page 8: Overview
PWM operations, and generation of interrupts are not supported by the VMEDIO32-L. The VME-DIO32-L comes with a green and a red LED in the front panel for each of the 32 I/O- channels. All LEDs are located on the front panel. The green LEDs indicate the input status, and the red LEDs indicate the output short-circuit of the individual channels. -
Page 9: Abbreviations
Overview 1.2 Abbreviations Abbreviation Term Central Processing Unit Hardware Input/Output Least Significant Bit Most Significant Bit n.a. not applicable Operating System Software Development Kit Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0 VME-DIO32-L Page 9 of 22... -
Page 10: Hardware
Hardware 2 Hardware 2.1 PCB View Figure 2: PCB top view of VME-DIO32-L NOTICE Read chapter “Hardware Installation” on page 15, before you start with the installation of the hardware! Page 10 of 22 Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0... -
Page 11: Leds
Hardware 2.2 LEDs The VME-DIO32-L comes with 3 general LEDs (BSY, OOK, OER) and 2 LEDs for each I/O-channel (STAT1- STAT 32 and I/O1 -I/O32) Function Colour Description (LED on) Busy Yellow Access to the board via VMEbus All outputs are working properly,... -
Page 12: Coding Switches
Hardware 2.3 Coding Switches The VME-DIO32-L comes with a rotary switch (SW111) and three DIP switches (SW110, SW120, SW121) for the adjustment of the VMEbus base address. The modifiers (AM0 - AM2 and AM2E) can be set via switch SW130. -
Page 13: Vme Base Address
VMEbus base address: Table 3: VME base address 2.3.4 Address-Modifier (SW130) The VME-DIO32-L can be operated with access modes A24/D16 (standard). At the default setting of the DIP-switch SW130 (see Table 2, page 12), A24/D16 accesses to the board are enabled. -
Page 14: Table 4: Vme Permissible Positions Of Am2 And Am2E
Standard supervisory data access OR Address bit Standard non-privileged data access Standard supervisory data access Address bit Standard non-privileged data access Table 5: Recommended access modes for standard accesses (A24) Page 14 of 22 Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0 VME-DIO32-L... -
Page 15: Hardware Installation
“Coding Switches” from page 12. The lower VMEbus address can also be easily set later via the rotary switch in the front panel. Disconnect the VME system from the mains. Make sure that no risk arises from the system into which the VME-DIO32-L shall be inserted. WARNING Hazardous Voltage Risk of electric shock due to unintentional contact with uninsulated live parts with high voltages. -
Page 16: Technical Data
Eurocard Double-height (6U), 1 slot width Dimensions /160 mm x 233,35 mm x 20,1 mm (length, width, hight) Weight Ca. 470 g Table 6: General data of the module Page 16 of 22 Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0 VME-DIO32-L... -
Page 17: Vme Interface
Table 7: VME interface 4.3 Connectors accessible from Outside Function, Name Type Interfaces VMEbus DIN41612, type C, 96-pin. Inputs/Outputs DIN41612, type C, 64-pin. Table 8: Connectors, accessible from outside Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0 VME-DIO32-L Page 17 of 22... -
Page 18: Digital Inputs/Outputs
Protective circuits of the Safety fuse 6.3 A for each group of 8 channels, power supply after activation of the fuse, the VME-DIO32-L has to be returned to esd for an expert repair. Transient protection from 39 V Digital Inputs Input voltage range -3 V ... -
Page 19: Description Of The Hardware Registers
DIN06 DIN05 DIN04 DIN03 DIN02 DIN01 DIN16 DIN15 DIN14 DIN13 DIN12 DIN11 DIN10 DIN09 (CIO Status) Table 10: Input register VME-DIO32-L 5.2 OUTPUT-Register (read/ write) Local Address DOUT32 DOUT31 DOUT30 DOUT29 DOUT28 DOUT27 DOUT26 DOUT25 DOUT24 DOUT23 DOUT22 DOUT21 DOUT20... -
Page 20: Connector Assignments
Current rating: max 1.0 A per pin - ..pin is not connected on the PCB ┐ ┘ ..signals are connected on the PCB Page 20 of 22 Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0 VME-DIO32-L... -
Page 21: I/O-Connector P2
) for the digital I/O circuits to be fed externally. Each 4 channels are locally connected to the same power supply (y = 1, 2, ..., 4) I/Ox ... I/O channels of VME-DIO32-L (x = 1, 2, ..., 32) Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0... -
Page 22: Order Information
M.1607.27 Table 14: Available manuals Printed Manuals If you need a printout of the manual additionally, please contact our sales team (sales@esd.eu) for a quotation. Printed manuals may be ordered for a fee. Page 22 of 22 Hardware Manual Doc. Nr.: M.1607.27 / Rev. 1.0...
