MPS4232
Table 5.3 - LabVIEW® Binary Packet (32 Chan)
This is the standard LabVIEW® binary packet for the MPS4232. This packet is a total of 136 bytes sent as 34 array elements.
This packet is used when FORMAT B is set to L. and SIM is set to 0.
FUNCTION
Frame Number
MPS Average
Temperature
Pressure
Channel 1
Pressure
Channel 2
::: :::
Pressure
Channel 32
Table 5.4 - LabVIEW® Binary Packet (64 Chan)
This is the LabVIEW® binary packet that simulates a MPS4264 packet. This packet is a total of 264 bytes sent as 66 array
elements. This packet is used when FORMAT B is set to L and SIM is set to 64. Note: This is implemented as a backward
compatible MPS4264 LabVIEW® packet. Channel data 33-64 will be padded with 0 and do not represent believable data. This
allows the same packet structure to be used for MPS4200 32 and 64 channel modules in the same software.
FUNCTION
Frame Number
MPS Average
Temperature
Pressure
Channel 1
Pressure
Channel 2
::: :::
Pressure
Channel 64

FTP File Names and Formats

When the MPS4232 is configured to output data via FTP, it must create a file at the destination. The table below shows the
common file names and formats for FTP scan data when the different formats are used (ASCII, Binary, CSV).
SETTING OF FORMAT VARIABLE
BYTES DATA TYPE
4 Float
4 Float
4 Float
4 Float
::: ::: :::
4 Float
BYTES DATA TYPE
4 Float
4 Float
4 Float
4 Float
::: ::: :::
4 Float
Table 5-8: File Name Extensions
SET FORMAT F A
SET FORMAT F B
SET FORMAT F C
ARRAY
ELEMENT
0 The current frame number if in the scan mode.
1 Average temperature (4 RTDs) of MPS.
2
3
::: :::
33
ARRAY
ELEMENT
0 The current frame number if in the scan mode.
1 Average temperature (4 RTDs) of MPS.
2
3
::: :::
65
TYPE OF SCAN
ASCII
Binary
Comma Separated Variable
37
Section 5: Software
DESCRIPTION
Pressure values for channel 1
Pressure values for channel 2
::: ::: ::: :::
Pressure values for channel 32
DESCRIPTION
Pressure values for channel 1
Pressure values for channel 2
::: ::: ::: :::
Padded data (0) for channel 64
FILE EXTENSION
nnnn.txt
nnnn.dat
nnnn.csv
