- Page 4 Main Frame Parts TH122-1 (1 item) TH122-2 Side Panel (2 item) TH122-3 Front Panel (1 item) TH122-4 Back Panel (1 item) TH122-5 13 500-6 Wheels (4 item) Rear Support Assembly TH122-6 Rear Axle Support (1 item) TH122-7 Left Rear Axle Brace (1 item) TH122-8 Hardware...
- Page 6 ASSEMBLY INSTRUCTIONS Step 1 Turn the trolley bed upside down so that the underside is facing upwards. Step 2 Attach the Rear Axle Support (6) assembly to the bed by firstly attaching the Right and Left Rear Axle Braces (7 and 8) onto the threaded bar with the two bolt hole section facing inwards. Insert six Carriage Support Bolts (25) through the bed and secure with six Washers (19) and Nuts (20).
