GASTRON GIR3000 Instruction Manual page 23

LEVEL1
ALARM PROGRAM
MODE
TEST MODE
IR SENSOR DATA
MODE
VERSION
MODE
MAINTENANCE
MODE
NAME
ALARM1 RELAY CTL
(ALARM RELAY CONTROL)
ALARM1 TIME SET
ALARM2 TYPE SEL.
(ALARM2 TYPE SELECT)
ALARM2 LEVEL ADJ
(ALARM2 LEVEL ADJUST)
ALARM2 DEAD BAND
ALARM2 RELAY CTL
(ALARM RELAY CONTROL)
ALARM2 TIME SET
TROUBLE RELAY
ALARM RELAY
OUTPUT SIGNAL
[ TEST ]
M(MANUAL)
Z(ZERO)
S(SPAN)
Z / S
ZS RAT(RATE)
A(AUTO)
VIN
MIN / MAX
GIR3000A
GSA920A
H/W VERSION
HART DEVICE
HART REV
CROSS SENS. TYPE
(CROSS SENSITIVITY TYPE)
CROSS SENS. ADJ.
(CROSS SENSITIVITY ADJUST)
SET – UP MODE
ZERO SKIP BAND
PAGE 23 of 44
GIR-3000 Instruction Manual
LEVEL2
PARAMETER
[ON / OFF]
[01]SEC , 0~60 ADJ
INCREASE/ DECREASE
1~Full Scale ADJ
0.0~ Adj within 10%
of Full Scale
[ON / OFF]
[01]SEC , 0~60 ADJ
[ON / OFF]
[ON / OFF]
[4mA / 20mA]
[ 0 ] 0~Full Scale ADJ
0.XXXX / 0.XXXX
X.XXX% + XX.XX%+XX
0.XXXX / 0.XXXX
0.XXXX / 0.XXXX
XX.X / XX.X
XX.X %
0.XXXX / 0.XXXX
[X]X.XXX% , XX.X
XX.X V
XX V / XX V
V XXX
V X.XX
[REV 2]
[REV 1]
[REV 7]
X.X / X.XX
[1.0] X GAS , 0.1~5.0 ADJ
[ON / OFF]
[ON / OFF]
DEFAULT
ON
01
INCREASE
40
1.0
ON
01
OFF
OFF
4mA
0
-
-
-
-
-
-
-
-
-
X.X
1.0
OFF
ON
Rev 2.0, 2012.8.21
