INSTRUCTION MANUAL
GARDEN TROLLEY
MODEL NO: THGT -- PRODUCT NO: 193854004
EN - ORIGINAL INSTRUCTIONS
ASSEMBLY REQUIRED - MINIMUM TWO PERSONS
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
IMPORTANT INFORMATION
The Garden Trolley is designed for use in private gardens and primarily used around GRASS OR LAWN AREAS,
but not in public facilities, parks or sports grounds and not for agricultural or forestry use.
Never exceed the rated load capacity of 200kg (440lb).
This is a garden trolley, therefore extended use over abrasive surfaces (e.g., concrete, tarmac etc.) could cause
premature wear on the trolley tyres. Commercial or industrial environments are not recommended.
Not to be used on public highways or roads. When operating with a tractor, do not exceed 10mph.
FOR YOUR SAFETY
WARNING: PERSONS SHOULD NEVER RIDE IN THE GARDEN TROLLEY.
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our policy
of continuous improvement determines the right to make modifications without prior warning.
Images used are for illustration purposes only.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for The Handy THGT
Summary of Contents for The Handy THGT
- Page 1 INSTRUCTION MANUAL GARDEN TROLLEY MODEL NO: THGT -- PRODUCT NO: 193854004 EN - ORIGINAL INSTRUCTIONS ASSEMBLY REQUIRED - MINIMUM TWO PERSONS SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 IMPORTANT INFORMATION The Garden Trolley is designed for use in private gardens and primarily used around GRASS OR LAWN AREAS, but not in public facilities, parks or sports grounds and not for agricultural or forestry use.
- Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
-
Page 3: Table Of Contents
CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS SET UP & PREPARATION FOR OPERATION ASSEMBLY OPERATION MAINTENANCE & STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST WARRANTY ASSEMBLY IS REQUIRED - MINIMUM TWO PERSONS • This product requires assembly before use. • See “Assembly”... -
Page 4: Specification
Tyre Puncture-less Consistent with our policy of continuous improvement, The Handy reserves the right to change the design and configuration of any of its products without notice or obligation. Therefore, please treat the text and images in this manual for illustrative purposes only. They may in no case serve as a basis for any legal claim. -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 6 USERS, BYSTANDERS AND CHILDREN Do not at any time carry passengers in or on the trolley, stationary or whilst moving. Do not allow any person, child or pet to play on, stand, sit, lay or climb in or on the trolley. Never allow children or people unfamiliar with these instructions to use the trolley.
-
Page 7: Set Up & Preparation For Operation
SET UP & PREPARATION FOR OPERATION This product must be assembled correctly before use. Carefully remove the product and any accessories from the carton. Inspect the product carefully to make sure there are no breakages or missing items during shipping. Do not discard the packing material and carton until you have carefully inspected and satisfactorily operated the product. - Page 8 STEP 2 Attach the Rear Axle Support (6) to the Bed (1) using two Carriage Support Bolts, Washers & Nuts (18). Place the Right (7) and Left (8) Rear Axle Braces onto the Rear Axle Support (6).
- Page 9 Attach the Rear Axle Braces (7 & 8) to the Bed (1) using four Carriage Support Bolts, Washers & Nuts (18). STEP 3 Attach the Front Axle Support (9) to the Bed (1) using two Carriage Support Bolts, Washers & Nuts (18).
- Page 10 STEP 4 Attach the Steering Link Connector (12) to the Front Axle Support (9), using Bolts, Washers and Nuts (19). The connector should sit over the axle as pictured. STEP 5 Position the Central Front Axle Brace (10) up to the Front Axle Support (9). Fix the Central Front Axle Brace (10) to the Bed (1) using Carriage Bolt, Washer &...
- Page 11 STEP 6 Slot the stepped arm of the Yoke (11) onto the protruding leg of the Front Axle Support (9) (this leg is stepped, so the Yoke (11) will not go all the way over the leg). Position the straight arm of the Yoke (11) between the Centre Front Axle Brace (10) & Front Axle Support (9). STEP 7 Fix the Yoke (11) &...
- Page 12 Attach the Steering Link Connector (12) to the Yoke (11) using Carriage Bolt, Washer & Nut (18). Slide the Large Washer (23) over the Front Axle Support (9) protruding leg (this is stepped) and slide the Split Pin (16) through the hole. Split open the Pin legs to secure. STEP 8 Attach the Pull Adapter (13) to the Yoke (11) by aligning the holes in the Lower Handle, Handle Coupling and the Yoke (11).
- Page 13 STEP 9 Slide the Wheel Assembly (5) onto the axle. Secure using a Wheel Washer (17) and a Wheel Nut (24) on to the axle. The nuts are supplied with nylon lock, which may prove difficult to tighten the nut initially. Do not over tighten;...
-
Page 14: Operation
STEP 12 Position the Side Lock Handles (22) through the tabs on the top right and left of the Side (2), Front (3) & Rear (4) Panels and secure using the nut provided (do not overtighten). Ensure the threaded end faces inwards towards each other. -
Page 15: Maintenance & Storage
MAINTENANCE & STORAGE WARNING Repairs and maintenance work other than those described within this instruction manual may be performed only by an authorised service agent. MAINTENANCE Users of this product should only undertake actions described in this manual, unless otherwise instructed by the manufacturer. - Page 16 PARTS DIAGRAM NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice. PARTS LIST - Part 1 ITEM NO PART NO. DESCRIPTION TH220-1-1 TH220-2-2...
- Page 17 PARTS LIST - Part 2 ITEM NO PART NO DESCRIPTION TH215-A1-16 Split Pin – 2.5x45 TH219-2 Wheel Washer 16mm TH215-C-18 Carriage Support Bolt, Washer & Nut - M8x15mm TH215-A4-19 Bolt, Washer & Nut - M6x16mm TH215-D-20 R-Clip - 40x105 TH215-E1-21 Bolt, Washer &...
- Page 18 Period of Warranty The Handy (Petrol & Electric only), Webb (excludes Dynamic, Heritage, Legacy), Sanli Engine 2 years from the original date of sale to the first domestic user. b) 90 days from the original date of sale to the professional/commercial user.
- Page 19 Disclaimer This warranty is only a remedy for defect of products. GJ Handy & Co Ltd will never warranty in terms of the merchantability or the fitness for a particular purpose. b) No person is authorised to make any warranties, representations or promises, expressed or implied, on behalf of GJ Handy &...
- Page 20 For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: customerservice@handydistribution.co.uk Opening Hours Weekdays: February to October 8:30am - 5:30pm November to January 8:30am - 5:00pm (CLOSED WEEKENDS & BANK HOLIDAYS) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier &...
