Summary of Contents for Prominence Home Hero 51655
-
Page 2: Package Contents
PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: PACKAGE CONTENTS 1. Upper Mounting Bracket 9. Blade (x5) 2. Motor Housing 10. Blade Arm (x5) 3. Lower Mounting Bracket 11. Hardware Kit 4. Motor 12. - Page 3 EXPLODED VIEW DETAIL Upper Mounting Bracket Motor Housing Blade Lower Mounting Bracket Motor Blade Arm Switch Housing Light Kit Bulb Glass Globe DIMENSION REFERENCE A. 13.22 in. B. 5.88 in. C. 7.01 in. D. 9.39 in.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS READ ALL SAFETY INFORMATION AND INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN INSTALLING THE FAN AND SAVE INSTRUCTIONS. CAUTION: All set screws of the fan must be checked and retightened where necessary before installation. To reduce the risk of personal injury, do not bend the blade brackets when installing the brackets, balancing the blades or cleaning fan. - Page 5 SAFETY INSTRUCTIONS WARNING: To avoid risk of electric shock, be sure to shut off power at the main fuse or circuit breaker box before installing or servicing this fixture. Turning off the electrical power by using the light switch is not sufficient to prevent electrical shock.
- Page 6 ASSEMBLY INSTRUCTIONS 1. Turn OFF the electrical power at the main fuse or circuit breaker. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. 2. Secure the upper mounting bracket to the outlet box (not included) using the two mounting screws and Upper Mounting...
- Page 7 ASSEMBLY INSTRUCTIONS 5. Reinstall the previously removed lower bracket screw and upper mounting screws to secure the lower mounting bracket to the upper mounting bracket. Lower Upper Bracket Bracket Screw Screw SECONDARY HANGING SYSTEM Braided Cable For installation in the United States: Building codes Brace in the U.S.A.
- Page 8 ASSEMBLY INSTRUCTIONS 9. Use wire connectors to connect the fan wires to the power supply wires according to the wiring diagram Black (live) and the following instructions: • Connect the green wire from the lower mounting White (neutral) bracket to the bare/green (ground) supply wire. Bare/Green (ground) •...
- Page 9 ASSEMBLY INSTRUCTIONS 13. Install the E26-base LED bulb into the socket of the light kit. Then, loosen the three thumbscrews near the bottom of the light kit. Lift the glass bowl into the light Bulb kit and retighten the previously loosened thumbscrews Thumbscrew to secure.
- Page 10 OPERATING INSTRUCTIONS 1. Using a ceiling fan will allow you to raise your thermostat setting in summer and lower your thermostat setting in winter without feeling a difference in your comfort. In warmer weather, push the reverse switch down which Reverse Switch will result in downward airflow creating a wind chill effect.
-
Page 11: Troubleshooting
TROUBLESHOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check the Troubleshooting section below. If a problem cannot be remedied or you are experiencing difficulty in installation, please contact the Service Department: 1-877-706-3267, 8 a.m. -
Page 12: Limited Lifetime Warranty
LIMITED LIFETIME WARRANTY To obtain Service, please contact Customer Service: 1-877-706-3267, 8 a.m. - 5 p.m. Central Time, Monday - Friday. Model Name: 28” Ceiling Fan Model No: 51655 - Bronze 51656 - Brushed Nickel Set forth below, the manufacturer, Hong Kong China Electric appliance Company (HKC) warrants the fan motor for this ceiling fan to be free from defects in workmanship and material for the life of the product.
