ESD PMC-CAN/400-4 Hardware Manual

4x can with arinc protocol + irig-b
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PMC-CAN/400-4
4x CAN with ARINC Protocol + IRIG-B
Hardware Manual
to Products C.2047.01, C.2047.03
PMC-CAN/400-4
Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3
Page 1 of 29
esd electronic system design gmbh
Vahrenwalder Str. 207 • 30165 Hannover • Germany
http://www.esd.eu
Phone: +49 (0) 511 3 72 98-0 • Fax: +49 (0) 511 3 72 98-68

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMC-CAN/400-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ESD PMC-CAN/400-4

Summary of Contents for ESD PMC-CAN/400-4

  • Page 1 PMC-CAN/400-4 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 Page 1 of 29 esd electronic system design gmbh Vahrenwalder Str. 207 • 30165 Hannover • Germany http://www.esd.eu Phone: +49 (0) 511 3 72 98-0 • Fax: +49 (0) 511 3 72 98-68...
  • Page 2 The information in this document has been carefully checked and is believed to be entirely reliable. esd makes no warranty of any kind with regard to the material in this document, and assumes no responsibility for any errors that may appear in this document. In particular descriptions and technical data specified in this document may not be constituted to be guaranteed product features in any legal sense.
  • Page 3 Notes about IRIG-B and cables inserted 2014-06-25 6.2.3.1, Description of IRIG-B signals supplemented 6.2.3.2 Chapter about cable changed, description of cable PMC-CAN/400-4-1C4 added, note to FE (functional earth) added Declaration of Conformity updated Chapter 'Order Information' moved and updated 1.1, 1.2...
  • Page 4 This NOTICE statement contains the general mandatory sign and gives information that must be heeded and complied with for a safe use. INFORMATION INFORMATION Notes to point out something important or useful. Page 4 of 29 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 PMC-CAN/400-4...

  • Page 5: Safety Instructions

    ● The PMC-CAN/400-4 may become warm during normal use. Always allow adequate ventilation around the PMC-CAN/400-4 and use care when handling. ● Do not operate the PMC-CAN/400-4 adjacent to heat sources and do not expose it to unnecessary thermal radiation. Ensure an ambient temperature as specified in the technical data.
  • Page 6 Intended Use The intended use of the PMC-CAN/400-4 is the operation as PMC-CAN interface on a base board according to IEEE 1386.1-2001. The guarantee given by esd does not cover damages which result from improper use, usage not in accordance with regulations or disregard of safety instructions and warnings.

  • Page 7: Table Of Contents

    Safety Instructions........................... 5 1. Overview............................8 1.1 PMC-CAN/400-4........................8 Customized PMC-CAN/400-4 Version (Conduction Cooled)..........9 PCB-View with Connector Position.....................10 2.1 PMC-CAN/400-4........................10 Customized PMC-CAN/400-4 Version (Conduction Cooled) ..........10 3. LEDs............................11 Hardware Installation........................12 Technical Data........................... 14 General Technical Data.......................14 Bus..........................15 Interfaces........................

  • Page 8: Overview

    Overview 1. Overview The PMC-CAN/400-4 is a PMC-CAN interface board with up to 4x CAN and optional ARINC protocol and IRIG-B. 1.1 PMC-CAN/400-4 6 LEDs Connectors Pn1, Pn2 (Option) 4x CAN Interface Bus Master Electrical Isolation FPGA Capability Xilinx Spartan-3E...

  • Page 9: Customized Pmc-Can/400-4 Version (Conduction Cooled)

    Block Diagram of conduction cooled PMC-CAN/400-4 Version Fig. 2: Block circuit diagram of the conduction cooled PMC-CAN/400-4 version INFORMATION esd offers a VMEbus carrier board in conduction cooled design to carry up to two conduction cooled PMC-CAN/400-4 boards. PMC-CAN/400-4 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3...

  • Page 10: Pcb-View With Connector Position

    See also page 17 for signal assignment of the connectors. 2.2 Customized PMC-CAN/400-4 Version (Conduction Cooled) Fig. 4: Top view of the conduction cooled PMC-CAN/400-4 version facing the carrier board See also page 17 for signal assignment of the connectors.

  • Page 11: Leds

    LEDs 3. LEDs The PMC-CAN/400-4 is equipped with 6 green LEDs in the front panel. Fig. 5: Front panel view of PMC-CAN/400-4 Function Indication (LED on) Board (FPGA) booted IRIG-B IRIG-B Link CAN1 Traffic on CAN-Line 1 CAN2 Traffic on CAN-Line 2...

  • Page 12: Hardware Installation

    Pay attention that the PMC module is correctly installed on the carrier board. Fix the PMC-CAN/400-4 with the screws on the carrier board. Use the four M 2.5 x 6 mm screws which are contained in the product package of the module.
  • Page 13 Hardware Installation 12. End of hardware installation. 13. Set the interface properties in your operating system. Refer to the documentation of the operating system. PMC-CAN/400-4 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 Page 13 of 29...

  • Page 14: Technical Data

    (64-pin PMC connector) - IRIG-B (TTL level only) X400: (DSUB25) - CAN, IRIG-B (physical layers available) INFORMATION The IRIG-B option is not equipped on the PMC-CAN/400-4, order No.: C.2047.03. INFORMATION X400 is not equipped on the customized PMC-CAN/400-4 version with conduction cooling. The CAN signals are connected via connector P14.

  • Page 15: Pci Bus

    Memory Block RAM: 72 KB optional DRAM: 64 MB Interrupt interrupt signal INT A P11 (Pn1), P12 (Pn2), P14 (Pn4) Connectors according to IEEE Standard P1386.1-2001 PMC-CAN/400-4 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 Page 15 of 29...

  • Page 16: Can Interfaces

    Technical Data 5.3 CAN Interfaces Number 4x CAN High-Speed CAN core integrated in FPGA, CAN controller according to ISO11898-1 (CAN 2.0 A/B) customized PMC- Customized PMC-CAN/400-4 IrigB, CAN/400-4 version for PMC-CAN/400-4 Module type PMC-CAN/400-4 extended temperature version with range conduction cooling C.2047.01,...

  • Page 17: Irig-B Input

    Pn4 as well. Please take attention that the interface is connected alternatively to connector X400 OR Pn4, not simultaneously! INFORMATION The IRIG-B option is not equipped on the PMC-CAN/400-4, order No.: C.2047.03. 5.5 Software ® ®...

  • Page 18: Connector Assignment

    IRIG-B_A+, IRIG-B_A-, IRIG-B analog input. INFORMATION The IRIG-B option is not equipped on the PMC-CAN/400-4, order No.: C.2047.03. The IRIG-B signals do not apply for this version. The signal assignment of the CAN signals are kept as shown above. NOTICE To ensure the EC Conformity shielded cables have to be used.

  • Page 19: Pmc Connectors

    Connector Assignment 6.2 PMC Connectors The PMC-CAN/400-4 module uses the PMC connectors Pn1, Pn2 and Pn4. Pn1 and Pn2 provide the PCI interface and power supply connection. Pn4 has a complete module specific pin out. 6.2.1 PMC Connector Pn1 (P11)

  • Page 20: Pmc Connector Pn2 (P12)

    +3.3V n.c. (GNTB#) n.c. (reserved) n.c. (reserved) n.c. (EREADY) RESETOUT# n.c. (ACK64#) +3.3V MONARCH# For signal description please refer to the PCI Local Bus Specification 2.2. Page 20 of 29 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 PMC-CAN/400-4...

  • Page 21: Pmc Connector Pn4 (P14) Pin Assignment

    ( … ) supported at the moment. IRIG-B.POS, IRIG-B digital input. Physical layer RS-422 compatible. IRIG-B.NEG The IRIG-B signals are not available on the PMC-CAN/400-4 (order No.: C.2047.03). PMC-CAN/400-4 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 Page 21 of 29...

  • Page 22: Customized Pmc-Can/400-4 (Conduction Cooled)

    3.3 V signal levels only (not 5 V tolerant!) IRIG-B.POS, IRIG-B digital input. Physical layer RS-422 compatible. The IRIG-B signals are not IRIG-B.NEG available on the PMC-CAN/400-4 (order No.: C.2047.03). Page 22 of 29 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 PMC-CAN/400-4...

  • Page 23: Adapter Cables Dsub25 To Dsub9

    Connector Assignment 6.3 Adapter Cables DSUB25 to DSUB9 esd offers the following two adapter cables (see order information on page 28): - PMC-CAN/400-4-1C5 (order no. C.2047.18) - PMC-CAN/400-4-1C4 (order no. C.2047.19) PMC-CAN/400-4-1C5 (order no. C.2047.18) This adapter connects the four CAN interfaces and the IRIG-B input to the front panel connector X400.
  • Page 24 Housing female white CAN4_L DSUB9 brown CAN4_H CAN4 plug, green CAN4_GND male Housing shield Housing PMC-CAN/400-4-1C5 (order no. C.2047.18) only: white IRIG-B_Rx+ brown IRIG-B_Rx- DSUB9 green socket, IRIG-B_A+ IRIG-B female yellow IRIG-B_A- Housing shield Housing CANx-GND are isolated from each other. They are not tied together by the adapter cable.

  • Page 25: Can Interfaces At Dsub9 Male (4X)

    CANx_L, CANx_H, CANx_GND Physical layer according to ISO11898-2. Functional earth (FE) is connected to the housing of the DSUB9 connector and to the shield of the cable PMC-CAN/400-4 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 Page 25 of 29...

  • Page 26: Irig-B Analog And Rs-422 Compatible Input At Dsub9 Female

    Connector Assignment 6.3.2 IRIG-B Analog and RS-422 Compatible Input at DSUB9 Female PMC-CAN/400-4-1C5 The DSUB9 female socket for the IRIG-B interface is only equipped on the cable (order no. C.2047.18). Pin Position: Pin Assignment: Signal Signal IRIG-B_A+ IRIG-B_A- IRIG-B_RX- IRIG-B_RX+...

  • Page 27: Declaration Of Conformity

    Declaration of Conformity 7. Declaration of Conformity PMC-CAN/400-4 Hardware Manual • Doc. No.: C.2047.21 / Rev. 1.3 Page 27 of 29...

  • Page 28: Order Information

    Description Order No. Active PMC-CAN Interface Board for PMC up to 66 MHz, 3.3V (5V tolerant), - 4 CAN 2.0A/B interfaces via DSUB-25 connector on front PMC-CAN/400-4 panel, Physical Layer according to ISO 11898, electrically C.2047.01 4x CAN, 1xIrigB isolated...
  • Page 29 Order Information PDF Manuals Manuals are available in English and usually in German as well. For availability of English manuals see table below. Please download the manuals as PDF documents from our esd website www.esd.eu for free. Manuals Order No.

This manual is also suitable for:

C.2047.01C.2047.03
