when a sensor is triggered, and motion is detected but neither sensor nor motion detection alarms
will be activated
Note
In case the recording schedule is set by "CONT + MOT" or "MOT + SENS", the system
records by continuous or motion detection mode in normal operation. However, when
motion occurs in the motion area or an alarm is activated, then the recording mode will
switch to recording as set by "MOTION ALARM" or "SENSOR" of the "EVENT" menu.
Note
Dark Blue Color
The data recorded during DST (Daylight Saving Time) will be indicated in Dark Blue color
in Intelli-Search Bar on playback mode.
HOLIDAY SETUP
Setup specific days as "holidays" in HOLIDAY SETUP to assign a
special recording schedule for those days. The system supports up to
32 holidays.
Press the [DATE] button (
save the data as a holiday.
Note
Instant Recording (Emergency Recording)
In the case of an emergency, the user enables Instant Record by pressing the panic
recording button in the menu bar. The system will instantly start recording all the channels
with the full-frame rate at the maximum resolution regardless of the recording mode setting.
will appear in live mode and a red-colored bar is shown in the time search bar for
video recorded by instant recording.
RECORD 1FPS CONTINUOUS WITH 'CONT+' MODE.
Check the box to set continuous recording to 1FPS when selecting "continuous + xx" modes.
LIMIT EMERGENCY RECORDING TIME
Set a limit to how long the system will record in emergency recording mode. Select from
30sec/60sec/90sec/2min/5min/10min.
) write a description, and press [ADD] to
