DW VMAX ip PLUS -VP9P User Manual page 87

87
Health check
System operation
Power requirements
Power consumption
Total PoE power budget
Maximum power per port
Operating temperature and
humidity
Dimension (W x D x H)
Certification
Warranty
* Specifications are subject to change without notice.
Real-time system, network and PoE status monitoring
IR remote controller (optional), USB mouse, PTZ control by
48V DC
90W total power
budget, 1.875A
19W per PoE
channel
(simultaneous)
76W
30W
41~104 °F (5~40 °C) / 20~90% RH
14.96" x 12.4" x
2.02" (380 × 315 ×
51.5 mm), 1U
CE, FCC, KCC, WEEE, RoHS
keyboard (optional)
110~240V A/C
360 W total power
budget, 5.5A,
18.75W per PoE
channel
(simultaneous)
150W
30W
17.32" x 15.66" x
2.79" (440 × 397.8
×70 mm), 1.5U
5 year limited
110~240V A/C
300 W total power
budget, 5.5A,
9.37W per PoE
channel
(simultaneous)
150W
30W
17.32" x 15.66" x
2.79" (440 × 397.8
×70 mm), 1.5U
