- Page 1 EclExpo Flood300VW 300W asymmetric LED floodlight, with Variable White CCT 2,700K - 6,500K USER MANUAL English version REV.01-04/22...
- Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
-
Page 3: Table Of Contents
FILTER FRAME (CODE ECLEXPOFL300VWFFB/W - OPTIONAL) ........21 BARNDOOR (CODE ECLEXPOFL300VWBDB/W - OPTIONAL) ........22 14 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............23 REPLACING THE FUSE ....................23 VISUAL CHECK OF PRODUCT HOUSING ..............23 TROUBLESHOOTING ..................... 24 PROLIGHTS - EclExpo Flood300VW... -
Page 4: Safety Information
• Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. Installation •... - Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
- Page 6 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - EclExpo Flood300VW...
-
Page 7: Packaging
• ECLEXPOFL300VWWKB / W: wireless kit for ECLEXPOFL300VW, black / white finishing; • UPBOX1U: Firmware uploader kit, USB IN, 3pin XLR DMX OUT, USB OUT. 2 - TECHNICAL DRAWING Weight: 5.1 kg / 2.31 lbs Fig. 01 PROLIGHTS - EclExpo Flood300VW... -
Page 8: Installation
Do not use any type of clamp that does not completely encircle the structure when fastened. C6002 RSR0630A/B clamp steel security cable 391 mm [15.4 in] 160 mm [6.3 in] 35 mm [1.4 in] Ø13 mm [0.5 in] Fig. 02 337 mm [13.3 in] PROLIGHTS - EclExpo Flood300VW... -
Page 9: Connection To The Mains Supply
• In case you wish to run the product through an external battery, then connect the product to an external battery (24-36V) into the dedicated XLR4p socket; to disconnect power, disconnect the Battery from the socket. PROLIGHTS - EclExpo Flood300VW... -
Page 10: Product Overview
8. DMX IN (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C. 9. DMX OUT (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C. 10. ANTENNA of Wireless DMX Receiver internal module. Fig. 03 PROLIGHTS - EclExpo Flood300VW... -
Page 11: Dmx Connection
... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX512 Controller Fig. 05 - Example 15 DMX channels configuration PROLIGHTS - EclExpo Flood300VW... -
Page 12: Construction Of The Dmx Termination
5. Ensure that the receiver units are not connected to any other transmitter. Please refer to "Reset the receiver" paragraph. 6. Enable TX LINK to ON to link transmitter to receivers (please note that TX LINK will be avaible only if WDMX mode is set to Transmitter). PROLIGHTS - EclExpo Flood300VW... -
Page 13: Unlinking The Transmitter
• The wireless icon on the receiver display indicates the received signal strength. WDMX TO DMX (RX) This function enable or disable the retransmission of the wireless DMX signal received throught the DMX port on the receiver side. PROLIGHTS - EclExpo Flood300VW... -
Page 14: Control Panel
The product is equipped with rotatory knobs for manual control of the product, those are enabled only in Stand Alone mode and they enable access to control certain attributes according to the selected STAND ALONE mode as indicated below. PROLIGHTS - EclExpo Flood300VW... -
Page 15: Menu Structure
To choose the desired unit of temperature measurement. UNIT °F TRANSFER WITHOU DMX To transfer the same menu settings of one fixtures to all SETTINGS ADDRESS the other in the daisy chain, including or not the dmx address. WITH DMX ADDRESS PROLIGHTS - EclExpo Flood300VW... - Page 16 PARTIAL POWER ON TOTAL CYCLE PARTIAL MAINTENANCE ELAPSED TIME TIME ALERT PERIOD TEMPERATURE NEAR SOURCE TEMP, DRIVER PCB TEMP, LED PCB TEMP,… FAN SPEED CHANNEL VALUE ERROR MESSAGE FIXTURE MODEL DEVICE LABEL SOFTWARE VERSION RDM UID PROLIGHTS - EclExpo Flood300VW...
- Page 17 <000 - 255> MANUAL User generated color preset by COLOR <000 - 255> assigning values to each primary color attribute. After enabled this mode, STROBE <000 - 255> the unit will be automatically assigned as Master PROLIGHTS - EclExpo Flood300VW...
-
Page 18: Rdm Functions
0x0140 DMX_FAIL_MODE 0x0141 DMX_STARTUP_MODE 0x0142 DIMMER_INFO 0x0340 MINIMUM_LEVEL 0x0341 MAXIMUM_LEVEL 0x0342 CURVE 0x0343 Dimmer CURVE_DESCRIPTION 0x0344 Settings OUTPUT_RESPONSE_TIME 0x0345 OUTPUT_RESPONSE_TIME_ DESCRIPTION 0x0346 MODULATION_FREQUENCY 0x0347 MODULATION_FREQUENCY_ DESCRIPTION 0x0348 SENSOR_DEFINITION 0x0200 SENSOR_VALUE 0x0201 Sensors RECORD_SENSORS 0x0202 BURN_IN 0x0440 PROLIGHTS - EclExpo Flood300VW... -
Page 19: Shortcuts
This error message indicates that an overheating has occurred and the led has been [TEMPERATURE TOO HIGH] switched OFF by the product protection system. [MAINTENANCE TIME] Need to be done standard maintenance and also reset of elapsed time [DMX ACTIVE] Transfer configuration is used with dmx signal connected PROLIGHTS - EclExpo Flood300VW... -
Page 20: Dmx Charts
EXTENDED Channel BASIC STANDARD EXTENDED DIMMER DIMMER DIMMER DIMMER DIMMER WARM WHITE DIMMER FINE DIMMER FINE COLD WHITE STROBE STROBE CCT FINE CCT FINE CROSSFADE WARM WHITE WARM WHITE FINE COLD WHITE COLD WHITE FINE FUNCTION PROLIGHTS - EclExpo Flood300VW... - Page 21 6400K - 6500K 248 ÷ 255 CCT FINE 000 ÷ 255 CROSSFADE CCT to WW/CW 0~100% 000 ÷ 255 WARM WHITE 0~100% 000 ÷ 255 WARM WHITE FINE 000 ÷ 255 COLD WHITE 0~100% 000 ÷ 255 PROLIGHTS - EclExpo Flood300VW...
- Page 22 Stand Alone Manual Color 082 ÷ 083 Menu Stand Alone 084 ÷ 085 Output Control Constant 086 ÷ 087 Output Control Dynamic 088 ÷ 089 RESERVED 090 ÷ 253 FACTORY DEFAULT OF ALL 254 ÷ 255 CONTROLLED FUNCTION PROLIGHTS - EclExpo Flood300VW...
-
Page 23: Accessories Installation
Insert the anti-glare louvre into the slot (DETAIL 1). Pull the knob out (DETAIL 2) and insert the acces- sory filter frame from the top into the guide on the hardware of the unit (DETAIL 3). Then release the knob (DETAIL 3). NOTE: To remove the accessory, reverse the procedure. Fig. 08 PROLIGHTS - EclExpo Flood300VW... -
Page 24: Barndoor (Code Eclexpofl300Vwbdb/W - Optional)
Unscrew the knob of the barndoor accessory (DETAIL 1). Then mount the barndoor by screwing the knob with the hole on the unit hardware (DETAIL 2). NOTE: To remove the accessory, reverse the procedure. Fig. 09 PROLIGHTS - EclExpo Flood300VW... -
Page 25: Maintenance
WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel. -
Page 26: Troubleshooting
• Check if the Fuse is intact and eventually replace it if fault. necessary. • Contact the PROLIGHTS Service or authorized service partner. Do not remove parts and/or covers, or carry out any repairs or service that are not described in... - Page 28 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
