Set Scan Units (UNITS)

COMMAND
TYPE
DESCRIPTION
SYNTAX
RETURNS
EXAMPLE
EXAMPLE
Sets the number of frames to output during a scan. Once this number of frames is met during a
scan, the MPS will stop scanning and return to READY mode.
A Frame contains a sampled pressure value per channel output (32 channels total) plus time
stamp, frame number, temperatures, and other additional information defined by the data output
configured in the MPS.
The FPS variable can be used to configure a scan for a certain time duration using the following
equation:
FPS = RATE x TIME
where RATE is expressed in Hertz and TIME is expressed in seconds
SET FPS <number of frames>
Where <number of frames> is the number of frames in a scan. When set to 0 the scan
continues until the STOP command is issued.
Prompt when ready to accept a new command
SET FPS 100
>
0
0 to 4294967295
UNITS
Set/Get
Set the scan units (pressure engineering units)
SET UNITS <units> [<user cv>]
Where <units> is one of the following:
PSI
CMH2O
INHG
KGCM2
MBAR
NCM2
PSF
When <units> is set to USER, the user must enter a value for <user cv>.
Prompt when ready to accept a new command
// To configure the EU output to PSI
UNITS PSI
>
// To configure a user conversion value
UNITS USER 1.50
>
ATM BAR
DECIBAR FTH2O
INH2O KNM2
KPA KIPIN2
MH2O MMHG
OZIN2 OZFT2
TORR USER
49
Section 5: Software
CMHG
GCM2
KGM2
MPA
NM2
PA
RAW
