- Page 1 4G/LTE Wireless PTZ Camera Builtin 4G Wifi Router Dual LAN port 2022/03 User Manual V3.0 Visit http://4g.sunba.net to access the step by step YouTube video tutorials for setting up Sunba IP PTZ camera.
-
Page 2: Product Overview
Product Overview Model 603-D25X 4G Image Sensor 1/2.8” Progressive Scan CMOS Resolution Memory Card Slot Focal Length Viewing Angle 59.5°-2.6° Aperture Range F1.5-F3.8 Min. Illumination Color: 0.05Lux @ (F1.6 AGC ON) B/W: 0.01Lux @ (F1.6 AGC ON) Focus Pan & Tilt Pan: 0-360°Tilt: -10-90°... -
Page 3: Tf Card Installation
It is important to examine the male/female end between the antenna and the receptive port on the camera before installation. If your antenna is damaged out of box, please contact support@sunba.net for replacement. female NOTE:Be careful with the female and male ends of the port and male the antennas. - Page 4 Warning: The load end for MANY battery charge controllers doesn't regulate voltages and is for wide voltage equipments. Sunba cameras require, however, fixed voltage. In this case, you need to get a voltage regulator for the load end if the battery doesn’t have built-in regulators.
- Page 5 U-Bolt x 4 (2 for solar panel; 2 for camera); Pole Mount x 6 (4 for solar panel; 2 for camera); SUNBA currently provides solar lithium battery kit PTZ Mount Adapter x 1; system, It is recommended to be used as a set with a 4G KC80 Waterseal Rubber Mastic Tape x 1;...
-
Page 6: Smartphone Control
6.Smartphone Control Method A: Scan the barcode to add the camera (4G Application) Download Guard Viewer App Sign up a cloud account. Select “international” service zone if asked. Download on D ow nl oad o n the App Store t he Google Play to show the sidebar, and go to the Devices option to add... - Page 7 The live view page will load as follows. Quality = Switch the live view quality. It’s recommended to set low in sites with limited cellular coverage. Snapshot = Take snapshots. Record = Record to smartphone. Image = Set live view windows such as 4/9/16.
-
Page 8: Desktop Setup
7.Desktop Setup Download the Guard Station Tool from https://sunbatech.com/download/ The default username and password is admin/123456. Go to Device Management – Cloud Device. Register the account if you haven’t or simply login if you’ve completed registration from other devices or through Guard Viewer. Click “Device Details”... - Page 9 8. 4G/LTE Router Panel Management Please search for the available wifi hotspot in your network and find the one starting with IM-LINK. And then connect to it with password 1234567890 Once connected, please login to the 4G/LTE management panel via its IP address. The default IP of the 4G module is http://192.168.8.1 but it is always recommended to check via Network and Sharing Center->Change Adapter Setting for verification.
-
Page 10: Frequent Asked Questions
9.Frequent Asked Questions Frequently Asked Questions (read me before placing an order) How can I power my Sunba 4G PTZ? The camera has only a DC12V port and accepts any input power of DC12V 4A. You can use regulated battery with solar panel or with DC12V cable running and plugged to AC outlet. - Page 11 10. ISP Frequency Band Comparison Table American version: LTE-FDD: B2/B4/B5/B12/B13/B14/B66/B71; WCDMA: B2/B4/B5 Japanese version: LTE-FDD: B1/B3/B8/B18/B19/B26; LTE-TDD: B41; WCDMA: B1/B6/B8/B19 European version: LTE-FDD: B1/B3/B7/B8/B20/B28; LTE-TDD: B38/B40/B41; WCDMA: B1/B8; GSM: B3/B8 Area Country Carrier(ISP ) LTE- FDD Compatible version Verizon T- Mobile B2/B4 AT&...
- Page 12 2) it must accept any interference it receives. WARNING: Please test the camera indoor before mounting it outside. Stay at least 24 hours to test both daytime and night vision IR LED. For any questions, don't hesitate to reach support@sunba.net SUNBA Technology ®...
