To avoid any damage to these items during transportation, the slide runners and slide tracks have been pre-assembled together in pairs. Each pair includes a slide runner and slide track. Before assembling your new Shangri-La unit, please separate the slide runners from the slide tracks according to the below instructions. - Page 4 Step 1: Extend the slide runners apart from the slide track: Step 2: Gently press the plastic release lever on the slide runner while pulling the slide runner and slide track apart from each other: Step 3: The slide runner and slide track should now be separated.
- Page 5 COMPONENTS...
- Page 6 Parts list Dimensions (mm) Dimensions (mm) 348 x 767 x 28 80 x 300 x 12 348 x 767 x 28 80 x 300 x 12 350 x 1000 x 28 78 x 896 x 12 290 x 340 x 15 294 x 905 x 2.5 80 x 340 x 15 50 x 285 x 12...
- Page 7 ASSEMBLY Step 1: B L=35mm (x6)
- Page 8 Step 2: F 12" (x2) G Φ3.5x12 (x4) DRAWER SLIDE (E X 1) DRAWER SLIDE (E X 1)
- Page 9 Step 3: Use D screws to secure parts as shown. Use a Phillips head screwdriver to secure A to B for part 6. A Φ15x9.6 (x2) D Φ4x32 (x2) Arrow to point in the direction of end hole...
- Page 10 Step 4: A Φ15x9.6 (x4) Arrow to point in the direction of end hole...
- Page 11 Step 5: E 12" (x2) G Φ3.5x12 (x4) DRAWER SLIDE (D X 2)
- Page 12 Step 6: K L=38mm (x8)
- Page 13 Step 7: K L=38mm (x6)
- Page 14 Step 8: J Φ15x11.5 (x8) Arrow to point in the direction of end hole...
- Page 15 Step 9: J Φ15x11.5 (x6) Arrow to point in the direction of end hole...
- Page 16 Step 10:...
- Page 17 Step 11: G Φ6x13x1 (x1) H (x1) I Φ4x16 (x1) TOPPLING FURNITURE WARNING: • It is strongly recommended that this product is permanently fixed to the wall. • Please seek professional advice if you are in doubt of what fixing device to use. •...
- Page 18 Step 12: Move the drawer chest to the final position. Attach the safety strap to the wall. Make sure it is firmly attached and make sure it is snugly fit.
- Page 19 Assembly complete.
