To our customers,
Old Company Name in Catalogs and Other Documents
st
On April 1
, 2010, NEC Electronics Corporation merged with Renesas Technology
Corporation, and Renesas Electronics Corporation took over all the business of both
companies. Therefore, although the old company name remains in this document, it is a valid
Renesas Electronics document. We appreciate your understanding.
Renesas Electronics website:
Issued by: Renesas Electronics Corporation (http://www.renesas.com)
Send any inquiries to http://www.renesas.com/inquiry.
http://www.renesas.com
st
April 1
, 2010
Renesas Electronics Corporation
Advertisement
Table of Contents
Related Manuals for Renesas H8/3694
Summary of Contents for Renesas H8/3694
- Page 1 On April 1 , 2010, NEC Electronics Corporation merged with Renesas Technology Corporation, and Renesas Electronics Corporation took over all the business of both companies. Therefore, although the old company name remains in this document, it is a valid Renesas Electronics document. We appreciate your understanding.
- Page 2 Renesas Electronics. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an application categorized as “Specific”...
- Page 3 H8/3694, H8/36014 Group TNP-48 User System Interface Cable for E6000 Emulator User’s Manual HS36014ECN61H Renesas Microcomputer Development Environment System H8 Family / H8/300H Tiny Series Rev.1.0 2003.12...
- Page 4 6. The prior written approval of Renesas Technology Corp. is necessary to reprint or reproduce in whole or in part these materials. 7. If these products or technologies are subject to the Japanese export control restrictions, they must be exported under a license from the Japanese government and cannot be imported into a country other than the approved destination.
-
Page 5: Important Information
Renesas) pursues a policy of continuing improvement in design, performance, functions, and safety of the user system interface cable. Renesas reserves the right to change, wholly or partially, the specifications, design, user's manual, and other documentation at any time without notice. -
Page 6: Limited Warranty
User system interface cables are wearing parts which Renesas will not repair or replace if damaged and/or worn through use. The foregoing shall constitute the sole remedy for any breach of Renesas' warranty. - Page 7 This user's manual and user system interface cable are copyrighted and all rights are reserved by Renesas. No part of this user's manual, all or part, may be reproduced or duplicated in any form, in hard-copy or machine-readable form, by any means available without Renesas' prior written consent.
- Page 8 • READ this user's manual before using this user system interface cable. • KEEP the user's manual handy for future reference. Do not attempt to use the user system interface cable until you fully understand its mechanism. DEFINITION OF SIGNAL WORDS This is the safety alert symbol.
- Page 9 Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. The USER PROGRAM will be LOST. 1. Do not repair or remodel the emulator product by yourself for electric shock prevention and quality assurance.
- Page 10 The HS36014ECN61H is a user system interface cable that connects an H8/3694 group, H8/36014 group E6000 emulator (HS3664EPI61H; hereinafter referred to as the emulator) to the IC socket for a TNP-48 package for the H8/3694 group or H8/36014 group MCU on the user system.
-
Page 11: Table Of Contents
Section 1 Configuration...1 Section 2 Connection Procedures ...3 Connecting User System Interface Cable to Emulator Station ... 3 Connecting User System Interface Cable to User System... 5 2.2.1 Installing IC Socket... 6 2.2.2 Soldering IC Socket ... 7 Inserting Cable Head... 7 2.2.3 2.2.4 Fastening Cable Head ... -
Page 12: Section 1 Configuration
Section 1 Configuration Use an NLPACK048SD socket (manufactured by Tokyo Eletech Corporation) for the TNP-48 package IC socket on the user system. Figure 1 shows the configuration of the HS36014ECN61H user system interface cable for the TNP-48 package. Figure 1 HS36014ECN61H User System Interface Cable CAUTION... - Page 13 Table 1 lists the HS36014ECN61H components. Please make sure you have all of these components when unpacking. Table 1 HS36014ECH64H Components No. Component Cable body Cable head IC socket Socket cover Screws (M2 x 10 mm) Screws (M2 x 6 mm) CTS screws (M3 x 6 mm) Guide pins ( 0.8 mm) Screwdriver...
-
Page 14: Section 2 Connection Procedures
Section 2 Connection Procedures Connecting User System Interface Cable to Emulator Station Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. - Page 15 Figure 2 Connecting User System Interface Cable to Emulator Station...
-
Page 16: Connecting User System Interface Cable To User System
Connecting User System Interface Cable to User System Always switch OFF the user system and the emulator product before the USER SYSTEM INTERFACE CABLE is connected to or removed from any part. Before connecting, make sure that pin 1 on both sides are correctly aligned. -
Page 17: Installing Ic Socket
2.2.1 Installing IC Socket After checking the location of pin 1 on the IC socket fasten it to the user system before soldering. After confirming the location of pin 1 on the IC socket, apply epoxy resin adhesive to the end of the four projections at the bottom of the IC socket, and fasten it to the user system. -
Page 18: Soldering Ic Socket
2.2.2 Soldering IC Socket After fastening, solder the IC socket for a TNP-48 package to the user system. Be sure to completely solder the leads so that the solder slops gently over the leads and forms solder fillets. (Use slightly more solder than the MCU.) 2.2.3 Inserting Cable Head Check the location of pin 1 before inserting. -
Page 19: Fastening Cable Head
2.2.4 Fastening Cable Head 1. Use the screwdriver provided for tightening screws. 2. The tightening torque must be 0.098 N•m or less. If the applied torque cannot be accurately measured, stop tightening when the force required to turn the screw becomes significantly greater than that needed when first tightening. - Page 20 Fasten the user system interface cable head to the IC socket for a TNP-48 package on the user system with the four screws (M2 10 mm) provided. Each screw should be tightened a little at a time, alternating between screws on opposing corners. Take special care, such as manually securing the IC socket soldered area, to prevent the soldered IC socket from being damaged by overtightening the screws or twisting the components.s Figure 4 Connecting User System Interface Cable to User System...
-
Page 21: Fastening Cable Body
2.2.5 Fastening Cable Body Connect the cable body to the cable head. Figure 5 Fastening Cable Body... -
Page 22: Recommended Dimensions For User System Mount Pad
Recommended Dimensions for User System Mount Pad Figure 6 shows the recommended dimensions for the mount pad (footprint) for the user system with an IC socket for a TNP-48 package (NLPACK048SD: manufactured by Tokyo Eletech Corporation). Note that the dimensions in figure 6 are somewhat different from those of the actual chip's mount pad. -
Page 23: Dimensions For User System Interface Cable Head
Dimensions for User System Interface Cable Head The dimensions for the user system interface cable head are shown in figure 7. ± Figure 7 Dimensions for User System Interface Cable Head... -
Page 24: Resulting Dimensions After Connecting User System Interface Cable
Resulting Dimensions after Connecting User System Interface Cable The resulting dimensions, after connecting the user system interface cable head to the user system, are shown in figure 8. ± Figure 8 Resulting Dimensions after Connecting User System Interface Cable... -
Page 25: Section 3 Installing The Mcu To The User System
Section 3 Installing the MCU to the User System 1. Check the location of pin 1 before inserting. 2. Use the screwdriver provided for tightening screws. 3. The tightening torque must be 0.098 N•m or less. If the applied torque cannot be accurately measured, stop tightening when the force required to turn the screw becomes significantly greater than that needed when first tightening. - Page 26 Figure 9 Installing MCU to User System...
-
Page 27: Section 4 Verifying Operation
Section 4 Verifying Operation 1. When using the H8/3694 group and H8/36014 group E6000 emulator (HS3664EPI61H), turn on the emulator according to the procedures described in the H8/3664 Series E6000 Emulator User's Manual (HS3664EPI61HE-U2). 2. Verify the user system interface cable connections by accessing ports and checking the bus states of the pins. - Page 28 Figure 10 shows the system clock oscillator on the user system interface cable and the subclock input specifications. Figure 10 System Clock Oscillator...
-
Page 29: Section 5 Notice
1. Make sure that pin 1 on the user system IC socket is correctly aligned with pin 1 on the cable head before inserting the cable head into the user system IC socket. 2. The dimensions of the recommended mount pad for the user system IC socket are different from those of the MCU. - Page 30 6. The P1 short connector is used for testing. Do not remove the inserted jumper pin. SW1 is a switch provided for selection of the H8/3694 group or the H8/36014 group. Shift the switch to 3694 or 36014 when the H8/3694 group or the H8/36014 group is in use, respectively. At default, the switch is shifted to 36014.
- Page 31 E6000 Emulator User's Manual Publication Date: Rev.1.00, December 19, 2003 Published by: Sales Strategic Planning Div. Renesas Technology Corp. Edited by: Technical Documentation & Information Department Renesas Kodaira Semiconductor Co., Ltd. 2003 Renesas Technology Corp. All rights reserved. Printed in Japan.
- Page 32 H8/3694, H8/36014 Group TNP-48 User System Interface Cable for E6000 Emulator User’s Manual 1753, Shimonumabe, Nakahara-ku, Kawasaki-shi, Kanagawa 211-8668 Japan REJ10B0094-0100H...
