INSTRUCTION MANUAL
1300W
2in1 ELECTRIC
SCARIFIER & RAKE
Model No: THSR -- Product No: 1938140001
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
Please read & understand this manual, paying particular attention to the safety instructions,
before use.
The manufacturer reserves the right to change the product specification and livery according to
continued product improvements.
18-11-2016
Advertisement
Table of Contents
Related Manuals for The Handy THSR
Summary of Contents for The Handy THSR
- Page 1 INSTRUCTION MANUAL 1300W 2in1 ELECTRIC SCARIFIER & RAKE Model No: THSR -- Product No: 1938140001 ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 Please read & understand this manual, paying particular attention to the safety instructions, before use.
-
Page 3: Table Of Contents
CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS INTENDED USE KNOW YOUR MACHINE SET UP & PREPARATION FOR OPERATION GENERAL OPERATION MAINTENANCE & STORAGE TROUBLE SHOOTING PARTS LISTS & DIAGRAM EC DECLARATION OF CONFORMITY WARRANTY If you require any assistance with regards to the contents or operation of your machine, please contact us: Tel: 01793 333212 - Mon to Friday 8.00am to 5.30pm (excl. -
Page 4: Specification
SPECIFICATION The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model THSR Product No. 1938140001 Motor Rated Power 230-240V~50Hz Protection IPX4 No-load Speed 2990/min Max. Working Width 320mm Height Range 5 adjustments (-10/-5/0/5/10mm) -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 6 STAY ALERT Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand. Be aware of what you are doing at all times. Use common sense. AVOID DANGEROUS CONDITIONS Make sure there is adequate surrounding workspace.
- Page 7 PROTECT THE ENVIRONMENT Take left over materials to an authorised collection point or follow the stipulations in the country where the machine is used. Do not discharge into drains, soil or water. STORE IDLE EQUIPMENT When not in use, the machine should be stored in a dry location. Keep the machine away from children and others not qualified to use it.
- Page 8 Electrical power should be supplied via a residual current device (RCD) with a tripping current of not more than 30 mA. Before use, check the supply and extension cord for signs of damage or aging. If the cord becomes damaged during use, disconnect the cord from the supply immediately.
-
Page 9: Intended Use
GENERAL MOWING TIPS When cutting long grass, reduce walking speed to allow for more effective cutting and a proper discharge of the clippings. It is recommended that you cut longer grass in stages. Start at a higher cutting height and go over the same area a second time with a lower cutting height. ... -
Page 10: Know Your Machine
KNOW YOUR MACHINE Top Handle Electric Cold Restraint Handle Knob Set (x4) Middle Handle Bottom Handle Handle Fixing Screw Support Air Vents Depth/Height Adjuster Wheel Rear Castor Discharge Opening Collector Flap Grass Collector Cable Clip (x2) Switch Box Safety Lock Button Trigger Lever Electric Power Cable &... -
Page 11: Set Up & Preparation For Operation
Slide the cord strain relief (2) onto the upper SET UP & PREPARATION handle bar (3). FOR OPERATION Align the upper handle bar (3) with the middle Follow the operating instructions step-by- handle bar (5) and secure them with one step and use the pictures provided as a visual mounting set (4) on each side. - Page 12 For cord strain relief of the cable, form a loop GRASS COLLECTOR ASSEMBLY at the end of the main cable and bring this through the opening in the handle and insert WARNING! it into the cord strain relief. Do not attempt to use the product without the grass catcher attached as objects may be thrown.
-
Page 13: Power Connection
Cracks caused by ageing of the insulation SCARIFYING Scale Setting Depth Description sheath. for transportation Kinks caused by incorrect fastening of the Transport +10mm and storage mains lead. scarifying a young 2. Such damaged mains lead should not be or sensitive lawn, used under any circumstances as they removing thin... -
Page 14: General Operation
Select the suitable working depth for the GENERAL OPERATION actual grass height. Do not work with this product on a wet lawn because the grass may stick to the WARNING! underside of the product, preventing the In some countries regulations define at what proper discharge of collected material, time of the day and on what day’s machines and could also cause you to slip and fall. - Page 15 Check that covers and guards are undamaged and correctly fitted. Carry out necessary maintenance or repairs before Cutting devices are very sharp and become using the product. hot during use! Handle them carefully! If the cutting device should happen to fail Wear safety gloves when handling cutting despite the care taken in manufacturing devices to avoid injuries like burns and cuts!
- Page 16 3. Loosen the two bolts (22a) with a suitable UK PLUG REPLACEMENT wrench, remove them together with the The fuse in the main plug of your garden spring washers (22b) and the attached power tool should always be replaced with cutting device (21 or 23).
-
Page 17: Troubleshooting
TROUBLESHOOTING WARNING! Only perform the steps described in these instructions! All further inspection, maintenance and repair work must be performed by an authorised service specialist! Contact your local authorised service dealer if the problem cannot be solved by yourself! WARNING! If the product does not perform properly, makes unusual sounds, the motor does not start or stop as described, the cutting device does not work properly, or any other irregularity or malfunction occurs, do not attempt to repair the product by yourself. -
Page 18: Parts Lists & Diagram
PARTS DIAGRAM... - Page 19 PARTS LIST...
-
Page 20: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: 1300 Watt 2-in1 Scarifier/Rake Model(s): THSR Product Number: 1938140001 Type/Serial No: As per rating label on machine Complies with the following directives: 2006/42/EC – Machinery Directive 2014/30/EU –... - Page 21 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
- Page 22 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
-
Page 24: Email: Customerservice@Handydistribution.co.uk
For spares or support of your Handy product, please contact us: Tel: 01793 333212 (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) Email: customerservice@handydistribution.co.uk To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
