Slide the end caps onto the brackets.
Removal
Place the screw driver under the end cap, turn
the screw driver and slide the end cap from the
bracket.
2
1
3UHVV WKH ERWWRP RI WKH IURQW SUR¿OH XSZDUGV
DQG SXOO LW RXWZDUGV
REV 01
August`11
15
Disconnect the motors and controls. Slide a screw
driver between bearing plug and bracket and push
the bearing in the motor direction.
16
Move the blind downwards out of the bracket.
17
Lift the motor front plate up and out of the bracket.
18
19
1
20
21
Installation Instruction
Duo
Roller Blind (Fascia)
Motor Operation
Type
5-156
