Section 5: Software

Calibration Variables (LIST C)

The calibration settings control the calibration and validation of the MPS4200. See Section 6: Calibration and Validation Over-
view for more information on performing calibrations or validations.

List Calibration Settings (LIST C)

DESCRIPTION
SYNTAX
RETURNS
EXAMPLE

Set Number of Points in Conversion Table (NUMPTS)

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
EXAMPLE
DEFAULT
RANGE
Returns all of the calibration settings
LIST C
All of the calibration settings followed by the prompt.
LIST C
SET NUMPTS 0 9 0 9
SET MIN 40.000000 -5.500000 5.000000 -5.000000
SET MAX 60.000000 5.500000 55.000000 5.000000
SET DELAY 5 5
SET IPOVEN 0.0.0.0 0
SET IPCAL 0.0.0.0 0 1
SET CALAVG 16 16
SET VALZO 0
SET FCAL 3 -5.00 5.00
SET FVAL 3 -5.00 5.00
>
NUMPTS
Set/Get
Sets the number calibration and validation temperature and pressure points. This setting works
with the MIN and MAX setting to the calibration and validation points.
SET NUMPTS <tcal> <pcal> <tval> <pval>
Where:
<tcal> = Number of temperature points for a calibration.
<pcal> = Number of pressure points for a calibration.
<tval> = Number of temperature points for a validation.
<pval> = Number of pressure points for a validation.
These values are not range checked.
Prompt when ready to accept a new command
SET NUMPTS 15 25 3 15
>
5 9 5 9
<0 to 15> <0 to 25> <0 to 15> <0 to 25>
